Audax FS 900X XX1 2018

MTB Cross Country
Groupset
SRAM XX1
Frame material
Carbon
Wheel size
29"
Suspension type
Hardtail
Audax FS 900X XX1 2018

About the Audax FS 900X XX1 2018

The Audax FS 900X XX1 2018 is a Hardtail Cross Country Mountain Bike with a carbon frame. Equipped with a SRAM XX1 drivetrain of 11 gears (1x11).

Specifications

Acessories
Pedals
VP VX500
Components
Saddle
Prologo Zero II
Brakes
SRAM Guide R Hydraulic 392 g
Application
MTB
Blade material
Aluminum - Stamped
Bracket disk brake
Direct mount DIR, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(170mm Rear rotor) 30I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (10mm spacer) 10S, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (30mm bracket) 30P, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Gloss Black
Model
DB-GDE-R-B1
Name
Guide R
Orientation
Front, Rear
Pad type disc
Steel-backed metal sintered, Steel-backed organic
Weight based on
Direct Mount, 800mm hose, 160mm CL Rotor
Weight
392
Drivetrain
Chain
SRAM XX1 246 g
Chain connector
PowerLock
Chain length links
118 links
Color inner link
Silver
Color outer link
Silver
Compat speed
11s
Inner link finish
Chrome Plated
Model
CN-XX-1-A1
Name
XX1 HARD CHROME Chain
Outer link finish
Nickel
Pin variant
Hollow Pin
Weight based on
114 links
Weight
246
Rear derailleur
SRAM XX1 11s 245 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Carbon
Color
Black, Blue, Green, Red
Max tooth
42
Model
RD-XX-1-A2
Name
XX1 X-HORIZON™ Rear Derailleur
Pulley bearings material
Ceramic
Speed
11s
Weight
245
Bottom bracket
FSA BB-392
Frameset
Front suspension
RockShox RS-1 RL Solo Air
Color
Diffusion Black, Gloss Black, Gloss White
fork offset
42mm (27.5"), 51mm (29")
Max tire width (mm)
62
Maximum rotor size
220mm
Minimum rotor size
160mm
Model
FS-RS1-RL-A1
Name
RS-1 RL
Spring
Solo Air
Travel (mm)
100mm, 120mm, 130mm
Upper tube type
32mm straight wall aluminum
Wheel size
27.5", 29"
Rear suspension
RockShox Monarch RL 215 g
Body eyelet
Standard
Compression tune
H, L, L3, M
Eye to eye stroke
152x31, 165x38, 184x44, 190x51, 200x51, 200x57, 216x63
Lockout force
430
Model
RS-MNR-RL-C2
Name
Monarch RL
Rebound tune
H, L, M
Shaft eyelet
Standard
Weight based on
165x38, standard air can, standard eyelet, no hardware
Weight
215
Frame
Audax Carbon

Geometry

Size P M G
a
Seat tube length
420,0
458,0
480,0
b
Seat tube angle
73,5º
73,5º
73,2º
c
Top tube length
565,0
595,0
620,0
d
Head tube length
100,0
110,0
125,0
e
Head tube angle
70,5º
70,5º
70,5º
f
Rake
-
-
-
g
Trail
51,0
51,0
51,0
h
Wheelbase
995,0
1109,0
1138,0
i
Chainstay length
450,0
450,0
450,0
j
Bottom bracket drop
40,0
40,0
40,0
k
Stack height
592,0
607,0
621,0
l
Reach
395,0
413,0
433,0
m
Standover height
-
-
-
x
Bottom bracket height
-
-
-
y
Front center
-
-
-
