Bianchi Magma 9.2 – Deore 2021

MTB Cross Country

Groupset

Shimano Deore

Frame material

Alloy

Wheel size

29"

Suspension type

Hardtail

Front travel

100mm

About the Bianchi Magma 9.2 – Deore 2021

The Bianchi Magma 9.2 – Deore 2021 is a Hardtail Cross Country Mountain Bike with a alloy frame. Equipped with a Shimano Deore drivetrain of 10 gears (1x10). Its features include internal routing e hydraulic disc brakes.

Features

The Bianchi Magma 9.2 – Deore 2021 has 2 features listed below.

Internal routing More info

Hydraulic disc brakes More info

Specifications

Acessories
Grip	T-one T-GP48B
Pedals	included

Components
Steam	Velomann 3D forged Alloy 6061, +/-7°, 1.1/8mm, diam. 31.8mm, ext: 80mm-15/17", 90mm-19/21"
Saddle	Velomann, steel rails, PVC soft touch cover, 140mm width
Headset	Fsa TH888
Seatpost	Velomann AL2014 shaft w/alloy head, diam. 27.2mm, 0mm seatback, length 350mm
Handlebar	Velomann Flat top DB Alloy 6061-T6, width 720mm, diam. 31,8mm, 9° backsweep
Discs	Shimano SM-RT10 160mm
Brakes	Shimano BR-MT200 Hydraulic disc brake 2 piston
Brake hose color kit Black Brake hose kit SM-BH59-JK-SS Brake type Hydraulic disc brake Caliper finish Painted Caliper material Aluminum Caliper fixing bolt anti loosen method Snap ring Caliper fixing bolt material Steel Caliper fixing bolt tool size 5 mm Primary color Black Hose joint Straight J-Kit spec for OEM Model BR-MT200 Mount type Post-type Oil SHIMANO Mineral One way bleeding Pad standard B03S Resin Pad mount Split pin Piston 2 Piston material Resin Recommended brake lever BL-MT201 BL-MT200 Recommended disc brake rotor SM-RT10* SM-RT26*

Drivetrain
Crankset	Shimano FC-M5100-1, 30T, crank lenght: 170mm-15" and 175mm-17/21", w/BB, 52mm
Shifter	Shimano Deore 1x10sp w/o Optical Gear Display, SL-M4100-R w/2050mm inner
Bottom bracket	Shimano SM-BB52
Rear derailleur	Shimano Deore RD-M5120 SGS 11/10s
B axle hollow B axle material Stainless steel Bracket finish Painted Bracket material Steel Bracket body finish Painted Bracket body material Aluminum Lower pulley max 46T (1x11/1x10-speed) 42T (2x11/2x10-speed) Lower pulley min 42T Model RD-M5120-SGS P axle material Steel pulley.screws_material Stainless steel pulley.sunken_type_pulley_screw Pulley teeth 11T Pulley cage SGS Speeds 11/10 Upper pulley max 11T Upper pulley min 11T Total capacity 41T
Chain	KMC X11
Cassette	Shimano Deore CS-M4100-10 HG
Combination names 11-42T 11-46T Compatible chain HG-X 10-speed Lock ring finish Plated Lock ring material Steel Model CS-M4100-10 Steel gear finish Plated Steel gear pieces 10 Type HG

Frameset
Frame	Magma 29 alu, 1.1/8" HT, BSA 68mm, seatpost diam. 27,2mm, HDM bottom pull or Side-Swing, PM 160mm, BOOST 9x141mm QR, internal cable routing, sizes 15-17-19-21"
Front suspension	SR Suntour XCR 32
