BMC Speedfox AL ONE 2022

MTB Trail
Groupset
SRAM NX Eagle
Frame material
Alloy
Wheel size
29"
Suspension type
Full suspension
Weight
1 kg
Front travel
130mm
Rear travel
120mm
BMC Speedfox AL ONE 2022

About the BMC Speedfox AL ONE 2022

The BMC Speedfox AL ONE 2022 is a Full suspension Trail Mountain Bike with a alloy frame. Equipped with a SRAM NX Eagle drivetrain of 12 gears (1x12). Its features include internal routing, dropper seatpost, and boost 148. The bike weighs approximately 1 kg.

Features

The BMC Speedfox AL ONE 2022 has 5 features listed below.
cabeamento-interno
Internal routing More info
canote-retratil
Dropper seatpost More info
cubo-traseiro-boost
Boost 148 More info
eixo-e-thru
E-THRU AXLE More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Components
Steam
BMC AMSM02
Saddle
WTB Silverado Comp
Seatpost
X-Fusion Manic Dropper 125/150mm, 31,6mm
Handlebar
BMC MFB03 Alloy 760mm
Brakes
Shimano Deore BR-M6100 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH90-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Series Color
Secondary color
Black (SHIMANO logo) ***
Hose joint
Straight
ICE TECHNOLOGIES pad compatible caliper
J-Kit spec for OEM
Model
BR-M6100
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad option
G04S Metal
Pad standard
G03S Resin
Pad standard
J03A Resin
Piston
2
Piston material
Resin
Recommended disc brake rotor
SM-RT54*
SM-RT56*
SM-RT64
SM-RT66
Drivetrain
Crankset
SRAM Stylo 6k Eagle 30T
Shifter
SRAM NX Eagle
Bottom bracket
BSA, threaded
Chain
SRAM NX Eagle 252 g
Chain connector
PowerLock
Chain length links
126 links
Color inner link
Grey
Color outer link
Grey
Compat speed
12s-Eagle
Inner link finish
Polished
Model
CN-EAGL-NX-A1
Name
NX Eagle Chain
Outer link finish
Polished
Pin variant
Solid Pin
Weight based on
114 links
Weight
252
Rear derailleur
SRAM NX Eagle 12s 339 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
50
Model
RD-NX-1-B1
Name
NX Eagle Rear Derailleur
Pulley bearings material
Steel
Speed
12s
Weight
339
Cassette
SRAM NX Eagle
Frameset
Frame
Speedfox Premium Aluminium with APS Suspension SyStem with 120mm, • Internal Cable Routing, • BSA Threaded Bottom Bracket, • Post Mount Disc, • 12x148mm Boost Thru-Axle
Rear suspension
Fox Float DPS Performance EVOL
Front suspension
RockShox Recon Silver RL Solo Air
Color
Diffusion Black, Gloss Black
Damper type
Motion Control
fork offset
37mm (27.5"), 42mm (27.5"), 42mm (29"), 46mm (27.5"), 46mm (29"), 51mm (29")
Max tire width (mm)
62, 81
Maximum rotor size
220mm
Minimum rotor size
160mm
Model
FS-RCNS-RL-D1
Name
Recon Silver RL
Spring
Solo Air
Travel (mm)
100mm, 120mm, 130mm, 140mm, 150mm
Upper tube type
32mm straight wall steel
Wheel size
27.5", 29"
Wheels
Rims
Alex MD30, 30mm Inner Width
Tires
Maxxis Forekaster 29x2.35 TR, EXO
Rear hub
SHIMANO HB-MT400-B/FH-MT400-B
Front hub
SHIMANO HB-MT400-B/FH-MT400-B

Geometry

Size SM MD LG XL
a
Seat tube length
420,0
440,0
480,0
510,0
b
Seat tube angle
73,8º
73,8º
73,8º
73,8º
c
Top tube length
590,0
614,0
637,0
656,0
d
Head tube length
95,0
105,0
115,0
135,0
e
Head tube angle
68,0º
68,0º
68,0º
68,0º
f
Rake
51,0
51,0
51,0
51,0
g
Trail
90,0
90,0
90,0
90,0
h
Wheelbase
1126,0
1148,0
1172,0
1192,0
i
Chainstay length
448,0
448,0
448,0
448,0
j
Bottom bracket drop
37,0
37,0
37,0
37,0
k
Stack height
603,0
613,0
623,0
638,0
l
Reach
411,0
433,0
453,0
468,0
m
Standover height
716,0
737,0
755,0
776,0
x
Bottom bracket height
337,0
337,0
337,0
337,0
y
Front center
677,0
704,0
728,0
748,0
