BikeWise

Cannondale Habit Carbon 1 2019

MTB Trail
Groupset
Shimano XTR
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Front travel
140mm
Rear travel
130mm
Cannondale Habit Carbon 1 2019

About the Cannondale Habit Carbon 1 2019

The Cannondale Habit Carbon 1 2019 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a Shimano XTR drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148.

Features

The Cannondale Habit Carbon 1 2019 has 6 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
tubeless-ready
Tubeless ready More info

Specifications

Acessories
Grip
Cannondale Locking Grips
Pedals
Not Included
Components
Steam
Cannondale C1, 3D Forged 6061 Alloy, 1-1/8", 31.8, 0°
Saddle
Fabric Scoop Shallow Race, ti rails
Headset
Integrated, 1-1/8 to 1.5", sealed angular contact bearings
Seatpost
Fox Factory Transfer dropper, Kashima coating, internal routing, 31.6, 125mm (S-M), 150mm (L-XL)
Handlebar
Cannondale C1 Riser, Carbon, 15mm rise, 9° sweep, 4° rise, 780mm
Brake lever
Shimano XTR Trail with Reach Adjust
Brakes
Shimano XTR BR-M9000 316.1 g Hydraulic disc brake 2 piston
Average weight (g)
316.1
Brake hose color kit
Black
Brake hose kit
SM-BH90-SBM
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Magnesium
Caliper fixing bolt anti loosen method
Wiring
Caliper fixing bolt material
Ti
Caliper fixing bolt tool size
** 4 mm
Primary color
Series color
Hose joint
Banjo
ICE TECHNOLOGIES pad compatible caliper
J-Kit spec for OEM
Model
BR-M9000
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad option
J02A Resin
J03A Resin
Pad option
J04C Metal
Pad standard
G02A Resin
G03A Resin
Pad standard
G04Ti Metal
Pad mount
Pad axle
Piston
2
Piston material
Ceramic
Recommended disc brake rotor
SM-RT99
* SM-RT99-A
Drivetrain
Crankset
Cannondale HollowGram Si, BB30 w/ X-Sync SpideRing, 30T Ai Offset
Shifter
Shimano XTR, 12-speed
Bottom bracket
Cannondale Alloy PressFit30
Chain
Shimano CN-M9100 242 g
Average weight (g)
242
Chromizing treatment roller link pin
Model
CN-M9100
Pin link plate
SIL-TEC
Roller
SIL-TEC
Roller link plate
Chromizing
Type
HG 12-speed
Cassette
Shimano XTR CS-M9100-12 12s HYPERGLIDE+
Aluminum gear finish
Painted
Aluminum gear pieces
3
Aluminum spider arm finish
Anodized
Aluminum spider arm pieces
1
Combination names
10-45T
10-51T
Combination
10-12-14-16-18-21-24-28-32-36-40-45
10-12-14-16-18-21-24-28-33-39-45-51
Compatible chain
HG 12-speed
Lock ring finish
Anodized
Lock ring material
Aluminum
Micro spline
Model
CS-M9100-12
Speeds
12
Steel gear finish
Plated
Steel gear pieces
4
Titanium gear finish
Shot
Titanium gear pieces
5
Type
HYPERGLIDE+
Weights
10-45T: 357g
10-51T: 367g
Rear derailleur
Shimano XTR RD-M9100-SGS 240 g SGS 12s
Average weight (g)
240
B axle finish
Anodized
B axle hollow
B axle material
Aluminum
Bracket body finish
Anodized
Bracket body material
Aluminum
Compatible chain
HG 12-speed
Lower pulley max
51T
Lower pulley min
51T
Model
RD-M9100-SGS
P axle material
Steel
pulley.guide_pulley_bearing
Sealed bearing
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
13T
pulley.tension_pulley_bearing
Sealed bearing
Pulley cage
SGS
Speeds
12
Upper pulley max
10T
Upper pulley min
10T
Total capacity
41T
Frameset
Frame
All-New Habit, 130mm travel, BallisTec Carbon Frame and Swingarm, Proportional Response Tuned, Ai offset drivetrain, ISCG05, PF30, Post mount brake, tapered headtube
Rear suspension
Fox Float DPX2 Factory EVOL
Front suspension
Fox 34 Float Factory Kashima
Wheels
Rims
Stan’s NoTubes Arch MK3, 28h, tubeless ready
Tires
Maxxis Minion DHF 29 x 2.5" WT front, High Roller II 2.3" rear, 3C compound, Max Terra, EXO puncture protection, tubeless ready
Spokes
DT Swiss Competition, straight pull (Ai Offset dish - rear)
Rear hub
Shimano XTR 15x110 front, 12x148 rear 28h, straight pull
Front hub
Shimano XTR 15x110 front, 12x148 rear 28h, straight pull

Geometry

Size XS SM MD LG XL
a
Seat tube length
380,0
400,0
440,0
480,0
520,0
b
Seat tube angle
74,5º
74,5º
74,5º
74,5º
74,5º
c
Top tube length
535,0
570,0
603,0
636,0
668,0
d
Head tube length
95,0
105,0
115,0
125,0
135,0
e
Head tube angle
66,0º
66,0º
66,0º
66,0º
66,0º
f
Rake
44,0
51,0
51,0
51,0
51,0
g
Trail
112,0
112,0
112,0
112,0
112,0
h
Wheelbase
1,1e3
1139,0
1173,0
1207,0
1241,0
i
Chainstay length
432,0
432,0
432,0
432,0
432,0
j
Bottom bracket drop
28,0
38,0
38,0
38,0
38,0
k
Stack height
597,0
604,0
613,0
622,0
631,0
l
Reach
363,0
397,0
427,0
457,0
487,0
m
Standover height
697,0
717,0
747,0
767,0
777,0
x
Bottom bracket height
331,0
339,0
339,0
339,0
339,0
y
Front center
670,0
710,0
743,0
778,0
811,0
