Cannondale Jekyll Carbon 29 2 2020

MTB Enduro
Groupset
SRAM X01 Eagle
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Weight
14,9 kg
Front travel
150mm
Rear travel
150mm
Cannondale Jekyll Carbon 29 2 2020

About the Cannondale Jekyll Carbon 29 2 2020

The Cannondale Jekyll Carbon 29 2 2020 is a Full suspension Enduro Mountain Bike with a carbon frame. Equipped with a SRAM X01 Eagle drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148. The bike weighs approximately 14,9 kg.

Features

The Cannondale Jekyll Carbon 29 2 2020 has 6 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
tubeless-ready
Tubeless ready More info

Specifications

Acessories
Grip
Fabric Funguy Locking Grips
Pedals
Not Included
Components
Steam
Cannondale 1, 3D Forged 6061 Alloy, 1-1/8", 31.8, 0°
Saddle
Fabric Scoop Shallow Elite, cro-mo rails
Headset
Integrated, 1-1/8 to 1.5", sealed angular contact bearings
Seatpost
Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M-XL)
Handlebar
Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
Brake lever
SRAM Code R hydro disc
Brakes
SRAM Code R Hydraulic
Application
MTB
Blade material
Aluminum - Forged
Bracket disk brake
Direct mount DIR, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(170mm Rear rotor) 30I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (10mm spacer) 10S, Post mount (203mm DIR to 220mm Rotor - 17mm bracket) 17P, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (30mm bracket) 30P, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Dark Grey Paint, Diffusion Black
Model
DB-CODE-R-B1
Name
Code R
Orientation
Front, Rear
Pad type disc
Steel-backed metal sintered, Steel-backed organic
Drivetrain
Crankset
Truvativ Stylo 7K DUB, 30T, Ai offset
Shifter
SRAM GX Eagle, 12-speed
Bottom bracket
SRAM DUB PF30 MTB83
Chain
SRAM GX Eagle 244 g
Chain connector
PowerLock
Chain length links
126 links
Color inner link
Black
Color outer link
Silver
Compat speed
12s-Eagle
Inner link finish
Black Oxide
Model
CN-EAGL-GX-A1
Name
GX Eagle Chain
Outer link finish
Nickel
Pin variant
Solid Pin
Weight based on
114 links
Weight
244
Cassette
SRAM XG-1295 Eagle Cassette 12s 357 g
Cog finish cassete
Black
Cog sizes
10-50t:10,12,14,16,18,21,24,28,32,36,42,50
Gearing
10-50t
Model
CS-XG-1295-A1
Name
XG-1295 Eagle Cassette
Speed
12s
Technology cassete
XG
Weight
357
Rear derailleur
SRAM X01 Eagle 12s
Cable pull ratio
X-actuation
Color
Black, Lunar, Red
Max tooth
52
Model
RD-X0-1-B2
Name
X01 Eagle Rear Derailleur
Speed
12s
Frameset
Frame
BallisTec Carbon front triangle, SmartForm C1 Alloy swingarm, 150mm travel, Ai offset drivetrain, ISCG05, PF30-83, flat mount brake, tapered headtube, 150mm travel, Ai offset drivetrain, ISCG05, PF30-83, Flat mount brake, Tapered headtube
Rear suspension
Fox Float DPX2 Factory EVOL
Front suspension
Fox 36 Float Performance
Wheels
Rims
Stan's NoTubes Flow MK3, 32h, tubeless ready
Tires
Maxxis Assegai, 29 x 2.5", 3C Compound, Max EXO puncture protection, tubeless ready
Spokes
DT Swiss Champion
Rear hub
SRAM 900 12x148 w/ XD driver
Front hub
Formula 15x110

Geometry

Size SM MD LG XL
a
Seat tube length
400,0
430,0
460,0
520,0
b
Seat tube angle
-
-
-
-
c
Top tube length
586,0
611,0
636,0
664,0
d
Head tube length
102,0
115,0
127,0
140,0
e
Head tube angle
65,0º
65,0º
65,0º
65,0º
f
Rake
42,0
42,0
42,0
42,0
g
Trail
130,0
130,0
130,0
130,0
h
Wheelbase
1179,0
1207,0
1234,0
1264,0
i
Chainstay length
442,0
442,0
442,0
442,0
j
Bottom bracket drop
16,0
16,0
16,0
16,0
k
Stack height
598,0
610,0
621,0
633,0
l
Reach
419,0
440,0
462,0
487,0
m
Standover height
760,0
766,0
776,0
788,0
x
Bottom bracket height
360,0
360,0
360,0
360,0
y
Front center
738,0
765,0
792,0
823,0
