Canyon Dude CF 8.0 2018

MTB Fatbike
Groupset
SRAM NX
Frame material
Carbon
Wheel size
26"
Suspension type
Rigid
Weight
12,2 kg
Canyon Dude CF 8.0 2018

About the Canyon Dude CF 8.0 2018

The Canyon Dude CF 8.0 2018 is a Rigid Fatbike Mountain Bike with a carbon frame. Equipped with a SRAM NX drivetrain. Its features include hydraulic disc brakes. The bike weighs approximately 12,2 kg.

Features

The Canyon Dude CF 8.0 2018 has 1 features listed below.
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
Canyon Bracelets, High level of damping quality thanks to a milling out of the inner plastic layer
Pedals
none included
Components
Steam
Iridium
Saddle
Iridium Trail
Headset
Cane Creek 40 | IPU Top Cap
Seatpost
Iridium
Handlebar
Iridium Riserbar
Brakes
Shimano BR-MT500 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH59-JK-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Black
Hose joint
Straight
J-Kit spec for OEM
Model
BR-MT500
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad standard
B03S Resin
Pad mount
Split pin (stainless steel)
Piston
2
Piston material
Resin
Recommended disc brake rotor
SM-RT54*
SM-RT56*
Drivetrain
Crankset
Race Face Aeffect, 11s, Direct Mount chainring, Lightweight forged aluminium AL6066 crank arm
Shifter
SRAM NX Trigger, 11s
Bottom bracket
Race Face
Rear derailleur
SRAM NX 11s 322 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
42
Model
RD-NX-1-A1
Name
NX 1x11 X-HORIZON™ Rear Derailleur
Pulley bearings material
Steel
Speed
11s
Weight
322
Cassette
Shimano SLX CS-M7000-11 HG
Aluminum gear pieces
1 (11-40T)
1 (11-42T)
2 (11-46T)
Aluminum spider arm finish
Anodized
Aluminum spider arm pieces
1
Combination names
11-40T
11-42T
11-46T
Compatible chain
HG 11-speed, LG
Lock ring finish
Plated
Lock ring material
Steel
Model
CS-M7000-11
Steel gear finish
Shot-Ni
Steel gear pieces
10 (11-40T)
10 (11-42T)
9 (11-46T)
Type
HG
Weights
11-40T: 450g
11-42T: 476g
11-46T: 482g
Chain
SRAM PC-1110 259 g
Chain connector
PowerLock
Chain length links
114 links
Color inner link
Grey
Color outer link
Grey
Compat speed
11s
Inner link finish
Polished
Model
CN-1110-A1
Name
PC-1110 Chain
Outer link finish
Polished
Pin variant
Solid Pin
Weight based on
114 links
Weight
259
Frameset
Frame
Canyon Dude CF, Carbon fibre fatbike frame constructed from multi-modulus carbon composites, 12 mm Canyon Through Axle, Impact Protection Unit shields the top tube, Two rear dropout positions for 4.0" and 4.8" tyres, PressFit bottom bracket, Weight: 1550 g
Front suspension
Canyon Rude CF Carbon
Wheels
Rims
DT Swiss BR 2300, Wheelset designed exclusively for the demands of fatbikes, DT Swiss Pawl System freehub, Rim Width: 80 mm
Tires
Schwalbe Jumbo Jim, 4.0, Triple Star, PaceStar Compound, 127 EPI Carcass, Width: 4.0"

Geometry

Size SM MD LG
a
Seat tube length
390,0
445,0
490,0
b
Seat tube angle
74,0º
74,0º
74,0º
c
Top tube length
576,0
612,0
649,0
d
Head tube length
95,0
120,0
145,0
e
Head tube angle
68,5º
68,5º
68,5º
f
Rake
11,0
-25,0
-62,0
g
Trail
123,0
162,0
202,0
h
Wheelbase
1111,0
1111,0
1111,0
i
Chainstay length
446,0
446,0
446,0
j
Bottom bracket drop
-60,0
-60,0
-60,0
k
Stack height
612,0
635,0
659,0
l
Reach
402,0
432,0
462,0
m
Standover height
768,0
788,0
788,0
x
Bottom bracket height
403,0
403,0
403,0
y
Front center
672,0
672,0
672,0
