Canyon Strive CF 9.0 Team 2018

Groupset
SRAM X01 Eagle
Frame material
Carbon
Wheel size
27,5"
Suspension type
Full suspension
Weight
13,6 kg
Canyon Strive CF 9.0 Team 2018

About the Canyon Strive CF 9.0 Team 2018

The Canyon Strive CF 9.0 Team 2018 is a Full suspension Enduro Mountain Bike with a carbon frame. Equipped with a SRAM X01 Eagle drivetrain. Its features include internal routing, dropper seatpost, and hydraulic disc brakes. The bike weighs approximately 13,6 kg.


Features

The Canyon Strive CF 9.0 Team 2018 has 4 features listed below.
cabeamento-interno
Internal routing More info
canote-retratil
Dropper seatpost More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info

Specifications

Acessories
Grip
Ergon GE10 Slim
Pedals
none included
Components
Steam
Renthal Apex, Angle: + / - 6°, 1 1/8” clamp, Stack: 40 mm, Handlebar clamp: 35 mm
Saddle
Ergon SME3 Pro Titanium
Headset
Canyon | Acros
Seatpost
RockShox Reverb Stealth B1, Dropper post with infinite height adjustment, Internally routed hose for clean look, 150 mm of adjustment, Framesize XS and S: 125 mm of adjustment, Diameter: 30.9 mm
Handlebar
Renthal Fatbar Carbon, Width: 780 mm, 20 mm Rise, Weight: 180 g
Brakes
SRAM Guide RSC Hydraulic 377 g
Application
MTB
Blade material
Aluminum - Forged
Bracket disk brake
Direct mount DIR, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(170mm Rear rotor) 30I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (10mm spacer) 10S, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (30mm bracket) 30P, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Black Anodized, Silver
Model
DB-GDE-RSC-B1
Name
Guide RSC
Orientation
Front, Rear
Pad type disc
Steel-backed metal sintered, Steel-backed organic
Weight based on
Direct Mount, 800mm hose, 160mm CL Rotor
Weight
377
Drivetrain
Crankset
SRAM X01 EAGLE Carbon, 12s, Carbon cranks, X-SYNC™ tooth profile for maximum chain control, Direct mount chainring, 24 mm axle
Shifter
SRAM X01 Eagle Trigger, 12s, SRAM 1X™ X-ACTUATION™ for precise and reliable 12-gear performance, Zero loss for quicker shifting procedure, Compatible with MatchMaker X, Aluminium body and adjustable lever, 12-speed
Chain guide
MRP V3 S3
Bottom bracket
SRAM GXP
Chain
SRAM X01 Eagle 239 g
Chain connector
PowerLock
Chain length links
126 links
Color inner link
Silver
Color outer link
Silver
Compat speed
12s-Eagle
Inner link finish
Chrome Plated
Model
CN-EAGL-X01-A1
Name
X01 Eagle Chain
Outer link finish
Nickel
Pin variant
Hollow Pin
Weight based on
114 links
Weight
239
Cassette
SRAM XG-1295 Eagle 12s 350 g
Cog finish cassete
Black
Cog sizes
10-52t:10,12,14,16,18,21,24,28,32,36,42,52
Gearing
10-52t
Model
CS-XG-1295-B1
Name
XG-1295 Eagle Cassette
Speed
12s
Technology cassete
XG
Weight
350
Rear derailleur
SRAM X01 Eagle 12s
Cable pull ratio
X-actuation
Color
Black, Lunar, Red
Max tooth
52
Model
RD-X0-1-B2
Name
X01 Eagle Rear Derailleur
Speed
12s
Frameset
Frame
Canyon Strive CF, Geometry, suspension travel and response adjustment with Shapeshifter, 2400 g carbon frame (incl. Shapeshifter), Tapered Head Tube, Internal routing for gear cables, brakes and dropper post., Down Tube Protector, 180mm Direct Post Mount Brakes, 160/135 mm Travel, Video Manual: Canyon Shapeshifter System
Front suspension
RockShox Lyrik RCT3 Dual Position Air, Solo Air 2005 g
Color
Diffusion Black, Gloss Black, Gloss White
Damper type
Charger, n/a
fork offset
42mm (27.5"), 46mm (27.5"), 51mm (29")
Max tire width (mm)
62, n/a
Maximum rotor size
203mm
Minimum rotor size
160mm
Model
FS-LYRK-RCT3-A1
Name
Lyrik RCT3
Spring
Dual Position Air, Solo Air
Travel (mm)
150mm, 160mm, 170mm, 180mm
Upper tube type
35mm tapered wall aluminum
Weight based on
27/29 Solo Air, RCT3, 180mm travel
Weight
2005
Wheel size
27.5", 27.5" B, 29", 29" B/27.5"+
Rear suspension
RockShox Monarch Plus RC3
Body eyelet
No Bushing, Standard
Compression tune
H, L, L1, L3, M
Eye to eye stroke
190x51, 200x51, 200x57, 216x63
Model
RS-MNRP-RC3-B4
Name
Monarch Plus RC3
Rebound tune
H, L, M
Shaft eyelet
No Bushing, Standard
Wheels
Rims
Mavic Deemax Pro
Tires
Mavic Claw Pro, 2.4 | MAVIC Quest Pro XL, 2.35

Geometry

Size XS SM MD LG XL
a
Seat tube length
388,0
430,0
430,0
460,0
500,0
b
Seat tube angle
73,5º
73,5º
73,5º
73,5º
73,5º
c
Top tube length
581,0
605,0
634,0
653,0
663,0
d
Head tube length
95,0
115,0
125,0
135,0
155,0
e
Head tube angle
66,0º
66,0º
66,0º
66,0º
66,0º
f
Rake
-
56,0
55,0
50,0
56,0
g
Trail
-
97,0
98,0
104,0
97,0
h
Wheelbase
1137,0
1163,0
1193,0
1212,0
1245,0
i
Chainstay length
428,0
428,0
428,0
428,0
428,0
j
Bottom bracket drop
-
36,0
36,0
36,0
36,0
k
Stack height
597,0
611,0
620,0
632,0
648,0
l
Reach
407,0
427,0
453,0
473,0
492,0
m
Standover height
-
-
-
-
-
x
Bottom bracket height
-
319,0
319,0
319,0
319,0
y
Front center
-
737,0
767,0
786,0
819,0
