Compare bikes

CUBE AMS 100 C:68 SL 29 2021 vs Canyon Lux CF SLX 9.0 Race Team 2020

CUBE 2021

AMS 100 C:68 SL 29
Canyon 2020

Lux CF SLX 9.0 Race Team

Details
Year	2021	2020
Category	Cross Country	Cross Country
Groupset	Shimano XT	Shimano XTR
Crank	32-32T	34-34T
Cassette	10-51T	10-51T
Speeds	12v	12v
Weight	10,9 kg	10,2 kg
Frame material	Carbon	Carbon
Wheel size	29"	29"
Suspension type	Full suspension	Full suspension
Front travel	100mm	100mm
Rear travel	100mm	100mm
Price	-	-

Components
Acessories
Grip	CUBE Race SL Grip 29.5mm, 1-Clamp	Ergon GA20
Pedals	-	None included
Components
Steam	Newmen Evolution SL 318.2, 31.8mm	Canyon V14
Saddle	Natural Fit Nuance SLT Carbon	Ergon SM Team
Headset	VP Integrated, Top 1 1/8", Bottom 1 1/2"	-
Seatpost	Newmen Advanced, Carbon, 31.6mm	Kind Shock Lev CI
Handlebar	Newmen Advanced 318.0, Carbon, 740mm	Canyon H20 Carbon Flatbar, Material: Carbon, Rise : 5 mm
Brakes	Shimano Deore XT BR-M8100 392 (BL-M8100) g Hydraulic disc brake 2 piston Shimano Deore XT BR-M8100 Average weight (g) 392 (BL-M8100) Brake hose color kit Black Brake hose kit SM-BH90-SBM Brake type Hydraulic disc brake Caliper finish Painted Caliper material Aluminum Caliper fixing bolt anti loosen method Snap ring Caliper fixing bolt material Steel Caliper fixing bolt tool size 5 mm Primary color Series color Hose joint Banjo ICE TECHNOLOGIES pad compatible caliper J-Kit spec for OEM Model BR-M8100 Mount type Post-type Oil SHIMANO Mineral One way bleeding Pad option J03A Resin (w/ fin) Pad option J04C Metal (w/ fin) Pad standard G03A Resin (w/o fin) Pad standard G04S Metal (w/o fin) Pad mount Pad axle Piston 2 Piston material Ceramic Recommended brake lever BL-M8100 BL-T8100	Shimano XTR BR-M9100 312 (BL-M9100) g Hydraulic disc brake 2 piston Shimano XTR BR-M9100 Average weight (g) 312 (BL-M9100) Brake hose color kit Black Brake hose kit SM-BH90-SS Brake type Hydraulic disc brake Caliper finish Anodizing Caliper material Aluminum caliper.mono_body Caliper fixing bolt anti loosen method Wiring Caliper fixing bolt material Ti Caliper fixing bolt tool size ** 4 mm Primary color Series color Hose joint Straight J-Kit spec for OEM Model BR-M9100 Mount type Post-type Oil SHIMANO Mineral One way bleeding Pad standard K03Ti Resin pad w/o fin (w/ titanium back plate) Pad standard K04Ti Metal pad w/o fin (w/ titanium back plate) Pad mount Pad axle Piston 2 Piston material Ceramic
Discs	-	Shimano RT-MT900, Disc Mount: Centerlock
Drivetrain
Crankset	Shimano XT, 32T	Race Face Next SL G5 Carbon 34T 34
Shifter	Shimano XT SL-M8100-IR, Direct Attach	Shimano XTR M9100 12s, Clamp: I-Spec EV
Rear derailleur	Shimano Deore XT RD-M8100 284 g SGS 12s Shimano Deore XT RD-M8100 Average weight (g) 284 B axle hollow B axle material Stainless steel Bracket body finish Painted Bracket body material Aluminum Compatible chain HG 12-speed Lower pulley max 51T Lower pulley min 51T Model RD-M8100-SGS P axle material Steel pulley.guide_pulley_bearing Sealed bearing pulley.screws_material Stainless steel pulley.sunken_type_pulley_screw Pulley teeth 13T pulley.tension_pulley_bearing Sealed bearing Pulley cage SGS Speeds 12 Upper pulley max 10T Upper pulley min 10T Total capacity 41T	Shimano XTR RD-M9100-SGS 240 g SGS 12s Shimano XTR RD-M9100-SGS Average weight (g) 240 B axle finish Anodized B axle hollow B axle material Aluminum Bracket body finish Anodized Bracket body material Aluminum Compatible chain HG 12-speed Lower pulley max 51T Lower pulley min 51T Model RD-M9100-SGS P axle material Steel pulley.guide_pulley_bearing Sealed bearing pulley.screws_material Stainless steel pulley.sunken_type_pulley_screw Pulley teeth 13T pulley.tension_pulley_bearing Sealed bearing Pulley cage SGS Speeds 12 Upper pulley max 10T Upper pulley min 10T Total capacity 41T
Chain	Shimano CN-M6100 252 g Shimano CN-M6100 Average weight (g) 252 Chromizing treatment roller link pin Model CN-M6100 Pin link plate Gray Roller link plate Brown Type HG 12-speed	-
Cassette	Shimano SLX CS-M7100-12 HYPERGLIDE+ Shimano SLX CS-M7100-12 Aluminum gear finish Anodized Aluminum gear pieces 1 Aluminum spider arm finish Painted Aluminum spider arm pieces 1 Combination names 10-45T 10-51T Compatible chain HG 12-speed Lock ring finish Anodized Lock ring material Aluminum Model CS-M7100-12 Steel gear finish Plated Steel gear pieces 11 Type HYPERGLIDE+ Weights 10-45T: 513g 10-51T: 534g	Shimano XTR CS-M9100-12 12s HYPERGLIDE+ Shimano XTR CS-M9100-12 Aluminum gear finish Painted Aluminum gear pieces 3 Aluminum spider arm finish Anodized Aluminum spider arm pieces 1 Combination names 10-45T 10-51T Combination 10-12-14-16-18-21-24-28-32-36-40-45 10-12-14-16-18-21-24-28-33-39-45-51 Compatible chain HG 12-speed Lock ring finish Anodized Lock ring material Aluminum Micro spline Model CS-M9100-12 Speeds 12 Steel gear finish Plated Steel gear pieces 4 Titanium gear finish Shot Titanium gear pieces 5 Type HYPERGLIDE+ Weights 10-45T: 357g 10-51T: 367g
Bottom bracket	-	Race Face Pressfit Cinch
Frameset
Frame	C:68, Carbon Technology	Canyon Lux CF SLX, Material: Carbon, Travel: 100 mm, Axle Dimension: 12 x 148 mm, Brake Mount: Flat Mount
Rear suspension	Fox Float DPS	Fox Float DPS Factory
Front suspension	Fox 32 Float SC	Fox 32 Factory SC
Wheels
Rims	Newmen Evolution SL X.A.25	DT Swiss XRC 1200 SH12, Rim Material: Carbon, Inner Width: 25 mm, Freewheel: Ratchet, Weight: 787 g
Tires	Schwalbe Racing Ray, Super Race, Addix Speedgrip, Kevlar, 2.25	MAXXIS Ikon 2.2'', Casing: Exo, Compound: 3C Triple, Technology: Tubeless ready

Features
Hydraulic disc brakes
Remote lockout
Tubeless ready
Boost 148
Dropper seatpost
Boost 110

Geometry
Size
Seat tube length	370,0	425,0
Seat tube angle	74,5º	74,0º
Top tube length	569,0	566,0
Head tube length	97,0	90,0
Head tube angle	70,0º	70,0º
Rake	50,0	58,0
Trail	83,0	75,0
Wheelbase	1103,0	1097,0
Chainstay length	447,0	426,0
Bottom bracket drop	42,0	34,0
Stack height	594,0	576,0
Reach	409,0	401,0
Standover height	744,0	777,0
Bottom bracket height	332,0	340,0
Front center	659,0	673,0
