Compare bikes
KTM Macina Kapoho Prestige 2020 vs Trek Rail 9.8 XT 2021
| Year | 2020 | 2021 |
|---|---|---|
| Category | Enduro | Enduro |
| Groupset | Shimano XTR | Shimano XT |
| Crank | 36-36T | - |
| Cassette | 10-51T | 10-51T |
| Speeds | 12v | 12v |
| Weight | 24,5 kg | 22,34 kg |
| Frame material | Carbon | Carbon |
| Wheel size | 27,5" | 29" |
| Suspension type | Full suspension | Full suspension |
| Front travel | 160mm | 160mm |
| Rear travel | 160mm | 150mm |
| Price | - | $9,049.99 |
| Acessories | ||
|
Pedals
|
VP-539 nylon
|
-
|
|---|---|---|
|
Grip
|
-
|
Bontrager XR Trail Comp
|
| Components | ||
|
Brake lever
|
Shimano XTR M9120
|
-
|
|
Brakes
|
Shimano XTR BR-M9120
385 (BL-M9120) g
Hydraulic disc brake
4 piston
Shimano XTR BR-M9120
|
Shimano SLX BR-M7120
444 (BL-M7100) g
Hydraulic disc brake
4 piston
Shimano SLX BR-M7120
|
|
Saddle
|
-
|
Bontrager Arvada
|
|
Headset
|
-
|
Trek Knock Block Integrated
|
|
Seatpost
|
-
|
Bontrager Line Elite Dropper
|
|
Charger
|
-
|
Bosch Standard 4A
|
|
Battery
|
-
|
Bosch PowerTube 625Wh
|
|
Discs
|
-
|
Shimano SM-RT76
Shimano SM-RT76
|
|
Steam
|
-
|
Bontrager Line Pro, 35mm, Knock Block
|
|
Handlebar
|
-
|
Bontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise, 780mm width
|
| Drivetrain | ||
|
Crankset
|
KTM Team, ISIS, 160mm length
|
-
|
|
Chain guide
|
Upper guide
|
-
|
|
Chain
|
Shimano CN-M8100
252 g
Shimano CN-M8100
|
Shimano CN-M8100
252 g
Shimano CN-M8100
|
|
Cassette
|
Shimano Deore XT CS-M8100-12
HYPERGLIDE+
Shimano Deore XT CS-M8100-12
|
Shimano Deore XT CS-M8100
|
|
Rear derailleur
|
Shimano XTR RD-M9100-SGS
240 g
SGS
12s
Shimano XTR RD-M9100-SGS
|
Shimano XT RD-M8100
|
|
Shifter
|
-
|
Shimano Deore XT SL-M8100
117 ( /pc) g
RAPIDFIRE PLUS
Shimano Deore XT SL-M8100
|
|
Motor
|
-
|
Bosch Performance CX
|
| Frameset | ||
|
Rear suspension
|
Fox Float DPX2 Factory
|
RockShox Super Deluxe Ultimate RT3
|
|
Front suspension
|
Fox 36 Float Factory Kashima
|
RockShox ZEB Select+
DebonAir, Dual Position Air
2265 g
RockShox ZEB Select+
|
|
Frame
|
-
|
Trek OCLV Mountain Carbon
|
| Wheels | ||
|
Spokes
|
KTM E-Prime Trail wheelset
|
-
|
|
Rear hub
|
KTM E-Prime Trail wheelset, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
|
-
|
|
Front hub
|
KTM E-Prime Trail wheelset, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
|
-
|
|
Rims
|
-
|
Bontrager Line Comp 30
|
|
Tires
|
-
|
Bontrager SE5 Team Issue, 29x2.60''
|
| Hydraulic disc brakes | ||
|---|---|---|
| Tubeless ready | ||
| Boost 148 | ||
| Dropper seatpost | ||
| Boost 110 | ||
| Tapered head tube | ||
| E-THRU AXLE | ||
| Internal routing |
| Size | ||
|---|---|---|
|
Seat tube length
|
430,0 | 420,0 |
|
Seat tube angle
|
76,8º | 75,0º |
|
Top tube length
|
585,0 | 606,0 |
|
Head tube length
|
100,0 | 105,0 |
|
Head tube angle
|
65,3º | 64,5º |
|
Rake
|
48,0 | 43,0 |
|
Trail
|
111,0 | 131,0 |
|
Wheelbase
|
1212,0 | 1214,0 |
|
Chainstay length
|
438,0 | 441,0 |
|
Bottom bracket drop
|
9,0 | 35,0 |
|
Stack height
|
601,0 | 619,0 |
|
Reach
|
443,0 | 438,0 |
|
Standover height
|
1212,0 | 758,0 |
|
Bottom bracket height
|
346,0 | 339,0 |
|
Front center
|
774,0 | 775,0 |
