Compare bikes

KTM Macina Prowler Sonic 2020

Details
Year	2020
Category	Enduro
Groupset	SRAM XX1 Eagle AXS
Crank	36-36T
Cassette	10-50T
Speeds	12v
Weight	24,1 kg
Frame material	Carbon
Wheel size	27,5"
Suspension type	Full suspension
Front travel	180mm
Rear travel	170mm
Price	-

Components
Acessories
Grip	Ergon GE10 Evo ergonomic
Pedals	VP-539 nylon
Components
Steam	KTM Team Trail, 35mm, with Kiox mount
Saddle	Ergon SM-10 E-Mountain Sport
Battery	Bosch PowerTube, lithium-ion, integrated, removable
Headset	KTM Team
Seatpost	RockShox Reverb AXS dropper, electronic wireless
Handlebar	KTM Prime Trail Carbon, 35mm diameter, 20mm rise, 800mm width
Brake lever	Shimano XTR M9120
Brakes	Shimano XTR BR-M9120 385 (BL-M9120) g Hydraulic disc brake 4 piston Shimano XTR BR-M9120 Average weight (g) 385 (BL-M9120) Brake hose color kit Black Brake hose kit SM-BH90-SBM Brake type Hydraulic disc brake Caliper finish Painted Caliper material Aluminum Caliper fixing bolt anti loosen method Wiring Caliper fixing bolt material Ti Caliper fixing bolt tool size ** 4 mm Primary color Series color Hose joint Banjo ICE TECHNOLOGIES pad compatible caliper J-Kit spec for OEM Model BR-M9120 Mount type Post-type Oil SHIMANO Mineral Pad standard N03A Resin pad (w/ radiator fin) Pad standard N04C Metal pad (w/ radiator fin) Pad mount Pad axle Piston 4 Piston material Ceramic
Drivetrain
Crankset	FSA CK-702/IS Carbon, 160mm length
Motor	Bosch Performance CX Gen.4, 75Nm torque
Shifter	SRAM Eagle AXS, 12-speed, electronic wireless
Chain guide	Upper guide
Rear derailleur	SRAM XX1 Eagle AXS 12s SRAM XX1 Eagle AXS Cage material Carbon Color Black Max tooth 52 Model RD-XX-1E-A1 Name XX1 Eagle AXS derailleur Pulley bearings material Steel Speed 12s
Cassette	SRAM XX1 XG1299 Eagle
Chain	SRAM XX1 Eagle 239 g SRAM XX1 Eagle Chain connector PowerLock Chain length links 126 links Color inner link Black, Gold Color outer link Black, Gold Compat speed 12s-Eagle Inner link finish Chrome plated +PVD Model CN-EAGL-XX1-A1 Name XX1 Eagle Chain Outer link finish Nickel+PVD Pin variant Hollow Pin Weight based on 114 links Weight 239
Frameset
Frame	Carbon Fiber
Front suspension	RockShox Lyrik Ultimate DebonAir 2003 g RockShox Lyrik Ultimate Color BoXXer Red, Gloss Black Damper type Charger 2.1 RC2, Charger 2.1 RCT3 fork offset 37mm (27.5"), 42mm (29"), 46mm (27.5"), 51mm (29") Max tire width (mm) 81 Maximum rotor size 220mm Minimum rotor size 180mm Model FS-LYRK-ULT-C2 Name Lyrik Ultimate Spring DebonAir Travel (mm) 150mm, 160mm, 170mm, 180mm Upper tube type 35mm tapered wall aluminum Weight based on 27.5" BOOST, 150mm, RC2 damper, Maxle Stealth Weight 2003 Wheel size 27.5", 29"
Rear suspension	RockShox Super Deluxe Coil Select+ 398 g RockShox Super Deluxe Coil Select+ Body eyelet Standard, Trunnion Compression tune H, L, L1, LC, M Damper type RT Eye to eye stroke 185x47.5(TR), 185x50(TR), 185x52.5(TR), 185x55(TR), 205x57.5(TR), 205x60(TR), 205x62.5(TR), 205x65(TR), 210x47.5, 210x50, 210x52.5, 210x55, 225x67.5(TR), 225x70(TR), 225x72.5(TR), 225x75(TR), 230x57.5, 230x60, 230x62.5, 230x65, 250x67.5, 250x70, 250x72.5, 250x75 Lockout force 320, 380 Model RS-SDLC-SELP-A2 Name Super Deluxe Coil Select+ Rebound tune H, L, M Shaft eyelet No Bushing, Standard Weight based on W/O coil spring, 210x50, MM tune, standard/standard Weight 398
Wheels
Rims	DT Swiss HXC 1200 Spline 30 Carbon, tubeless ready, 29" front, 27.5" rear
Tires	Front: Maxxis Minion DHF, 3C MaxxTerra, EXO, TR, 29", Rear: Maxxis Minion DHR II, 3C MaxxTerra, EXO, TR, 27.5"
Spokes	DT Swiss HXC 1200 Spline 30 wheelset
Rear hub	DT Swiss HXC 1200 Spline 30 wheelset, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear with XD driver
Front hub	DT Swiss HXC 1200 Spline 30 wheelset, CENTER LOCK rotor mounts, 15x110mm Boost front, 12x148mm Boost rear with XD driver

Features
Hydraulic disc brakes
Tubeless ready
Boost 148
Dropper seatpost
Boost 110

Geometry
Size
Seat tube length	430,0
Seat tube angle	76,5º
Top tube length	586,0
Head tube length	100,0
Head tube angle	65,0º
Rake	48,0
Trail	113,0
Wheelbase	1216,0
Chainstay length	438,0
Bottom bracket drop	4,0
Stack height	603,0
Reach	440,0
Standover height	797,0
Bottom bracket height	351,0
Front center	778,0
