Compare bikes

Mondraker Summum Carbon Pro Team 2020 vs Scott Gambler 930 2020

Mondraker 2020

Summum Carbon Pro Team
Scott 2020

Gambler 930

Details
Year	2020	2020
Category	Downhill	Downhill
Groupset	Shimano Saint	SRAM X5
Crank	36-36T	34-34T
Cassette	11-25T	11-28T
Speeds	10v	8v
Weight	15,7 kg	16,9 kg
Frame material	Carbon	Alloy
Wheel size	27,5"	29"
Suspension type	Full suspension	Full suspension
Front travel	203mm	200mm
Rear travel	205mm	-
Price	-	-

Components
Acessories
Grip	Renthal, double lock-on, kevlar compound, 130mm	-
Pedals	-	Wellgo B155U SCT / flat / w/replaceable pins
Components
Steam	Onoff Krypton DH CNC Integrated FG, 25-30mm adjustable length, 31.8mm clamp, 6061 alloy, 2x6mm spacers included	Syncros DH1.5 31.8mm / Direct Mount 50mm
Saddle	SDG I-Fly 2.0 I-Beam, high-density PU foam, Cordura sides	Syncros Comox 2.0 Crmo Rails
Headset	Onoff Mercurium, 41x30.15x7x45°x45° ACB sealed bearings, geometry kit cups (+/-2° head angle adjustment), external diameter 56mm	Syncros DH adjustable Semi integrated / adj +-1° with cup ID 49.6mm / OD 56mm
Seatpost	SDG Micro I-Beam SP-751 Alloy, 300mm, micro-adjustment	Syncros DH2.0 / 31.6mm / Alloy6061
Handlebar	Renthal Fatbar series 7 alloy, rise: 30mm, width: 780mm, 7° backsweep, 5° upsweep, 31.8mm clamping diameter	Syncros Hixon 1.5 DH 31.8mm / 15mm Rise/ 8° / 800mm Syncros Pro DH dual lock-on grips
Brake lever	Shimano Saint M820	Shimano BL-MT500
Brakes	Shimano Saint BR-M820 438 (BL-M820) g Hydraulic disc brake 4 piston Shimano Saint BR-M820 Average weight (g) 438 (BL-M820) Brake hose color kit Black Brake hose color kit White Brake hose kit SM-BH90-SBLS Brake type Hydraulic disc brake Caliper finish Painted Caliper material Aluminum Caliper fixing bolt anti loosen method Snap ring Caliper fixing bolt material Steel Caliper fixing bolt tool size 5 mm Primary color Series color Hose joint Banjo ICE TECHNOLOGIES pad compatible caliper J-Kit spec for OEM Model BR-M820 Mount type Post-type Oil SHIMANO Mineral One way bleeding Pad standard H01A Resin H03A Resin Pad standard H03C Metal Pad mount Pad axle Piston 4 Piston material Ceramic Recommended disc brake rotor SM-RT99 SM-RT86	Shimano BR-MT520 Hydraulic disc brake 4 piston Shimano BR-MT520 Brake hose color kit Black Brake hose kit SM-BH90-SS Brake type Hydraulic disc brake Caliper finish Painted Caliper material Aluminum Caliper fixing bolt anti loosen method Snap ring Caliper fixing bolt material Steel Caliper fixing bolt tool size 5 mm Primary color Black Hose joint Straight J-Kit spec for OEM Model BR-MT520 Mount type Post-type Oil SHIMANO Mineral One way bleeding Pad standard D03S resin Pad standard D02S Metal Pad mount Split pin Piston 4 Piston material Ceramic
Drivetrain
Crankset	Shimano Saint M820 165mm	Race Face Chester 34T Alloy chainring / 165mm
Shifter	Shimano Saint M820 10-speed	SRAM X4 Trigger Shifter / 8 Speed
Chain guide	e*thirteen LG1 + Race Carbon	SCOTT DH Custom
Bottom bracket	Shimano 83mm BSA	Race Face BB107 Shell 107x41mm
Chain	Shimano CN-HG95 273 g Shimano CN-HG95 Average weight (g) 273 Chromizing treatment roller link pin Model CN-HG95 Pin link plate SIL-TEC Roller link plate SIL-TEC Type HG-X 10-speed	KMC Z7
Rear derailleur	Shimano RD-M820-SS 280 (w/o mode converter) g SS 10s Shimano RD-M820-SS Average weight (g) 280 (w/o mode converter) B axle finish Anodized B axle hollow B axle material Aluminum Bracket finish Painted Bracket material Aluminum Bracket body finish Painted Bracket body material Aluminum Compatible chain HG-X 10-speed Lower pulley max 28/36T Lower pulley min 23T Model RD-M820-SS P axle material Steel pulley.screws_material Stainless steel pulley.sunken_type_pulley_screw Pulley teeth 11T pulley.tension_pulley_bearing Sealed bearing Pulley cage SS Speeds 10 Upper pulley max 12T Upper pulley min 11T Total capacity 25T	SRAM X5 Rear Derailleur 10s, 9/8/7s, 9s SRAM X5 Rear Derailleur Cable pull ratio 1:1, Exact actuation Cage Long, Medium Cage material Aluminum, Aluminum/Steel Color Black, Silver Max tooth 34, 36 Model RD-X5-A1 Name X5 Rear Derailleur Pulley bearings material Standard, Steel Speed 10s, 9/8/7s, 9s
Cassette	Shimano Deore CS-HG500-10	SRAM PG-830 8s SRAM PG-830 Cog finish cassete Silver Cog sizes 11-28t:11,12,14,16,18,21,24,28 11-30t:11,13,15,17,20,23,26,30 11-32t:11,12,14,16,18,21,26,32 Gearing 11-28t 11-30t 11-32t Model CS-PG-830-A1 Name PG-830 Cassette Speed 8s Technology cassete PG
Frameset
Frame	Carbon Fiber	Gambler Alloy 6061 / Hydroformed custom butted / BB107 VLK Virtual 4 Link kinematic 27.5" (2.6) and 29" (2.5) tire compatible with Geo -BB adj. SW DH 12x157mm dropout
Front suspension	Fox 40 Float Factory	RockShox Boxxer Select DebonAir 2558 g RockShox Boxxer Select Color Diffusion Black, Gloss Black Damper type Charger RC fork offset 36mm (27.5"), 46mm (27.5"), 46mm (29"), 56mm (29") Max tire width (mm) 81 Maximum rotor size 220mm Minimum rotor size 200mm Model FS-BXR-SEL-C2 Name BoXXer Select Spring DebonAir Travel (mm) 180mm, 190mm, 200mm Upper tube type 35mm straight wall aluminum Weight based on 27.5" BOOST, 200mm, Maxle Stealth, Short Crown Weight 2558 Wheel size 27.5", 29"
Rear suspension	Fox DHX2 Factory	X-Fusion Vector R Coil Rebound
Wheels
Rims	Mavic DeeMax DH Tubeless, 28mm internal width, hookless, Maxtal aluminum, 28 hole	Syncros MD30 Disc / 29" / 32H black / Tubeless Ready
Tires	Maxxis Assegai 2.5WT, 3C/TR/DH MaxxGrip, folding bead front and rear	Maxxis Assegai 29x2.5" / 2x60TPI Kevlar Bead / DH / TR / 3C Maxx Grip
Spokes	Mavic stainless steel	DT Swiss Industry / 2.0 black
Rear hub	Mavic 20x110mm front, 12x150mm IST-4 QRM rear	Formula DHL-157 157x12mm thru axle / sealed bearings
Front hub	Mavic 20x110mm front, 12x150mm IST-4 QRM rear	Formula DHL-92 Boost / 110x20mm thru axle

Features
Hydraulic disc brakes
Boost 110
Tubeless ready
E-THRU AXLE

Geometry
Size
Seat tube length	400,0	405,0
Seat tube angle	73,5º	67,2º
Top tube length	575,0	540,7
Head tube length	112,0	110,0
Head tube angle	63,0º	63,2º
Rake	-	52,0
Trail	-	119,0
Wheelbase	1,2e3	1217,8
Chainstay length	445,0	440,0
Bottom bracket drop	-	8,5
Stack height	597,0	636,3
Reach	397,0	410,0
Standover height	-	717,3
Bottom bracket height	-	342,6
Front center	-	778,0
