Compare bikes

Orbea OCCAM H30 2020 vs CUBE STEREO 120 HPC TM 29 2020

Orbea 2020

OCCAM H30
CUBE 2020

STEREO 120 HPC TM 29

Details
Year	2020	2020
Category	Trail	Trail
Groupset	Shimano Deore	SRAM GX Eagle
Crank	32-32T	30-30T
Cassette	11-51T	10-50T
Speeds	12v	12v
Weight	-	12,9 kg
Frame material	Alloy	Carbon
Wheel size	29"	29"
Suspension type	Full suspension	Full suspension
Front travel	140mm	130mm
Rear travel	140mm	120mm
Price	-	-

Components
Acessories
Grip	-	SDG Slater
Components
Steam	OC1 3D Forged 35mm interface 7º	Newmen Evolution 318.4, 31.8mm
Saddle	Selle Royal 2043 HRN	SDG Radar
Headset	FSA 1-1/8 - 1-1/2" Integrated	FSA Orbit I-t, Integrated, Top 1 1/8", Bottom 1 1/2"
Seatpost	OC2 Dropper 31.6mm	CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm, 480x150mm (420x125mm for smallest frame size)
Handlebar	OC1 35mm 12mm Rise 780mm	Newmen Evolution 318.20, 760mm
Brakes	Shimano BR-MT200 Hydraulic disc brake 2 piston Shimano BR-MT200 Brake hose color kit Black Brake hose kit SM-BH59-JK-SS Brake type Hydraulic disc brake Caliper finish Painted Caliper material Aluminum Caliper fixing bolt anti loosen method Snap ring Caliper fixing bolt material Steel Caliper fixing bolt tool size 5 mm Primary color Black Hose joint Straight J-Kit spec for OEM Model BR-MT200 Mount type Post-type Oil SHIMANO Mineral One way bleeding Pad standard B03S Resin Pad mount Split pin Piston 2 Piston material Resin Recommended brake lever BL-MT201 BL-MT200 Recommended disc brake rotor SM-RT10* SM-RT26*	Shimano Deore XT BR-M8120 410 (BL-M8100) g Hydraulic disc brake 4 piston Shimano Deore XT BR-M8120 Average weight (g) 410 (BL-M8100) Brake hose color kit Black Brake hose kit SM-BH90-SBM Brake type Hydraulic disc brake Caliper finish Painted Caliper material Aluminum Caliper fixing bolt anti loosen method Snap ring Caliper fixing bolt material Steel Caliper fixing bolt tool size 5 mm Primary color Series color Hose joint Banjo ICE TECHNOLOGIES pad compatible caliper J-Kit spec for OEM Model BR-M8120 Mount type Post-type Oil SHIMANO Mineral Pad option D03S Resin (w/o fin) Pad option D02S Metal (w/o fin) Pad standard N03A Resin (w/ fin) Pad standard N04C Metal (w/ fin) Pad mount Pad axle Piston 4 Piston material Ceramic Recommended brake lever BL-M8100 BL-T8100
Drivetrain
Crankset	OC1 Alloy forged Boost 32t	SRAM X1 1000 Eagle™, 30T
Shifter	Shimano Deore M6100	SRAM NX Eagle™ Trigger
Rear derailleur	Shimano Deore RD-M6100 SGS 12s Shimano Deore RD-M6100 B axle hollow B axle material Stainless steel Bracket body finish Painted Bracket body material Aluminum Compatible chain HG 12-speed Lower pulley max 51T Lower pulley min 51T Model RD-M6100-SGS P axle material Steel pulley.screws_material Stainless steel pulley.sunken_type_pulley_screw Pulley teeth 13T Pulley cage SGS Speeds 12 Upper pulley max 10T Upper pulley min 10T Total capacity 41T	SRAM GX Eagle 12s SRAM GX Eagle Cable pull ratio X-actuation Cage Long Cage material Aluminum Color Lunar Max tooth 52 Model RD-GX-1-B2 Name GX Eagle Rear Derailleur Pulley bearings material Steel Speed 12s
Cassette	Sunrace 12-speed	SRAM XG-1275 Eagle 12s SRAM XG-1275 Eagle Cog finish cassete Black Cog sizes 10-52t:10,12,14,16,18,21,24,28,32,36,42,52 Gearing 10-52t Model CS-XG-1275-B1 Name XG-1275 Eagle Cassette Speed 12s Technology cassete XG
Chain	KMC X12	SRAM SX Eagle
Frameset
Frame	Orbea Occam Hydro High Polished 2020 Triple Butted 140mm travel 29"-Boost 12x148	HPC, High Performance Composite
Front suspension	Marzocchi Bomber Z2	Fox 34 Rhythm
Rear suspension	Fox Float DPS Performance EVOL	Fox Float DPS
Wheels
Rims	Orbea OC1 29c Tubeless Ready	Fulcrum Red 55 EM
Tires	Maxxis Rekon 2.40" FB 60 TPI Dual Exo TR	Schwalbe Nobby Nic, Addix Speedgrip, Kevlar, Tubeless Easy, 2.35

Features
Hydraulic disc brakes
Tubeless ready
Boost 148
Dropper seatpost
Boost 110

Geometry
Size
Seat tube length	381,0	520,0
Seat tube angle	77,0º	75,3º
Top tube length	563,0	644,3
Head tube length	95,0	133,0
Head tube angle	66,0º	67,0º
Rake	44,0	48,0
Trail	119,0	107,0
Wheelbase	1163,0	1222,0
Chainstay length	438,0	439,5
Bottom bracket drop	35,0	40,0
Stack height	602,0	638,0
Reach	423,0	484,0
Standover height	708,0	814,4
Bottom bracket height	336,0	334,0
Front center	727,0	785,0
