Groupset
SRAM NX Eagle
Wheel size
29"
Suspension type
Full suspension
Front travel
150mm
Rear travel
135mm
About the Fezzari Delano Peak Comp Eagle GA Link High 2022
The Fezzari Delano Peak Comp Eagle GA Link High 2022 is a Full suspension Trail Mountain Bike. Equipped with a SRAM NX Eagle drivetrain. Its features include dropper seatpost, boost 110 , and boost 148.
Features
Dropper seatpost
More info
Dropper seatpost
Boost 110
More info
Boost 110
Boost 148
More info
Boost 148
Hydraulic disc brakes
More info
Hydraulic disc brakes
Tubeless ready
More info
Tubeless ready
Specifications
|
Pedals
|
Available Separately
|
|---|
|
Steam
|
Fezzari FRD Charger35, CNC 6061-T6 Alloy, 35mm clamp
|
|---|---|
|
Saddle
|
Selle Italia Model X
|
|
Headset
|
Cane Creek 40, ZS44/28.6 ZS56/40
|
|
Seatpost
|
X-Fusion Manic Internal Dropper with Remote (Travel adjusted with 23-point customs fit after checkout)
|
|
Handlebar
|
Fezzari FRD Charger35, alloy, 35mm clamp, 800mm wide, 15mm riser, 9 degree backsweep,5 degree upsweep
|
|
Brake lever
|
SRAM G2 R
|
|
Brakes
|
SRAM G2 R
Hydraulic
393 g
|
|
|
|
|
Crankset
|
SRAM NX Eagle Dub, 3mm offset for 148 Boost chainline
|
|---|---|
|
Shifter
|
SRAM NX Eagle, 12 speed
|
|
Bottom bracket
|
SRAM Dub 73 mm English Thread
|
|
Chain
|
SRAM NX Eagle
252 g
|
|
|
|
|
Rear derailleur
|
SRAM NX Eagle
12s
339 g
|
|
|
|
|
Cassette
|
SRAM PG-1230 Eagle
12s
615 g
|
|
|
|
|
Frame
|
Fezzari ST135 CleanCast Carbon TetraLink Full Suspension, 135mm travel. Internal Future-Proof cable routing on top of Downtube. CleanCatch rattle-proof cable guides. SRAM Universal Derailleur Hanger. 2 Flush-mount bottle cages (M,L,XL)
|
|---|---|
|
Rear suspension
|
DVO Topaz T3
|
|
Front suspension
|
DVO Diamond D1
|
|
Rims
|
WTB STP i29 TCS 29", 32 hole, disc specific, tubeless ready
|
|---|---|
|
Tires
|
Front: Maxxis Minion DHF 29x2.5" 60 TPI, EXO, Tubeless Ready, Rear: Maxxis Aggressor 29x2.5" 60 TPI, EXO, Tubeless Ready
|
|
Spokes
|
15G Stainless black, brass nipples
|
|
Rear hub
|
Front: Bear Pawls MTB Disc, 15x110 Rear: Bear Pawls MTB Disc, 12x148 Microspline Freehub
|
|
Front hub
|
Front: Bear Pawls MTB Disc, 15x110 Rear: Bear Pawls MTB Disc, 12x148 Microspline Freehub
|
Geometry
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
|
a
Seat tube length
|
400,0
|
420,0
|
445,0
|
460,0
|
|
b
Seat tube angle
|
77,9º
|
77,9º
|
77,9º
|
77,9º
|
|
c
Top tube length
|
560,0
|
593,0
|
612,9
|
637,0
|
|
d
Head tube length
|
95,0
|
95,0
|
115,0
|
130,0
|
|
e
Head tube angle
|
65,4º
|
65,4º
|
65,4º
|
65,4º
|
|
f
Rake
|
44,0
|
44,0
|
44,0
|
44,0
|
|
g
Trail
|
130,0
|
129,0
|
129,0
|
129,0
|
|
h
Wheelbase
|
1175,478
|
1208,4
|
1232,7
|
1260,1
|
|
i
Chainstay length
|
433,0
|
433,0
|
433,0
|
433,0
|
|
j
Bottom bracket drop
|
22,8
|
22,8
|
22,8
|
22,8
|
|
k
Stack height
|
603,5
|
603,5
|
621,8
|
635,5
|
|
l
Reach
|
435,6
|
467,4
|
483,3
|
504,8
|
|
m
Standover height
|
734,0
|
741,0
|
751,0
|
763,0
|
|
x
Bottom bracket height
|
343,0
|
343,0
|
343,0
|
343,0
|
|
y
Front center
|
743,0
|
776,0
|
801,0
|
828,0
|
