Fezzari Hidden Peak Carbon NX1 2018

MTB Trail
Groupset
SRAM NX
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Front travel
120mm
Rear travel
120mm
Fezzari Hidden Peak Carbon NX1 2018

About the Fezzari Hidden Peak Carbon NX1 2018

The Fezzari Hidden Peak Carbon NX1 2018 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a SRAM NX drivetrain of 11 gears (1x11). Its features include boost 110 , e-thru axle, and hydraulic disc brakes.

Features

The Fezzari Hidden Peak Carbon NX1 2018 has 5 features listed below.
cubo-dianteiro-boost
Boost 110 More info
eixo-e-thru
E-THRU AXLE More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
tubeless-ready
Tubeless ready More info

Specifications

Acessories
Grip
Fezzari lock-on MTB
Components
Steam
Fezzari 3D forged alloy, 31.8mm clamp, 7° rise, 4-bolt bar clamp, customized lengths
Saddle
WTB Volt Race
Headset
FSA No.57, integrated
Seatpost
Fezzari Racing Design XrT Dual Bolt UD Carbon
Handlebar
Fezzari Racing Design Alloy, 31.8mm clamp, 0mm rise, 740mm width (customized widths available)
Brake lever
SRAM Level
Brakes
SRAM Level Hydraulic 430 g
Application
MTB
Blade material
Aluminum - Stamped
Bracket disk brake
Direct mount DIR, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(170mm Rear rotor) 30I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (10mm spacer) 10S, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (30mm bracket) 30P, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Black
Model
DB-LVL-A1
Name
Level
Orientation
L/F, L/R, R/F, R/R
Pad type disc
Steel-backed organic
Weight based on
Direct Mount, 800mm hose, 160mm G2 Rotor (TARGET)
Weight
430
Drivetrain
Crankset
Race Face Aeffect
Shifter
SRAM NX trigger, 11-speed
Bottom bracket
Race Face BB92
Rear derailleur
SRAM NX 11s 322 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
42
Model
RD-NX-1-A1
Name
NX 1x11 X-HORIZON™ Rear Derailleur
Pulley bearings material
Steel
Speed
11s
Weight
322
Cassette
SRAM XG-1150 11s
Cog finish cassete
Black
Cog sizes
10-42t:10,12,14,16,18,21,24,28,32,36,42
Gearing
10-42t
Model
CS-XG-1150-A1
Name
XG-1150 FULL PIN Cassette
Speed
11s
Technology cassete
XG
Chain
KMC X11
Frameset
Frame
Carbon Fiber
Front suspension
RockShox Reba RL Solo Air 1620 g
Color
Diffusion Black, Gloss Black, Gloss White
Damper type
n/a, RL
fork offset
40mm (26"), 42mm (27.5"), 46mm (29"), 51mm (29")
Maximum rotor size
200mm
Minimum rotor size
160mm
Model
FS-REBA-RL-A6
Name
Reba RL
Spring
Solo Air
Travel (mm)
100mm, 120mm, 80mm
Upper tube type
32mm straight wall aluminum
Weight based on
15x100 Maxle Stealth, Tapered steerer, 120mm travel
Weight
1620
Wheel size
26", 27.5", 27.5" B, 29", 29" B/27.5"+
Rear suspension
RockShox Monarch RT
Body eyelet
No Bushing, Standard
Compression tune
H, L, L1, L3, M
Eye to eye stroke
152x31, 165x38, 184x44, 190x51, 200x51, 200x57, 216x63
Lockout force
320, 380
Model
RS-MNR-RT-D3
Name
Monarch RT
Rebound tune
H, L, M
Shaft eyelet
No Bushing, Standard
Wheels
Rims
WTB STP i25 TCS, 32 hole, disc specific, tubeless ready
Tires
Maxxis Ardent Race, 120 tpi, 3C Maxx Speed, tubeless ready, 29" x 2.2"
Spokes
15G, black stainless
Rear hub
Front: Formula Disc, 110x15mm thru axle, 32 hole, 6 bolt, Rear: Formula Disc, 142x12mm thru axle, 32 hole, 6 bolt
Front hub
Front: Formula Disc, 110x15mm thru axle, 32 hole, 6 bolt, Rear: Formula Disc, 142x12mm thru axle, 32 hole, 6 bolt

Geometry

Size SM MD LG XL
a
Seat tube length
-
-
-
-
b
Seat tube angle
73,5º
73,5º
73,5º
73,5º
c
Top tube length
586,0
603,0
622,0
641,0
d
Head tube length
108,0
118,0
128,0
138,0
e
Head tube angle
69,9º
69,9º
69,9º
69,9º
f
Rake
-
-
-
-
g
Trail
-
-
-
-
h
Wheelbase
1117,1
1133,6
1153,4
1173,0
i
Chainstay length
455,0
455,0
455,0
455,0
j
Bottom bracket drop
30,0
30,0
30,0
30,0
k
Stack height
-
-
-
-
l
Reach
591,7
601,3
610,5
619,9
m
Standover height
-
-
-
-
x
Bottom bracket height
344,0
344,0
344,0
344,0
y
Front center
664,0
680,0
700,0
720,0
