Fezzari Wire Peak Comp 29 2021

E-Bike
MTB Trail
Groupset
Shimano Deore
Wheel size
29"
Suspension type
Full suspension
Front travel
140mm
Rear travel
140mm
Fezzari Wire Peak Comp 29 2021

About the Fezzari Wire Peak Comp 29 2021

The Fezzari Wire Peak Comp 29 2021 is a Full suspension Trail Mountain Bike. Equipped with a Shimano Deore drivetrain of 10 gears (1x10). Its features include boost 110 , boost 148, and hydraulic disc brakes.

Features

The Fezzari Wire Peak Comp 29 2021 has 4 features listed below.
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info
tubeless-ready
Tubeless ready More info

Specifications

Acessories
Pedals
Available Separately
Components
Steam
Fezzari FRD Charger35, alloy, 35mm clamp, sizes vary depending on custom fit
Saddle
WTB Volt Comp
Headset
FSA Orbit 1.5 ZS No.57E, internal sealed cartridge bearing, tapered
Seatpost
Fezzari Alloy, Dual Bolt Clamp, 31.6 x 350-400 (based on custom setup), Dropper seatpost available after adding bike to cart
Handlebar
Fezzari FRD Charger35, alloy, 35mm clamp, 780mm wide, 1'mm riser, 9 degree bend
Brake lever
SRAM Level T
Brakes
SRAM Level T Hydraulic 410 g
Application
MTB
Blade material
Aluminum - Stamped
Bracket disk brake
Direct mount DIR, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(170mm Rear rotor) 30I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (10mm spacer) 10S, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (30mm bracket) 30P, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Gloss Black
Model
DB-LVL-T-A1
Name
Level T
Orientation
Front, L/F, L/R, R/F, R/R, Rear
Pad type disc
Steel-backed metal sintered, Steel-backed organic
Weight based on
Direct Mount, 800mm hose, 160mm CL Rotor (TARGET)
Weight
410
Drivetrain
Crankset
Shimano E8000, 165mm
Motor
Front: Bear Pawls Sealed Bearing Disc Boost 110x15mm, Rear: Bear Pawls BEB E-bike specific, 6 Sealed Bearings, Steel Axle, 6-bolts Disc, Boost 148x12mm, Shimano/SRAM Driver
Shifter
Shimano Deore M6000, 1x10, 10-speed, RAPIDFIRE Plus, Vivid index shifting, instant-release, 2-way release
Bottom bracket
Shimano E7000 Bike motor system
Rear derailleur
Shimano Deore RD-M6000-GS GS 10s
B axle hollow
B axle material
Stainless steel
Bracket finish
Painted
Bracket material
Steel
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG-X 10-speed
Lower pulley max
42T
Lower pulley min
42T
Model
RD-M6000-GS
P axle finish
Painted
P axle material
Steel
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
11T
Pulley cage
GS
Speeds
10
Upper pulley max
11T
Upper pulley min
11T
Total capacity
41T
Chain
KMC 10v
Cassette
Shimano Deore CS-HG500-10
Frameset
Frame
Fezzari Racing Design AT5529-E, 140mm travel TetraLink™ suspension, CleanCatch™ rattle-proof cable guides, Frame Defense Tech derailleur hanger, Internal battery compartment with removable battery, sealed cartridge bearings
Front suspension
RockShox Recon RL Solo Air
Color
Diffusion Black, Gloss Black, Gloss White
fork offset
42mm (27.5"), 46mm (29"), 51mm (29")
Max tire width (mm)
62, 81
Maximum rotor size
220mm
Minimum rotor size
160mm
Model
FS-RCN-RL-A1
Name
Recon RL
Spring
Solo Air
Travel (mm)
100mm, 120mm, 130mm, 140mm, 150mm, 80mm
Upper tube type
32mm straight wall steel
Wheel size
27.5", 29"
Rear suspension
X-Fusion O2 Pro RL
Wheels
Rims
WTB ST i35 2.0, Tubeless ready, 27.5+ diameter designed for 2.8 wide tires
Tires
Front: Maxxis Minion DHF 27.5x2.8 3C Exo Maxx Terra Tubeless Ready 120 TPI, Rear: Maxxis Rekon 27.5x2.8 3C Exo Maxx Terra Tubeless Ready 120 TPI
Spokes
1.8mm (15g) black stainless, brass nipples
Rear hub
Front: Bear Pawls Sealed Bearing Disc Boost 110x15mm, Rear: Bear Pawls BEB E-bike specific, 6 Sealed Bearings, Steel Axle, 6-bolts Disc, Boost 148x12mm, Shimano/SRAM Driver
Front hub
Front: Bear Pawls Sealed Bearing Disc Boost 110x15mm, Rear: Bear Pawls BEB E-bike specific, 6 Sealed Bearings, Steel Axle, 6-bolts Disc, Boost 148x12mm, Shimano/SRAM Driver

Geometry

Size SM MD LG XL
a
Seat tube length
400,0
420,0
457,0
460,0
b
Seat tube angle
75,5º
75,5º
75,5º
75,5º
c
Top tube length
563,0
589,0
618,0
647,0
d
Head tube length
105,0
105,0
110,0
120,0
e
Head tube angle
65,5º
65,5º
65,5º
65,5º
f
Rake
44,0
44,0
44,0
44,0
g
Trail
106,0
132,0
132,0
134,0
h
Wheelbase
1167,8
1169,0
1198,0
1229,0
i
Chainstay length
434,0
434,0
434,0
434,0
j
Bottom bracket drop
30,0
30,0
30,0
30,0
k
Stack height
625,0
629,6
634,2
648,3
l
Reach
399,0
424,0
451,7
478,0
m
Standover height
785,0
787,0
787,0
792,0
x
Bottom bracket height
346,0
346,0
346,0
346,0
y
Front center
735,0
737,0
766,0
797,0
