BikeWise

Focus JAM Elite 29 2018

MTB Trail
Groupset
Shimano Deore
Frame material
Alloy
Wheel size
29"
Suspension type
Full suspension
Front travel
130mm
Focus JAM Elite 29 2018

About the Focus JAM Elite 29 2018

The Focus JAM Elite 29 2018 is a Full suspension Trail Mountain Bike with a alloy frame. Equipped with a Shimano Deore drivetrain. Its features include internal routing, dropper seatpost, and boost 110 .

Features

The Focus JAM Elite 29 2018 has 5 features listed below.
cabeamento-interno
Internal routing More info
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Components
Steam
BBB, aluminium, 31.8mm
Seatpost
KindShock E30i, 31,6mm, internal
Handlebar
BBB, aluminium, flatbar, 760mm, rise: 0mm, backsweep: 9degree
Brakes
Shimano Deore BR-M6000 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH90-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Series Black
Secondary color
Series Silver *
color.3
Black (SHIMANO logo) ***
Hose joint
Straight
ICE TECHNOLOGIES pad compatible caliper
J-Kit spec for OEM
Model
BR-M6000
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad option
G04S Metal **
Pad standard
G02S Resin,
G03S Resin
Pad standard
J02A Resin **
J03A Resin **
Pad mount
Split pin (stainless steel)
Piston
2
Piston material
Resin
Recommended brake lever
BL-M6100
BL-MT501
BL-T6000
Recommended disc brake rotor
SM-RT54****
SM-RT56****
SM-RT64
SM-RT66
Drivetrain
Shifter
Shimano Deore
Rear derailleur
Shimano Deore RD-M6000-GS GS 10s
B axle hollow
B axle material
Stainless steel
Bracket finish
Painted
Bracket material
Steel
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG-X 10-speed
Lower pulley max
42T
Lower pulley min
42T
Model
RD-M6000-GS
P axle finish
Painted
P axle material
Steel
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
11T
Pulley cage
GS
Speeds
10
Upper pulley max
11T
Upper pulley min
11T
Total capacity
41T
Frameset
Frame
6066 aluminium, BSA BB, 148x12 through axle, internal cable routing, Post Mount 180 mm
Front suspension
Fox 34 Rhythm
Rear suspension
Fox Float Performance
Wheels
Rims
RaceFace AR30, 622-30, Shimano Deore CL, 148x12 mm / 110x15 mm
Tires
Minion DHF 2.3 3C/TR/ EXO, foldable

Geometry

Size SM MD LG XL
a
Seat tube length
420,0
440,0
480,0
510,0
b
Seat tube angle
74,5º
74,5º
74,5º
74,5º
c
Top tube length
578,0
598,0
627,0
655,0
d
Head tube length
110,0
110,0
135,0
155,0
e
Head tube angle
67,8º
67,8º
67,8º
67,8º
f
Rake
51,0
51,0
51,0
51,0
g
Trail
98,0
98,0
98,0
98,0
h
Wheelbase
1151,0
1171,0
1,2e3
1228,0
i
Chainstay length
443,0
443,0
443,0
443,0
j
Bottom bracket drop
33,0
33,0
33,0
33,0
k
Stack height
621,0
621,0
644,0
663,0
l
Reach
418,0
438,0
458,0
478,0
m
Standover height
-
-
-
-
x
Bottom bracket height
341,0
341,0
341,0
341,0
y
Front center
710,0
730,0
759,0
787,0
