Fuji Tahoe 29 1.3 2020

MTB Cross Country
Groupset
Shimano XT
Frame material
Alloy
Wheel size
29"
Suspension type
Hardtail
Front travel
100mm
Fuji Tahoe 29 1.3 2020

About the Fuji Tahoe 29 1.3 2020

The Fuji Tahoe 29 1.3 2020 is a Hardtail Cross Country Mountain Bike with a alloy frame. Equipped with a Shimano XT drivetrain of 22 gears (2x11). Its features include boost 110 , boost 148, and hydraulic disc brakes.

Features

The Fuji Tahoe 29 1.3 2020 has 6 features listed below.
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
trava-remota-guidao
Remote lockout More info
tubeless-ready
Tubeless ready More info

Specifications

Acessories
Grip
Fuji Performance Grip Lock On
Components
Steam
Race Face Ride, 6° rise
Saddle
WTB Silverado Comp
Headset
FSA 1 1/8" - 1.5", sealed bearings
Seatpost
Race Face Ride XC, 30.9MM
Handlebar
Race Face Ride Flat Bar, 710MM
Brake lever
Shimano MT501, 180/160MM rotors
Brakes
Shimano Deore BR-MT501
Drivetrain
Crankset
Shimano MT600, 36/26T
Shifter
Shimano SLX Ispec, Rapid Fire, 2 x 11-speed
Bottom bracket
Shimano, threaded
Front derailleur
Shimano SLX
Rear derailleur
Shimano Deore XT RD-M8000-GS 271 g GS 11s
Average weight (g)
271
B axle hollow
B axle material
Stainless steel
Bracket finish
Painted
Bracket material
Aluminum
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG-X 11-speed
Lower pulley max
42T(2x11-speed),
46T(1x11-speed)
Lower pulley min
40T
Model
RD-M8000-GS
P axle material
Steel
pulley.guide_pulley_bearing
Sealed bearing
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
11T
pulley.tension_pulley_bearing
Sealed bearing
Pulley cage
GS
Speeds
11
Upper pulley max
11T
Upper pulley min
11T
Total capacity
39T
Cassette
Shimano SLX CS-M7000-11 HG
Aluminum gear pieces
1 (11-40T)
1 (11-42T)
2 (11-46T)
Aluminum spider arm finish
Anodized
Aluminum spider arm pieces
1
Combination names
11-40T
11-42T
11-46T
Compatible chain
HG 11-speed, LG
Lock ring finish
Plated
Lock ring material
Steel
Model
CS-M7000-11
Steel gear finish
Shot-Ni
Steel gear pieces
10 (11-40T)
10 (11-42T)
9 (11-46T)
Type
HG
Weights
11-40T: 450g
11-42T: 476g
11-46T: 482g
Chain
KMC X11
Frameset
Frame
Fuji A6-SL super-butted alloy, smooth welds, Boost 148x12MM
Front suspension
RockShox Judy Gold RL Solo Air
Color
Diffusion Black, Gloss Black
Damper type
Motion Control
fork offset
42mm (27.5"), 51mm (27.5"), 51mm (29")
Max tire width (mm)
81
Maximum rotor size
220mm
Minimum rotor size
160mm
Model
FS-JDYG-RL-A2
Name
Judy Gold RL
Spring
Solo Air
Travel (mm)
100mm, 120mm, 80mm
Upper tube type
30mm straight wall aluminum
Wheel size
27.5", 29"
Wheels
Rims
WTB ST i25 TCS 29" 32H rims, Shimano MT400 front hub, MT400 rear hub, stainless black spokes
Tires
Maxxis Ikon, 29" x 2.2", 60tpi, EXO, Tubeless Ready, folding

Geometry

Size SM MD LG XL XXL
a
Seat tube length
430,0
430,0
465,0
513,0
543,0
b
Seat tube angle
73,0º
73,0º
73,0º
73,0º
73,0º
c
Top tube length
576,0
601,0
626,0
646,0
666,0
d
Head tube length
100,0
100,0
110,0
115,0
120,0
e
Head tube angle
69,0º
69,0º
69,0º
69,0º
69,0º
f
Rake
51,0
51,0
51,0
51,0
51,0
g
Trail
89,0
89,0
89,0
89,0
89,0
h
Wheelbase
1086,9
1111,8
1137,9
1158,0
1178,4
i
Chainstay length
431,0
431,0
431,0
431,0
431,0
j
Bottom bracket drop
60,0
60,0
60,0
60,0
60,0
k
Stack height
615,6
615,6
624,9
629,6
634,3
l
Reach
386,6
411,6
433,7
452,3
470,9
m
Standover height
699,5
698,0
696,3
717,6
729,4
x
Bottom bracket height
314,0
314,0
314,0
314,0
314,0
y
Front center
663,0
688,0
714,0
734,0
754,0
