Ghost KATO Advanced 27.5 2021

MTB Cross Country
Groupset
Shimano Deore
Frame material
Alloy
Wheel size
27,5"
Suspension type
Hardtail
Weight
14,7 kg
Front travel
100mm
Ghost KATO Advanced 27.5 2021

About the Ghost KATO Advanced 27.5 2021

The Ghost KATO Advanced 27.5 2021 is a Hardtail Cross Country Mountain Bike with a alloy frame. Equipped with a Shimano Deore drivetrain of 20 gears (2x10). Its features include hydraulic disc brakes. The bike weighs approximately 14,7 kg.

Features

The Ghost KATO Advanced 27.5 2021 has 1 features listed below.
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Components
Steam
GHOST 31.8 60mm
Saddle
DDK D2373A
Headset
14106
Seatpost
GHOST SP-DC1 31.6 mm
Handlebar
GHOST Low Rizer light 720 mm Rise 15 mm 31.8 mm
Brakes
Shimano BR-MT200 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH59-JK-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Black
Hose joint
Straight
J-Kit spec for OEM
Model
BR-MT200
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad standard
B03S Resin
Pad mount
Split pin
Piston
2
Piston material
Resin
Recommended brake lever
BL-MT201
BL-MT200
Recommended disc brake rotor
SM-RT10*
SM-RT26*
Drivetrain
Crankset
Shimano Deore FC-M4100 36-26
Front derailleur
Shimano Deore FD-M4100-M
Rear derailleur
Shimano Deore RD-M5120 SGS 11/10s
B axle hollow
B axle material
Stainless steel
Bracket finish
Painted
Bracket material
Steel
Bracket body finish
Painted
Bracket body material
Aluminum
Lower pulley max
46T (1x11/1x10-speed)
42T (2x11/2x10-speed)
Lower pulley min
42T
Model
RD-M5120-SGS
P axle material
Steel
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
11T
Pulley cage
SGS
Speeds
11/10
Upper pulley max
11T
Upper pulley min
11T
Total capacity
41T
Cassette
Shimano Deore CS-M4100-10 HG
Combination names
11-42T
11-46T
Compatible chain
HG-X 10-speed
Lock ring finish
Plated
Lock ring material
Steel
Model
CS-M4100-10
Steel gear finish
Plated
Steel gear pieces
10
Type
HG
Frameset
Frame
KATO AL
Front suspension
SR Suntour XCR
Wheels
Rims
Rodi Excalibur XC 19
Tires
Mitas Ocelot 27x2.10
Rear hub
Shimano FH-TX505 QR 135 mm
Front hub
Shimano HB-TX505 QR 100 mm

Geometry

Size XS SM MD
a
Seat tube length
680,0
680,0
680,0
b
Seat tube angle
-
-
-
c
Top tube length
536,0
561,0
581,0
d
Head tube length
105,0
115,0
125,0
e
Head tube angle
-
-
-
f
Rake
250,0
-334,0
-714,0
g
Trail
-35,0
-3940,0
6128,0
h
Wheelbase
421,0
421,0
421,0
i
Chainstay length
-
-
-
j
Bottom bracket drop
73,5
73,5
73,5
k
Stack height
579,0
589,0
598,0
l
Reach
362,0
384,0
402,0
m
Standover height
351,0
391,0
431,0
x
Bottom bracket height
282,0
282,0
282,0
y
Front center
635,0
661,0
682,0
