Giant Trance Advanced 2 2018

MTB Cross Country
Groupset
Shimano SLX
Frame material
Carbon
Wheel size
27,5"
Suspension type
Rigid
Giant Trance Advanced 2 2018

About the Giant Trance Advanced 2 2018

The Giant Trance Advanced 2 2018 is a Rigid Cross Country Mountain Bike with a carbon frame. Equipped with a Shimano SLX drivetrain of 11 gears (1x11).

Specifications

Components
Seatpost
Giant Contact
Brake lever
Shimano SLX BL-M7000
Brakes
Shimano SLX BR-M7000
Steam
Giant Contact
Saddle
Giant Contact
Handlebar
Giant Contact
Drivetrain
Crankset
Shimano SLX FC-M7000-11-1 11s
Chain line (mm)
50
Chainring combination
34T, 32T, 30T (SM-CRM70)
Primary color
Series color
Compatible bottom bracket type (outboard)
Compatible chain
HG-X11
Crank arm finish
Anodized
Crank arm material
Aluminum
Crank arm length 170 mm
Crank arm length 175 mm
Crank axle finish
Plated
Crank axle material
Steel
Crank fixing bolt included
Hollowtech II
Model
FC-M7000-11-1
Pitch circle diameter
96
Q factor (mm)
176
Speeds
11
Recommended bottom bracket (press fit)
BB-MT800-PA
Recommended bottom bracket (threaded normal)
BB-MT800
Spider arm finish
Painted
Spider arm material
Aluminum
Spider gear arms
4
Threaded bottom bracket shell width 68 mm
Threaded bottom bracket shell width 73 mm
Cassette
Shimano SLX CS-M7000-11 HG
Aluminum gear pieces
1 (11-40T)
1 (11-42T)
2 (11-46T)
Aluminum spider arm finish
Anodized
Aluminum spider arm pieces
1
Combination names
11-40T
11-42T
11-46T
Compatible chain
HG 11-speed, LG
Lock ring finish
Plated
Lock ring material
Steel
Model
CS-M7000-11
Steel gear finish
Shot-Ni
Steel gear pieces
10 (11-40T)
10 (11-42T)
9 (11-46T)
Type
HG
Weights
11-40T: 450g
11-42T: 476g
11-46T: 482g
Rear derailleur
Shimano SLX RD-M7000-10-SGS 313 g SGS 10s
Average weight (g)
313
B axle hollow
B axle material
Stainless steel
Bracket finish
Painted
Bracket material
Steel
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG-X 10-speed
Lower pulley max
36T
Lower pulley min
32T
Model
RD-M7000-10-SGS
P axle material
Steel
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
11T
Pulley cage
SGS
Speeds
10
Upper pulley max
11T
Upper pulley min
11T
Total capacity
43T
Shifter
Shimano SLX SL-M7000 135 ( /pc) g RAPIDFIRE PLUS
Average weight (g)
135 ( /pc)
Base cover material
GFRP
Clamp bolt material
Stainless steel
Primary color
Series color
Compatible rear derailleur type
MTB 11-speed
Compatible with I spec
Main lever body material
GFRP & Steel
Max multiple shifts main lever rear
3
Model
SL-M7000-11-R
Mount type
Clamp band
Optical gear display
With (removable)
Speeds
11
Release function
2-WAY RELEASE
release_lever_body.material
GFRP & Steel
Shifter type
RAPIDFIRE PLUS
Shifting lever bracket finish
Painted
Shifting lever bracket material
Aluminum
Shifting lever cable finish
OPTISLICK
Shifting lever cable material
Stainless steel
Shifting lever cable adjust
Chain
KMC X11
Frameset
Frame
Giant Advanced-Grade Composite Carbon
Front suspension
RockShox Revelation RC DebonAir
Color
Diffusion Black, Gloss Black
Damper type
Motion Control
fork offset
37mm (27.5"), 42mm (29"), 46mm (27.5"), 51mm (29")
Max tire width (mm)
81
Maximum rotor size
220mm
Minimum rotor size
180mm
Model
FS-RVL-RC-A2
Name
Revelation RC
Spring
DebonAir
Travel (mm)
120mm, 130mm, 140mm, 150mm, 160mm
Upper tube type
35mm tapered wall aluminum
Wheel size
27.5", 29"
Rear suspension
RockShox Deluxe RT
Body eyelet
Bearing, No Bushing, Standard
Compression tune
L, L1, LC, M
Eye to eye stroke
145x35(TR), 165x37.5(TR), 165x40(TR), 165x42.5(TR), 165x45(TR), 170x35, 185x47.5(TR), 185x50(TR), 185x52.5(TR), 185x55(TR), 190x37.5, 190x40, 190x42.5, 190x45, 205x57.5(TR), 205x60(TR), 205x62.5(TR), 205x65(TR), 210x47.5, 210x50, 210x52.5, 210x55, 230x57.5, 230x60, 230x62.5, 230x65
Lockout force
320
Model
RS-DLX-RT-B1
Name
Deluxe RT
Rebound tune
H, L, M
Shaft eyelet
Bearing, No Bushing, Standard, Trunnion
Wheels
Rims
Giant TRX 1
Spokes
Giant TRX 1
Front hub
Giant TRX 1
Rear hub
Giant TRX 1
Tires
Maxxis High Roller II

Geometry

Size S M L XL
a
Seat tube length
380,0
431,0
482,0
507,0
b
Seat tube angle
73,5º
73,5º
73,5º
73,5º
c
Top tube length
580,0
610,0
630,0
655,0
d
Head tube length
100,0
105,0
130,0
145,0
e
Head tube angle
67,0º
67,0º
67,0º
67,0º
f
Rake
-
-
-
-
g
Trail
-
-
-
-
h
Wheelbase
1129,0
1160,0
1183,0
1209,0
i
Chainstay length
435,0
435,0
435,0
435,0
j
Bottom bracket drop
15,0
15,0
15,0
15,0
k
Stack height
587,0
591,0
614,0
628,0
l
Reach
406,0
435,0
448,0
469,0
m
Standover height
701,0
723,0
768,0
788,0
x
Bottom bracket height
-
-
-
-
y
Front center
-
-
-
-
