GT Sensor Carbon Elite 2019

MTB Trail
Groupset
SRAM NX Eagle
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Front travel
130mm
Rear travel
130mm
GT Sensor Carbon Elite 2019

About the GT Sensor Carbon Elite 2019

The GT Sensor Carbon Elite 2019 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a SRAM NX Eagle drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148.

Features

The GT Sensor Carbon Elite 2019 has 6 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
tubeless-ready
Tubeless ready More info

Specifications

Acessories
Grip
New GT Statement Single Lock-on Grips
Pedals
None included
Components
Steam
All Terra, 1-1/8" Threadless, 3D Forged, 31.8mm, 7° Rise, 60mm
Saddle
WTB Silverado Sport
Headset
FSA Orbit C-40-ACB
Seatpost
X-Fusion Dropper Post w/ 1x Lever, 31.6, 125mm (S-M) 150mm (L-XL)
Handlebar
All Terra Alloy Riser, Double-butted 6061, 15mm rise, 780mm
Brake lever
SRAM Level TL hydro disc
Brakes
SRAM Level TL Hydraulic 370 g
Application
MTB
Blade material
Aluminum - Forged
Bracket disk brake
Direct mount DIR, Flat Mount 20mm offset, Flat Mount no offset, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(170mm Rear rotor) 30I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (10mm spacer) 10S, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (30mm bracket) 30P, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Diffusion Black Anodized, Gloss Black
Model
DB-LVL-TL-A1
Name
Level TL
Orientation
Front, Rear
Pad type disc
Steel-backed metal sintered, Steel-backed organic
Weight based on
Direct Mount, 800mm hose, 160mm CL Rotor (TARGET)
Weight
370
Drivetrain
Chain
SRAM Eagle 12spd
Crankset
Truvativ Descendant 6K, Dub, 32T
Shifter
SRAM NX Eagle
Bottom bracket
SRAM Dub, 73mm BSA
Rear derailleur
SRAM NX Eagle 12s 339 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
50
Model
RD-NX-1-B1
Name
NX Eagle Rear Derailleur
Pulley bearings material
Steel
Speed
12s
Weight
339
Cassette
SRAM PG-1230 Eagle 12s 615 g
Cog finish cassete
Black
Cog sizes
11-50t:11,13,15,17,19,22,25,28,32,36,42,50
Gearing
11-50t
Model
CS-PG-1230-A1
Name
PG-1230 Eagle Cassette
Speed
12s
Technology cassete
PG
Weight
615
Frameset
Frame
All New Sensor Carbon, 130mm rear wheel travel, carbon front/alloy rear frame, Boost 148 rear spacing, ISCG05 mounts, sealed bearing LockR pivots, Metric Trunnion shock mounts, coil shock compatible
Rear suspension
RockShox Deluxe R
Body eyelet
Bearing, No Bushing, Standard
Compression tune
L, L3, M
Eye to eye stroke
145x35(TR), 165x37.5(TR), 165x40(TR), 165x42.5(TR), 165x45(TR), 170x35, 185x47.5(TR), 185x50(TR), 185x52.5(TR), 185x55(TR), 190x37.5, 190x40, 190x42.5, 190x45, 205x57.5(TR), 205x60(TR), 205x62.5(TR), 205x65(TR), 210x47.5, 210x50, 210x52.5, 210x55, 230x57.5, 230x60, 230x62.5, 230x65
Model
RS-DLX-R-B1
Name
Deluxe R
Rebound tune
L, M
Shaft eyelet
Bearing, Standard, Trunnion
Front suspension
RockShox Sektor RL DebonAir
Color
Diffusion Black, Gloss Black
Damper type
Motion Control
fork offset
37mm (27.5"), 42mm (29"), 46mm (27.5"), 51mm (29")
Max tire width (mm)
81
Maximum rotor size
220mm
Minimum rotor size
160mm
Model
FS-SKTR-RL-C1
Name
Sektor RL
Spring
DebonAir
Travel (mm)
100mm, 120mm, 130mm, 140mm, 150mm, 80mm
Upper tube type
32mm straight wall aluminum
Wheel size
27.5", 29"
Wheels
Rims
WTB ST i29 TCS 2.0, 32h, tubeless ready
Tires
Schwalbe Nobby Nic Performance 29 x 2.35", tubeless ready
Spokes
Stainless Steel, 14g
Rear hub
All Terra Alloy Disc, Boost front or rear
Front hub
All Terra Alloy Disc 15x110 front, 12x148 rear

Geometry

Size XS High XS Low SM High SM Low MD High MD Low LG High LG Low XL High XL Low
a
Seat tube length
392,0
392,0
400,0
400,0
430,0
430,0
480,0
480,0
520,0
520,0
b
Seat tube angle
76,0º
76,0º
76,0º
76,0º
76,0º
76,0º
76,0º
76,0º
76,0º
76,0º
c
Top tube length
534,0
534,0
559,0
559,0
585,0
585,0
612,0
612,0
639,0
639,0
d
Head tube length
102,0
102,0
102,0
102,0
110,0
110,0
118,0
118,0
126,0
126,0
e
Head tube angle
65,5º
65,5º
65,5º
65,5º
65,5º
65,5º
65,5º
65,5º
65,5º
65,5º
f
Rake
-
-
-
-
-
-
-
-
-
-
g
Trail
-
-
-
-
-
-
-
-
-
-
h
Wheelbase
1133,0
1133,0
1158,0
1158,0
1186,0
1186,0
1214,0
1214,0
1243,0
1243,0
i
Chainstay length
427,0
427,0
427,0
427,0
427,0
427,0
427,0
427,0
427,0
427,0
j
Bottom bracket drop
25,0
25,0
25,0
25,0
25,0
25,0
25,0
25,0
25,0
25,0
k
Stack height
579,0
579,0
579,0
579,0
587,0
587,0
594,0
594,0
601,0
601,0
l
Reach
387,0
387,0
412,0
412,0
437,0
437,0
462,0
462,0
487,0
487,0
m
Standover height
734,5
734,5
742,0
742,0
752,0
752,0
762,0
762,0
797,0
797,0
x
Bottom bracket height
349,0
349,0
349,0
349,0
349,0
349,0
349,0
349,0
349,0
349,0
y
Front center
-
-
-
-
-
-
-
-
-
-
