Haro Shift Plus i/O 5 2020
The Haro Shift Plus i/O 5 2020 is an electric-bike. E-bikes are bicycles with a battery-powered assist that comes via pedaling, so when you push the pedals a motor engages and gives you a boost.
E-Bike
Groupset
Shimano Deore
Frame material
Alloy
Wheel size
27,5"
Suspension type
Full suspension
Front travel
160mm
Rear travel
160mm
About the Haro Shift Plus i/O 5 2020
The Haro Shift Plus i/O 5 2020 is a Full suspension Enduro Mountain Bike with a alloy frame. Equipped with a Shimano Deore drivetrain of 10 gears (1x10). Its features include dropper seatpost, hydraulic disc brakes, and tubeless ready.
Features
Dropper seatpost
More info
Dropper seatpost
Hydraulic disc brakes
More info
Hydraulic disc brakes
Tubeless ready
More info
Tubeless ready
Specifications
|
Steam
|
Pivit 3D Forged alloy 50mm
|
|---|---|
|
Saddle
|
WTB Volt Sport 150mm Wide
|
|
Battery
|
New Darfon internal, STePS compatible 504Wh
|
|
Headset
|
FPD Dozer 1-1/8"-1.5", w/ Bottom AC Bearing, 8mm Cone
|
|
Seatpost
|
X-Fusion Manic 100, 125, 150mm Dropper post w/ horizontal remote, Alloy, 31.6mm
|
|
Handlebar
|
New Pivit Alloy riser bar, 31.8mm O.D. 780mm wide; 20mm rise
|
|
Brake lever
|
Tektro HD-M745
|
|
Brakes
|
Tektro HD-M745
|
|
Crankset
|
Samox crankarms, Shimano 34T Chainring, 165mm all Sizes
|
|---|---|
|
Motor
|
Shimano STePS E8000, 70Nm Torque
|
|
Shifter
|
Shimano Deore SL-M6000-R 10-spd
|
|
Front derailleur
|
Shimano E-7000 Guide
|
|
Rear derailleur
|
Shimano Deore RD-M6000-GS
GS
10s
|
|
|
|
|
Chain
|
KMC e10 Sport
|
|
Cassette
|
Shimano Deore CS-HG500-10
|
|
Frame
|
New Shift Plus I/O X6 Aluminum frame for Shimano STePS E8000, 4-Bar linkage w/ Carbon Injected Rocker, vertical shock, 160mm travel, Internal Battery, Enduro Bearings
|
|---|---|
|
Front suspension
|
SR Suntour Aion 35
|
|
Rear suspension
|
X-Fusion O2 Pro RL
|
|
Rims
|
Weinmann U-40 TL, Tubeless Ready, 27.5"x40mm, Double Wall
|
|---|---|
|
Tires
|
Kenda NEVEGAL 2 27.5x2.6", EMC, 60tpi, Aramid beads, Tubeless Compatible
|
|
Rear hub
|
Pivit Alloy disc Boost, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axles
|
|
Front hub
|
Pivit Alloy disc Boost, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axles
|
Geometry
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
|
a
Seat tube length
|
394,0
|
432,0
|
470,0
|
495,0
|
|
b
Seat tube angle
|
74,0º
|
74,0º
|
74,0º
|
74,0º
|
|
c
Top tube length
|
559,0
|
587,0
|
616,0
|
644,0
|
|
d
Head tube length
|
100,0
|
110,0
|
120,0
|
130,0
|
|
e
Head tube angle
|
65,0º
|
65,0º
|
65,0º
|
65,0º
|
|
f
Rake
|
51,0
|
51,0
|
51,0
|
51,0
|
|
g
Trail
|
110,0
|
110,0
|
110,0
|
110,0
|
|
h
Wheelbase
|
1197,0
|
1226,0
|
1256,0
|
1285,0
|
|
i
Chainstay length
|
444,0
|
444,0
|
444,0
|
444,0
|
|
j
Bottom bracket drop
|
20,0
|
20,0
|
20,0
|
20,0
|
|
k
Stack height
|
598,0
|
607,0
|
616,0
|
625,0
|
|
l
Reach
|
419,0
|
444,0
|
469,0
|
494,0
|
|
m
Standover height
|
767,0
|
774,0
|
777,0
|
782,0
|
|
x
Bottom bracket height
|
335,0
|
335,0
|
335,0
|
335,0
|
|
y
Front center
|
754,0
|
783,0
|
813,0
|
842,0
|
