Marin Mount Vision Pro 2020

MTB Enduro
Groupset
Shimano XTR
Frame material
Carbon
Wheel size
27,5"
Suspension type
Full suspension
Front travel
150mm
Rear travel
150mm
Marin Mount Vision Pro 2020

About the Marin Mount Vision Pro 2020

The Marin Mount Vision Pro 2020 is a Full suspension Enduro Mountain Bike with a carbon frame. Equipped with a Shimano XTR drivetrain. Its features include dropper seatpost, boost 110 , and boost 148.

Features

The Marin Mount Vision Pro 2020 has 5 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
eixo-e-thru
E-THRU AXLE More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
Marin Locking
Pedals
Not Included.
Components
Steam
Deity Copperhead Stem, 35mm
Saddle
WTB Volt Team, Ti Rails
Headset
FSA Orbit, No. 42/47/ACB/S-4, Sealed Cartridge Bearings, 1 1/8"x 1 1/2”
Seatpost
Fox Transfer Performance Elite, Ano Black with 1x lever, Size S 120mm Travel, All Other Sizes: 150mm Travel, 30.9mm
Handlebar
Deity DC31 Mohawk Carbon Bar, 787mm Width, 25mm Rise, Custom Color
Brake lever
New Shimano XTR BLM9120
Brakes
Shimano XTR BR-M9120 385 (BL-M9120) g Hydraulic disc brake 4 piston
Average weight (g)
385 (BL-M9120)
Brake hose color kit
Black
Brake hose kit
SM-BH90-SBM
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Wiring
Caliper fixing bolt material
Ti
Caliper fixing bolt tool size
** 4 mm
Primary color
Series color
Hose joint
Banjo
ICE TECHNOLOGIES pad compatible caliper
J-Kit spec for OEM
Model
BR-M9120
Mount type
Post-type
Oil
SHIMANO Mineral
Pad standard
N03A Resin pad (w/ radiator fin)
Pad standard
N04C Metal pad (w/ radiator fin)
Pad mount
Pad axle
Piston
4
Piston material
Ceramic
Drivetrain
Crankset
e*thirteen TRSr Carbon, 32T Ultralight Chainring, 170mm length
Shifter
New Shimano XTR, SL-M9100-IR, I-Spec EV
Bottom bracket
Shimano XTR PF92
Chain
KMC 12v
Cassette
Shimano XTR CS-M9100-12 12s HYPERGLIDE+
Aluminum gear finish
Painted
Aluminum gear pieces
3
Aluminum spider arm finish
Anodized
Aluminum spider arm pieces
1
Combination names
10-45T
10-51T
Combination
10-12-14-16-18-21-24-28-32-36-40-45
10-12-14-16-18-21-24-28-33-39-45-51
Compatible chain
HG 12-speed
Lock ring finish
Anodized
Lock ring material
Aluminum
Micro spline
Model
CS-M9100-12
Speeds
12
Steel gear finish
Plated
Steel gear pieces
4
Titanium gear finish
Shot
Titanium gear pieces
5
Type
HYPERGLIDE+
Weights
10-45T: 357g
10-51T: 367g
Rear derailleur
Shimano XTR RD-M9100-SGS 240 g SGS 12s
Average weight (g)
240
B axle finish
Anodized
B axle hollow
B axle material
Aluminum
Bracket body finish
Anodized
Bracket body material
Aluminum
Compatible chain
HG 12-speed
Lower pulley max
51T
Lower pulley min
51T
Model
RD-M9100-SGS
P axle material
Steel
pulley.guide_pulley_bearing
Sealed bearing
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
13T
pulley.tension_pulley_bearing
Sealed bearing
Pulley cage
SGS
Speeds
12
Upper pulley max
10T
Upper pulley min
10T
Total capacity
41T
Frameset
Frame
Full Unidirectional Carbon Fiber Frame, Naild R3ACT – 2 Play Suspension Technology, 27.5" Wheels, 150mm Travel, 148mm Boost Rear Spacing, Bolt On Thru-Axle
Rear suspension
Fox Float X2 Factory
Front suspension
Fox 36 Factory
Wheels
Rims
e*thirteen TRS Race, Carbon Fiber Rim, 28H, 31mm Inner, Hookless, Tubeless Compatible
Tires
Front: e*thirteen, TRS Race All-Terrain Tire, 27.5x2.35", 72tpi, Single Ply Apex Aramid Reinforced, Race Compound, Tubeless Compatible; Rear: e*thirteen, TRS PLUS All-Terrain Tire, 27.5x2.35", 72tpi, Race Compound, Tubeless Compatible
Spokes
The Hive Triple-Butted, Black, J-bend
Rear hub
New Shimano XTR, Alloy Body, Cartridge Bearings, 148x12 E-Thru Axle, 28H, Mircospline Freehub Body
Front hub
New Shimano XTR, Alloy Body, Cartridge Bearings, 110x15 E-Thru Axle, 28H

Geometry

Size SM MD LG XL
a
Seat tube length
395,0
430,0
465,0
502,0
b
Seat tube angle
75,5º
75,3º
75,1º
75,0º
c
Top tube length
576,2
598,0
621,0
645,0
d
Head tube length
90,0
105,0
125,0
138,0
e
Head tube angle
65,0º
65,0º
65,0º
65,0º
f
Rake
44,0
44,0
44,0
44,0
g
Trail
116,0
116,0
117,0
117,0
h
Wheelbase
1155,0
1182,0
1208,0
1235,0
i
Chainstay length
415,0
415,0
415,0
415,0
j
Bottom bracket drop
30,0
30,0
30,0
30,0
k
Stack height
581,6
595,0
613,0
625,0
l
Reach
427,2
448,0
466,5
488,0
m
Standover height
711,0
712,0
723,0
744,0
x
Bottom bracket height
330,0
330,0
330,0
330,0
y
Front center
742,0
769,0
795,0
822,0
