Marin Nail Trail 6 2020

MTB Trail
Groupset
SRAM SX Eagle
Frame material
Alloy
Wheel size
27,5"
Suspension type
Hardtail
Front travel
120mm
Marin Nail Trail 6 2020

About the Marin Nail Trail 6 2020

The Marin Nail Trail 6 2020 is a Hardtail Trail Mountain Bike with a alloy frame. Equipped with a SRAM SX Eagle drivetrain of 12 gears (1x12). Its features include boost 110 , boost 148, and e-thru axle.

Features

The Marin Nail Trail 6 2020 has 5 features listed below.
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
eixo-e-thru
E-THRU AXLE More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info

Specifications

Acessories
Grip
Marin Single Clamp Locking
Pedals
Nylon Platform
Components
Steam
Marin 3D Forged Alloy, 35mm
Saddle
Marin Speed Concept
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seatpost
Marin Alloy, 30.9mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back
Brake lever
Shimano BL-MT400 Hydraulic
Brakes
Shimano BR-MT400 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH59-JK-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Black
Secondary color
Silver
Hose joint
Straight
J-Kit spec for OEM
Model
BR-MT400
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad standard
B03S Resin
Pad mount
Split pin
Piston
2
Piston material
Resin
Recommended brake lever
BL-MT400
BL-MT401
BL-MT402-3A
Recommended disc brake rotor
SM-RT30*
SM-RT54*
SM-RT56*
Drivetrain
Crankset
Marin Forged Alloy 1x12, Hollow Spindle, Steel Narrow-Wide 32T Chainring, 76mm BCD
Shifter
SRAM SX 1x12-Speed
Bottom bracket
External Sealed Cartridge Bearings
Cassette
SRAM SX Eagle
Chain
SRAM SX Eagle
Rear derailleur
SRAM SX Eagle 12s
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
50
Model
RD-SX-1-A1
Name
SX Eagle Rear Derailleur
Pulley bearings material
Steel
Speed
12s
Frameset
Frame
Series 3 6061 Aluminum, 27.5” Wheels, Double Butted Frame, Internal Shifter and Dropper Post Routing, 148x12mm Boost Thru-Axle
Front suspension
RockShox Recon RL Solo Air
Color
Diffusion Black, Gloss Black, Gloss White
fork offset
42mm (27.5"), 46mm (29"), 51mm (29")
Max tire width (mm)
62, 81
Maximum rotor size
220mm
Minimum rotor size
160mm
Model
FS-RCN-RL-A1
Name
Recon RL
Spring
Solo Air
Travel (mm)
100mm, 120mm, 130mm, 140mm, 150mm, 80mm
Upper tube type
32mm straight wall steel
Wheel size
27.5", 29"
Wheels
Rims
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Tires
Vee Tire, Crown Gem 29x2.3"/27.5x2.3", Dual Control Compound, Folding Bead
Spokes
14g Black Stainless Steel
Rear hub
Formula, 148x12mm, Quad Sealed Cartridge Bearings, Alloy Axle, Centerlock Disc, 32H
Front hub
Formula, 110x15mm, Sealed Cartridge Bearings, Centerlock Disc, 32H

Geometry

Size SM MD MD LG XL
a
Seat tube length
381,0
431,0
431,0
482,0
520,0
b
Seat tube angle
74,0º
74,0º
74,0º
74,0º
74,0º
c
Top tube length
588,0
605,0
605,0
625,0
642,0
d
Head tube length
105,0
110,0
110,0
115,0
120,0
e
Head tube angle
68,0º
68,0º
68,0º
68,0º
68,0º
f
Rake
44,0
44,0
51,0
51,0
51,0
g
Trail
95,0
95,0
89,0
89,0
89,0
h
Wheelbase
1110,0
1128,0
1140,53
1161,07
1178,62
i
Chainstay length
423,0
423,0
433,0
433,0
433,0
j
Bottom bracket drop
45,0
45,0
59,0
59,0
59,0
k
Stack height
595,5
600,2
623,69
628,33
632,96
l
Reach
416,0
432,0
425,59
444,26
459,93
m
Standover height
694,84
732,82
737,58
780,02
810,85
x
Bottom bracket height
308,0
308,0
311,5
311,5
311,5
y
Front center
691,0
709,0
714,0
734,0
752,0
