Merida BIG.SEVEN 300 2020

MTB Cross Country
Groupset
Shimano XT
Frame material
Alloy
Wheel size
27,5"
Suspension type
Hardtail
Weight
12,91 kg
Front travel
100mm
Merida BIG.SEVEN 300 2020

About the Merida BIG.SEVEN 300 2020

The Merida BIG.SEVEN 300 2020 is a Hardtail Cross Country Mountain Bike with a alloy frame. Equipped with a Shimano XT drivetrain of 20 gears (2x10). Its features include hydraulic disc brakes. The bike weighs approximately 12,91 kg.

Features

The Merida BIG.SEVEN 300 2020 has 1 features listed below.
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Components
Saddle
MERIDA COMP CC
Headset
MERIDA M2346 Neck
Seatpost
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 0mm setback
Handlebar
MERIDA EXPERT CC, material: aluminium, 720mm width, 10mm rise
Discs
Shimano RT10
Brakes
Shimano BR-MT200 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH59-JK-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Black
Hose joint
Straight
J-Kit spec for OEM
Model
BR-MT200
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad standard
B03S Resin
Pad mount
Split pin
Piston
2
Piston material
Resin
Recommended brake lever
BL-MT201
BL-MT200
Recommended disc brake rotor
SM-RT10*
SM-RT26*
Drivetrain
Crankset
FSA Alfa Drive, 36-22 teeth, 170 mm-S, 175 mm-M up
Shifter
Shimano Deore
Bottom bracket
FSA TH-7420ST Cartridge Bearing
Front derailleur
Shimano Deore
Chain
KMC X10
Cassette
Shimano Deore CS-HG50-10 HG
Combination names
11-36T
Compatible chain
HG-X 10-speed
Lock ring finish
Cr plated
Lock ring material
Steel
Model
CS-HG50-10
Steel gear finish
Ni plated
Steel gear pieces
10
Type
HG
Rear derailleur
Shimano Deore XT RD-M781 238 g SGS 10s
Average weight (g)
238
B axle hollow
B axle material
Stainless steel
Bracket finish
Painted
Bracket material
Aluminum
Bracket body finish
Painted
Bracket body material
Aluminum
Cable fixing bolt material
Stainless steel
Compatible chain
HG-X 10-speed
Lower pulley max
36T
Lower pulley min
32T
Model
RD-M781-SGS
P axle material
Steel
Pulley bolts material
Stainless steel
G pulley bearing
Sealed bearing
Sunken type pulley bolt
T pulley bearing
Sealed bearing
Pulley teeth
11T
Pulley cage
SGS
Speeds
10
Upper pulley max
11T
Upper pulley min
11T
Total capacity
43T
Frameset
Frame
BIG.SEVEN TFS, material: aluminium, 27.5 wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Front suspension
SR Suntour XCR
Wheels
Rims
MERIDA COMP CC, 20mm inner width, material: aluminium
Tires
Maxxis Ikon

Geometry

Size SM MD LG
a
Seat tube length
380,0
440,0
480,0
b
Seat tube angle
73,0º
73,0º
73,0º
c
Top tube length
567,0
587,0
607,0
d
Head tube length
115,0
130,0
145,0
e
Head tube angle
69,0º
69,0º
69,0º
f
Rake
42,0
43,0
42,0
g
Trail
91,0
90,0
91,0
h
Wheelbase
1075,0
1096,0
1117,0
i
Chainstay length
427,0
427,0
427,0
j
Bottom bracket drop
30,0
30,0
30,0
k
Stack height
574,0
588,0
602,0
l
Reach
391,0
406,0
422,0
m
Standover height
686,0
737,0
775,0
x
Bottom bracket height
325,0
325,0
325,0
y
Front center
650,0
671,0
692,0
