Merida BIG.SEVEN 7000-E 2018

E-Bike
MTB Cross Country
Groupset
Shimano XT Di2
Wheel size
27,5"
Suspension type
Hardtail
Weight
9,94 kg
Front travel
100mm
Merida BIG.SEVEN 7000-E 2018

About the Merida BIG.SEVEN 7000-E 2018

The Merida BIG.SEVEN 7000-E 2018 is a Hardtail Cross Country Mountain Bike. Equipped with a Shimano XT Di2 drivetrain of 22 gears (2x11). Its features include hydraulic disc brakes, tapered head tube, and remote lockout. The bike weighs approximately 9,94 kg.

Features

The Merida BIG.SEVEN 7000-E 2018 has 3 features listed below.
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
trava-remota-guidao
Remote lockout More info

Specifications

Components
Saddle
Prologo Scratch
Headset
FSA NO.55E
Seatpost
MERIDA Team carbon S-Flex in line 30.9mm
Handlebar
MERIDA Expert CC 720mm wide flat
Brake lever
Shimano XT
Brakes
Shimano Deore XT BR-M8000 403 (BL-M8000) g Hydraulic disc brake 2 piston
Average weight (g)
403 (BL-M8000)
Brake hose color kit
Black
Brake hose kit
SM-BH90-SB
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Series color
Hose joint
Banjo
ICE TECHNOLOGIES pad compatible caliper
Model
BR-M8000
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad option
G04S Metal
Pad option
J04C Metal
Pad standard
G02A Resin
G03A Resin
Pad standard
J02A Resin
J03A Resin
Pad mount
Pad axle
Piston
2
Piston material
Ceramic
Recommended brake lever
BL-M8000
BL-T8000
Recommended disc brake rotor
RT-MT800
SM-RT86
Drivetrain
Crankset
Shimano XT 34-24 teeth
Shifter
Shimano XT Di2, 22 speed integrated shifting
Front derailleur
Shimano XT Di2
Cassette
Shimano Deore XT CS-M8000 HG
Aluminum gear pieces
2
Aluminum spider arm finish
Anodized
Aluminum spider arm pieces
2
Combination names
11-40T
11-42T
11-46T
Compatible chain
HG 11-speed, LG
Lock ring finish
Anodized
Lock ring material
Aluminum
Model
CS-M8000
Steel gear finish
Shot-Ni
Steel gear pieces
9
Type
HG
Weights
11-40T: 411g
11-42T: 434g
11-46T: 437g
Rear derailleur
Shimano Deore XT RD-M8050 Di2
Chain
KMC X11
Frameset
Frame
BIG.NINE CF3
Front suspension
Fox 32 Float Performance SC
Wheels
Rims
DT Swiss X 1700 SPLINE 22.5, Boost standard - 15mm front and 12mm rear bolt through axles
Tires
Continental Race King Race Sport 2.2" SL

Geometry

Size SM MD LG XL XXL
a
Seat tube length
380,0
444,0
483,0
532,0
584,0
b
Seat tube angle
73,5º
73,5º
73,5º
73,5º
73,5º
c
Top tube length
582,0
602,0
622,0
642,0
662,0
d
Head tube length
95,0
100,0
110,0
125,0
145,0
e
Head tube angle
70,0º
70,0º
70,0º
70,0º
70,0º
f
Rake
46,0
46,0
46,0
46,0
46,0
g
Trail
80,0
80,0
80,0
80,0
80,0
h
Wheelbase
1077,0
1098,0
1118,0
1139,0
1160,0
i
Chainstay length
430,0
430,0
430,0
430,0
430,0
j
Bottom bracket drop
65,0
65,0
65,0
65,0
65,0
k
Stack height
614,0
619,0
628,0
642,0
661,0
l
Reach
399,0
418,0
435,0
451,0
465,0
m
Standover height
678,0
741,0
775,0
816,0
839,0
x
Bottom bracket height
290,0
290,0
290,0
290,0
290,0
y
Front center
655,0
676,0
696,0
717,0
738,0
