Groupset
Shimano Deore
Frame material
Alloy
Wheel size
29"
Suspension type
Hardtail
Front travel
140mm

About the Merida BIG TRAIL 600 2022
The Merida BIG TRAIL 600 2022 is a Hardtail Trail Mountain Bike with a alloy frame. Equipped with a Shimano Deore drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148.
Features
Dropper seatpost
More info
Dropper seatpost
Boost 110
More info
Boost 110
Boost 148
More info
Boost 148
Hydraulic disc brakes
More info
Hydraulic disc brakes
Tapered head tube
More info
Tapered head tube
Tubeless ready
More info
Tubeless ready
Specifications
Steam
|
MERIDA EXPERT TR, material: aluminium, 35mm diameter, 0° stem angle, 50 mm all sizes
|
---|---|
Saddle
|
MERIDA COMP SL, V-mount, incl. MERIDA minitool
|
Headset
|
MERIDA M2331
|
Seatpost
|
MERIDA COMP TR, 30.9mm diameter, 0mm setback, S: 125mm travel seatpost - M/L: 150mm travel seatpost - XL/XXL 175mm travel seatpost
|
Handlebar
|
MERIDA EXPERT TR, material: aluminium, 780mm width, 20mm rise
|
Discs
|
Shimano RT10, 180mm
|
Brakes
|
Shimano BR-MT410
Hydraulic disc brake
2 piston
|
SM-RT54* SM-RT56* |
Crankset
|
Race Face Ride, 32 teeth, 170 mm-S, 175 mm-M up
|
---|---|
Shifter
|
Shimano SL -MT500-IL / Shimano Deore M6100
|
Bottom bracket
|
Race Face BSA 68/73 – 24mm
|
Cassette
|
Shimano Deore CS-M6100-12
HYPERGLIDE+
|
|
|
Rear derailleur
|
Shimano Deore RD-M6100
SGS
12s
|
|
|
Chain
|
KMC X12
|
Frame
|
BIG.TRAIL TFS, material: aluminium, 29x2.5" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard
|
---|---|
Front suspension
|
Marzocchi Z2 Air
|
Rims
|
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
|
---|---|
Tires
|
Maxxis Dissector, 29x2.4", fold, TR EXO Dual
|
Rear hub
|
Shimano MT400-B / Shimano MT410-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
|
Front hub
|
Shimano MT400-B / Shimano MT410-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
|
Geometry
Size | SM | MD | LG | XL | XXL |
---|---|---|---|---|---|
a
Seat tube length
|
380,0
|
410,0
|
430,0
|
450,0
|
470,0
|
b
Seat tube angle
|
75,5º
|
75,5º
|
75,5º
|
75,5º
|
75,5º
|
c
Top tube length
|
576,0
|
597,0
|
619,0
|
642,0
|
667,0
|
d
Head tube length
|
95,0
|
100,0
|
110,0
|
120,0
|
120,0
|
e
Head tube angle
|
65,5º
|
65,5º
|
65,5º
|
65,5º
|
65,5º
|
f
Rake
|
41,0
|
41,0
|
41,0
|
41,0
|
41,0
|
g
Trail
|
126,0
|
126,0
|
126,0
|
126,0
|
126,0
|
h
Wheelbase
|
1147,0
|
1169,0
|
1193,0
|
1217,0
|
1242,0
|
i
Chainstay length
|
432,0
|
432,0
|
432,0
|
432,0
|
432,0
|
j
Bottom bracket drop
|
66,5
|
66,5
|
66,5
|
66,5
|
66,5
|
k
Stack height
|
633,0
|
638,0
|
647,0
|
656,0
|
656,0
|
l
Reach
|
412,0
|
432,0
|
452,0
|
472,0
|
497,0
|
m
Standover height
|
713,0
|
720,0
|
722,0
|
725,0
|
779,0
|
x
Bottom bracket height
|
308,0
|
308,0
|
308,0
|
308,0
|
308,0
|
y
Front center
|
723,0
|
745,0
|
769,0
|
793,0
|
818,0
|
