Merida eONE-FORTY 8000 2022

E-Bike
MTB Trail
Groupset
Shimano XT
Frame material
Carbon
Wheel size
27,5"
Suspension type
Full suspension
Front travel
140mm
Rear travel
133mm
Merida eONE-FORTY 8000 2022

About the Merida eONE-FORTY 8000 2022

The Merida eONE-FORTY 8000 2022 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a Shimano XT drivetrain of 11 gears (1x11). Its features include dropper seatpost, boost 110 , and boost 148.

Features

The Merida eONE-FORTY 8000 2022 has 6 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
tubeless-ready
Tubeless ready More info

Specifications

Acessories
Remote
Shimano SC-E7000
Components
Saddle
MERIDA EXPERT CC, V-mount
Battery
Shimano E8036 630Wh / Shimano E8035 504Wh for S only
Headset
MERIDA-8152
Seatpost
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, S 100mm travel seatpost - S/M 125mm travel seatpost - L 150mm travel seatpost - XL/XXL 170mm travel seatpost
Handlebar
MERIDA EXPERT eTR, 780mm width, 20mm rise
Brakes
Shimano SLX BR-M7000
Drivetrain
Crankset
Shimano CRE80-B, 34 teeth, Shimano FCEM600
Motor
Shimano EP8, 85Nm
Shifter
Shimano SL -MT500-IL
Bottom bracket
included
Chain
Shimano CN-LG500 257 g
Average weight (g)
257
Chromizing treatment roller link pin
Model
CN-LG500
Pin link plate
Gray
Roller link plate
Gray
Type
LG
Cassette
Shimano CS-LG600-11 LINKGLIDE
Combination names
11-50T
Compatible chain
HG 11-speed, LG
Lock ring finish
Chrome plated
Lock ring material
Steel
Model
CS-LG600-11
Steel gear finish
Nickel chrome cobalt black plated
Steel gear pieces
11
Type
LINKGLIDE
Rear derailleur
Shimano Deore XT RD-M8000-GS 271 g GS 11s
Average weight (g)
271
B axle hollow
B axle material
Stainless steel
Bracket finish
Painted
Bracket material
Aluminum
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG-X 11-speed
Lower pulley max
42T(2x11-speed),
46T(1x11-speed)
Lower pulley min
40T
Model
RD-M8000-GS
P axle material
Steel
pulley.guide_pulley_bearing
Sealed bearing
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
11T
pulley.tension_pulley_bearing
Sealed bearing
Pulley cage
GS
Speeds
11
Upper pulley max
11T
Upper pulley min
11T
Total capacity
39T
Frameset
Frame
eONE-FORTY CFA II, material: carbon, 133mm suspension travel, 27.5x2.8" max. wheelsize, 148x12mm axle standard, intube, max. 630 Wh
Front suspension
Fox 34 Float Rhythm
Rear suspension
Fox Float DPS Performance
Wheels
Rims
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Tires
Trail King, 29x2.4 ", fold, BlackChili, ProTection Apex, TR
Spokes
Black stainless
Rear hub
Shimano XT, 148x12mm width rear hub, 36 spoke holes, Centerlock
Front hub
Shimano XT, 110x15mm width front hub, 32 spoke holes, Centerlock

Geometry

Size SM MD LG XL XXL
a
Seat tube length
405,0
420,0
440,0
470,0
500,0
b
Seat tube angle
76,5º
76,5º
76,5º
76,5º
76,5º
c
Top tube length
566,0
587,0
608,0
631,0
655,0
d
Head tube length
110,0
115,0
120,0
135,0
150,0
e
Head tube angle
66,5º
66,5º
66,5º
66,5º
66,5º
f
Rake
47,0
47,0
47,0
48,0
48,0
g
Trail
103,0
103,0
103,0
102,0
102,0
h
Wheelbase
1165,0
1187,0
1209,0
1235,5
1261,5
i
Chainstay length
444,5
444,5
444,5
444,5
444,5
j
Bottom bracket drop
24,0
24,0
24,0
24,0
24,0
k
Stack height
627,0
631,5
636,0
649,5
663,0
l
Reach
415,0
434,5
454,5
474,5
494,5
m
Standover height
741,0
736,0
732,0
739,0
753,0
x
Bottom bracket height
331,0
331,0
331,0
331,0
331,0
y
Front center
722,0
744,0
766,0
792,0
818,0
