Merida eONE-SIXTY 10K 2022
The Merida eONE-SIXTY 10K 2022 is an electric-bike. E-bikes are bicycles with a battery-powered assist that comes via pedaling, so when you push the pedals a motor engages and gives you a boost.
E-Bike
Groupset
Shimano XTR
Frame material
Carbon
Wheel size
29" / 27,5"
Suspension type
Full suspension
Front travel
160mm
Rear travel
150mm
About the Merida eONE-SIXTY 10K 2022
The Merida eONE-SIXTY 10K 2022 is a Full suspension Enduro Mountain Bike with a carbon frame. Equipped with a Shimano XTR drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148.
Features
Dropper seatpost
More info
Dropper seatpost
Boost 110
More info
Boost 110
Boost 148
More info
Boost 148
Hydraulic disc brakes
More info
Hydraulic disc brakes
Tapered head tube
More info
Tapered head tube
Tubeless ready
More info
Tubeless ready
Specifications
|
Remote
|
Shimano SC-EM800
|
|---|
|
Steam
|
MERIDA EXPERT eTRII, material: aluminium, 35mm diameter, 0° stem angle, Supernova mount, 40 mm all sizes
|
|---|---|
|
Saddle
|
MERIDA EXPERT CC, V-mount
|
|
Battery
|
Shimano E8036 630Wh / Shimano E8035 504Wh for XS only
|
|
Headset
|
MERIDA-8152
|
|
Seatpost
|
SP REVERB AXS, 30.9mm diameter, 0mm setback, XS 125mm travel seatpost - S/M 150mm travel seatpost - L/XL 170mm travel seatpost
|
|
Handlebar
|
MERIDA EXPERT eTR, 780mm width, 20mm rise
|
|
Discs
|
Shimano RT-MT900 / Shimano RT-EM910, 203 mm
|
|
Brakes
|
Shimano XTR BR-M9000
316.1 g
Hydraulic disc brake
2 piston
|
|
J03A Resin G03A Resin * SM-RT99-A |
|
|
Crankset
|
Shimano CRE80-12-B, 34 teeth, Shimano FCEM900
|
|---|---|
|
Motor
|
Shimano EP8, 85Nm
|
|
Shifter
|
EC AXS ROCKSHOX LH 1BUTTON DIS / Shimano XTR M9100
|
|
Bottom bracket
|
included
|
|
Cassette
|
Shimano XTR CS-M9100-12
12s
HYPERGLIDE+
|
|
10-51T 10-12-14-16-18-21-24-28-33-39-45-51 10-51T: 367g |
|
|
Rear derailleur
|
Shimano XTR RD-M9100-SGS
240 g
SGS
12s
|
|
|
|
|
Chain
|
KMC e12 Turbo
|
|
Frame
|
eONE-SIXTY CFA II, material: carbon, 150mm suspension travel, 27.5x2.8" max. wheelsize, 148x12mm axle standard, intube, max. 630 Wh
|
|---|---|
|
Rear suspension
|
Fox Float X2 Factory
|
|
Front suspension
|
Fox 38 Factory
|
|
Rims
|
DT Swiss Spline HXC1501 spline 30 boost, 110x15mm width front hub, 148x12mm width rear hub, 30mm inner width, Centerlock, microspline, material: carbon, Tubeless ready (tubeless tape and valves included)
|
|---|---|
|
Tires
|
Maxxis Assegai, 29x2.5 ", fold, TR EXO+ 3C MaxxGrip
|
|
Rear hub
|
MERIDA EXPERT TR, including removeable lever, 6/4mm allen key
|
|
Front hub
|
MERIDA EXPERT TR, including removeable lever, 6/4mm allen key
|
Geometry
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
|
a
Seat tube length
|
405,0
|
420,0
|
440,0
|
470,0
|
500,0
|
|
b
Seat tube angle
|
75,5º
|
75,5º
|
75,5º
|
75,5º
|
75,5º
|
|
c
Top tube length
|
568,0
|
589,0
|
610,0
|
634,0
|
657,0
|
|
d
Head tube length
|
110,0
|
115,0
|
120,0
|
135,0
|
150,0
|
|
e
Head tube angle
|
65,5º
|
65,5º
|
65,5º
|
65,5º
|
65,5º
|
|
f
Rake
|
46,0
|
46,0
|
46,0
|
46,0
|
46,0
|
|
g
Trail
|
120,0
|
120,0
|
120,0
|
120,0
|
120,0
|
|
h
Wheelbase
|
1173,0
|
1195,0
|
1217,0
|
1243,5
|
1270,0
|
|
i
Chainstay length
|
444,5
|
444,5
|
444,5
|
444,5
|
444,5
|
|
j
Bottom bracket drop
|
17,5
|
17,5
|
17,5
|
17,5
|
17,5
|
|
k
Stack height
|
633,5
|
638,0
|
642,5
|
656,5
|
670,0
|
|
l
Reach
|
405,0
|
425,0
|
445,0
|
465,0
|
485,0
|
|
m
Standover height
|
747,0
|
742,0
|
738,0
|
745,0
|
759,0
|
|
x
Bottom bracket height
|
-
|
-
|
-
|
-
|
-
|
|
y
Front center
|
729,0
|
751,0
|
773,0
|
800,0
|
826,0
|
