Merida eONE-SIXTY 9000 2022
The Merida eONE-SIXTY 9000 2022 is an electric-bike. E-bikes are bicycles with a battery-powered assist that comes via pedaling, so when you push the pedals a motor engages and gives you a boost.
E-Bike
Groupset
Shimano XT
Frame material
Carbon
Wheel size
29" / 27,5"
Suspension type
Full suspension
Front travel
160mm
Rear travel
150mm
About the Merida eONE-SIXTY 9000 2022
The Merida eONE-SIXTY 9000 2022 is a Full suspension Enduro Mountain Bike with a carbon frame. Equipped with a Shimano XT drivetrain of 11 gears (1x11). Its features include dropper seatpost, boost 110 , and boost 148.
Features
Dropper seatpost
More info
Dropper seatpost
Boost 110
More info
Boost 110
Boost 148
More info
Boost 148
Hydraulic disc brakes
More info
Hydraulic disc brakes
Tapered head tube
More info
Tapered head tube
Tubeless ready
More info
Tubeless ready
Specifications
|
Remote
|
Shimano SC-EM800
|
|---|
|
Steam
|
MERIDA EXPERT eTRII, material: aluminium, 35mm diameter, 0° stem angle, Supernova mount, 40 mm all sizes
|
|---|---|
|
Saddle
|
MERIDA EXPERT CC, V-mount
|
|
Battery
|
Shimano E8036 630Wh / Shimano E8035 504Wh for XS only
|
|
Headset
|
MERIDA-8152
|
|
Seatpost
|
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, XS 100mm travel seatpost - S 125mm travel seatpost - M 150mm travel seatpost - L/XL 170mm travel seatpost
|
|
Handlebar
|
MERIDA EXPERT eTR, 780mm width, 20mm rise
|
|
Discs
|
Shimano RT-MT900 / Shimano RT-EM910, 203 mm
|
|
Brakes
|
Shimano Deore XT BR-M8000
403 (BL-M8000) g
Hydraulic disc brake
2 piston
|
|
G03A Resin J03A Resin BL-T8000 SM-RT86 |
|
|
Crankset
|
Shimano CRE80-B, 34 teeth, Shimano FCEM900
|
|---|---|
|
Motor
|
Shimano EP8, 85Nm
|
|
Shifter
|
Shimano SL -MT800-IL / Shimano XT M8130 11
|
|
Bottom bracket
|
included
|
|
Chain
|
Shimano CN-LG500
257 g
|
|
|
|
|
Cassette
|
Shimano CS-LG600-11
LINKGLIDE
|
|
|
|
|
Rear derailleur
|
Shimano Deore XT RD-M8000-GS
271 g
GS
11s
|
|
46T(1x11-speed) |
|
|
Frame
|
eONE-SIXTY CFA II, material: carbon, 150mm suspension travel, 27.5x2.8" max. wheelsize, 148x12mm axle standard, intube, max. 630 Wh
|
|---|---|
|
Front suspension
|
Fox 38 Factory
|
|
Rear suspension
|
Fox Float DPX2
|
|
Rims
|
DT Swiss Spline HX1501 ONE 30 boost, 110x15mm width front hub, 148x12mm width rear hub, 30mm inner width, Centerlock, material: aluminium, Tubeless ready (tubeless tape and valves included)
|
|---|---|
|
Tires
|
Maxxis Assegai, 29x2.5 ", fold, TR EXO+ 3C MaxxGrip
|
|
Rear hub
|
MERIDA EXPERT TR, including removeable lever, 6/4mm allen key
|
|
Front hub
|
MERIDA EXPERT TR, including removeable lever, 6/4mm allen key
|
Geometry
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
|
a
Seat tube length
|
405,0
|
420,0
|
440,0
|
470,0
|
500,0
|
|
b
Seat tube angle
|
75,5º
|
75,5º
|
75,5º
|
75,5º
|
75,5º
|
|
c
Top tube length
|
568,0
|
589,0
|
610,0
|
634,0
|
657,0
|
|
d
Head tube length
|
110,0
|
115,0
|
120,0
|
135,0
|
150,0
|
|
e
Head tube angle
|
65,5º
|
65,5º
|
65,5º
|
65,5º
|
65,5º
|
|
f
Rake
|
46,0
|
46,0
|
46,0
|
46,0
|
46,0
|
|
g
Trail
|
120,0
|
120,0
|
120,0
|
120,0
|
120,0
|
|
h
Wheelbase
|
1173,0
|
1195,0
|
1217,0
|
1243,5
|
1270,0
|
|
i
Chainstay length
|
444,5
|
444,5
|
444,5
|
444,5
|
444,5
|
|
j
Bottom bracket drop
|
17,5
|
17,5
|
17,5
|
17,5
|
17,5
|
|
k
Stack height
|
633,5
|
638,0
|
642,5
|
656,5
|
670,0
|
|
l
Reach
|
405,0
|
425,0
|
445,0
|
465,0
|
485,0
|
|
m
Standover height
|
747,0
|
742,0
|
738,0
|
745,0
|
759,0
|
|
x
Bottom bracket height
|
-
|
-
|
-
|
-
|
-
|
|
y
Front center
|
729,0
|
751,0
|
773,0
|
800,0
|
826,0
|
