Merida JULIET 6. 20-V 2018
The Merida JULIET 6. 20-V 2018 is a women’s bike. In general, women’s bikes are designed to fit better on women's body proportions.
Women's Bike
Groupset
Shimano Tourney
Wheel size
26"
Suspension type
Hardtail
Weight
13,9 kg
Front travel
100mm
About the Merida JULIET 6. 20-V 2018
The Merida JULIET 6. 20-V 2018 is a Hardtail Cross Country Mountain Bike. Equipped with a Shimano Tourney drivetrain of 24 gears (3x8). The bike weighs approximately 13,9 kg.
Specifications
|
Brakes
|
Shimano EF500 levers with Promax V-brakes
|
|---|---|
|
Saddle
|
Female specific Juliet Sport
|
|
Headset
|
MERIDA 44 PSE
|
|
Seatpost
|
MERIDA Speed 27.2mm
|
|
Handlebar
|
MERIDA Speed 620mm wide 30mm rise
|
|
Brake lever
|
Shimano EF500
|
|
Chain
|
KMC M700
|
|---|---|
|
Crankset
|
Shimano TY301 42-34-24 with chainguard
|
|
Shifter
|
Shimano EF500 24 speed EZ-fire shifters
|
|
Front derailleur
|
Shimano Tourney / Acera-X, 24 speed
|
|
Rear derailleur
|
Shimano Tourney RD-TX800
SGS
8/7s
|
|
|
|
|
Cassette
|
Sunrace M66 11-34T 8-speed
|
|
Frame
|
JULIET SPEED 6.
|
|---|---|
|
Front suspension
|
SR Suntour XCT
|
|
Rims
|
MERIDA aluminium, 32 hole for V-brakes
|
|---|---|
|
Tires
|
MERIDA K1080 26 * 1.95" wire bead
|
|
Spokes
|
Black steel
|
|
Rear hub
|
Alloy, 32 hole quick release front and Shimano TX500 rear.
|
|
Front hub
|
Alloy, 32 hole quick release front and Shimano TX500 rear.
|
Geometry
| Size | XS | SM | MD |
|---|---|---|---|
|
a
Seat tube length
|
343,0
|
381,0
|
432,0
|
|
b
Seat tube angle
|
73,5º
|
73,5º
|
73,0º
|
|
c
Top tube length
|
534,0
|
544,0
|
554,0
|
|
d
Head tube length
|
115,0
|
125,0
|
135,0
|
|
e
Head tube angle
|
69,5º
|
69,5º
|
70,0º
|
|
f
Rake
|
38,0
|
38,0
|
38,0
|
|
g
Trail
|
88,0
|
88,0
|
84,0
|
|
h
Wheelbase
|
1022,0
|
1032,0
|
1032,0
|
|
i
Chainstay length
|
419,0
|
419,0
|
419,0
|
|
j
Bottom bracket drop
|
55,0
|
55,0
|
55,0
|
|
k
Stack height
|
588,0
|
598,0
|
609,0
|
|
l
Reach
|
358,0
|
365,0
|
366,0
|
|
m
Standover height
|
583,0
|
615,0
|
668,0
|
|
x
Bottom bracket height
|
288,0
|
288,0
|
288,0
|
|
y
Front center
|
609,0
|
619,0
|
619,0
|
