Merida NINETY-SIX 6000 2022
Groupset
Shimano SLX
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Front travel
120mm
Rear travel
100mm
About the Merida NINETY-SIX 6000 2022
The Merida NINETY-SIX 6000 2022 is a Full suspension Cross Country Mountain Bike with a carbon frame. Equipped with a Shimano SLX drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148.
Features
Dropper seatpost
More info
Dropper seatpost
Boost 110
More info
Boost 110
Boost 148
More info
Boost 148
Hydraulic disc brakes
More info
Hydraulic disc brakes
Tapered head tube
More info
Tapered head tube
Tubeless ready
More info
Tubeless ready
Specifications
|
Steam
|
MERIDA TEAM CC II, material: aluminium, 31.8mm diameter, -8° stem angle, 60 mm all sizes
|
|---|---|
|
Saddle
|
MERIDA COMP SL, V-mount, incl. MERIDA minitool
|
|
Headset
|
MERIDA-8151 1-1/8"-1.5" cartridge bearing set
|
|
Seatpost
|
MERIDA COMP TR, 30.9mm diameter, 0mm setback, S: 125mm travel seatpost - M/L: 150mm travel seatpost - XL 175mm travel seatpost
|
|
Handlebar
|
MERIDA EXPERT CC, material: aluminium, 760mm width, flat
|
|
Discs
|
Shimano RT54, 180mm, 160mm
|
|
Brakes
|
Shimano SLX BR-M7120
444 (BL-M7100) g
Hydraulic disc brake
4 piston
|
|
|
|
|
Crankset
|
Race Face Aeffect, 34 teeth, 170 mm-S, 175 mm-M up
|
|---|---|
|
Shifter
|
Shimano SL -MT500-IL / Shimano XT, Multi Release
|
|
Bottom bracket
|
Race Face BSA 68/73 – 24mm
|
|
Cassette
|
Shimano Deore CS-M6100-12
HYPERGLIDE+
|
|
|
|
|
Chain
|
KMC X12
|
|
Rear derailleur
|
Shimano SLX RD-M7100
313 g
SGS
12s
|
|
|
|
|
Frame
|
NINETY-SIX CF4 III, 100mm suspension travel, material: carbon, 29x2.3" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard
|
|---|---|
|
Rear suspension
|
Fox Float DPS Performance Elite
|
|
Front suspension
|
RockShox SID
|
|
Rims
|
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
|
|---|---|
|
Tires
|
Maxxis Minion DHR II, 29x2.3", fold, TR EXO 3C MaxxTerra
|
|
Rear hub
|
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
|
|
Front hub
|
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
|
Geometry
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
|
a
Seat tube length
|
400,0
|
440,0
|
470,0
|
500,0
|
|
b
Seat tube angle
|
75,0º
|
75,0º
|
75,0º
|
74,5º
|
|
c
Top tube length
|
581,0
|
601,0
|
624,0
|
648,0
|
|
d
Head tube length
|
95,0
|
95,0
|
105,0
|
115,0
|
|
e
Head tube angle
|
67,0º
|
67,0º
|
67,0º
|
67,0º
|
|
f
Rake
|
42,0
|
42,0
|
41,0
|
41,0
|
|
g
Trail
|
113,0
|
113,0
|
114,0
|
114,0
|
|
h
Wheelbase
|
1136,0
|
1156,0
|
1180,0
|
1203,0
|
|
i
Chainstay length
|
435,0
|
435,0
|
435,0
|
435,0
|
|
j
Bottom bracket drop
|
36,0
|
36,0
|
36,0
|
36,0
|
|
k
Stack height
|
595,0
|
595,0
|
605,0
|
614,0
|
|
l
Reach
|
420,0
|
440,0
|
460,0
|
480,0
|
|
m
Standover height
|
740,0
|
741,0
|
747,0
|
749,0
|
|
x
Bottom bracket height
|
338,0
|
338,0
|
338,0
|
338,0
|
|
y
Front center
|
703,0
|
723,0
|
747,0
|
770,0
|
