Merida NINETY-SIX 7000 2022

MTB Cross Country
Groupset
Shimano XT
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Front travel
120mm
Rear travel
100mm
Merida NINETY-SIX 7000 2022

About the Merida NINETY-SIX 7000 2022

The Merida NINETY-SIX 7000 2022 is a Full suspension Cross Country Mountain Bike with a carbon frame. Equipped with a Shimano XT drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148.

Features

The Merida NINETY-SIX 7000 2022 has 7 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
trava-remota-guidao
Remote lockout More info
tubeless-ready
Tubeless ready More info

Specifications

Components
Steam
MERIDA TEAM CC II, material: aluminium, 31.8mm diameter, -8° stem angle, 60 mm all sizes
Saddle
MERIDA EXPERT SL, V-mount, incl. MERIDA minitool
Headset
MERIDA-8151 1-1/8"-1.5" cartridge bearing set
Seatpost
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, S: 125mm travel seatpost - M 150mm travel seatpost - L/XL 170mm travel seatpost
Handlebar
MERIDA EXPERT CC, material: aluminium, 760mm width, flat
Discs
Shimano RT-MT800, 180mm, 160mm
Brakes
Shimano Deore XT BR-M8110-R 417 (BL-M8100) g Hydraulic disc brake 2 piston
Average weight (g)
417 (BL-M8100)
Brake hose color kit
Black
Brake hose kit
SM-BH90-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Bolt fix pin/Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
4 mm
Primary color
Series color
Hose joint
Straight
ICE TECHNOLOGIES pad compatible caliper
J-Kit spec for OEM
Model
BR-M8110-R
Mount type
Flat mount
Oil
SHIMANO Mineral
One way bleeding
Pad option
L03A Resin (w/ fin)
Pad option
L04C Metal (w/ fin)
Pad standard
K03S Resin (w/o fin)
Pad standard
K04S Metal (w/o fin)
Pad mount
Pad axle
Piston
2
Piston material
Ceramic
Drivetrain
Crankset
Race Face Next R, 34 teeth, 170 mm-S, 175 mm-M up
Shifter
Shimano SL -MT800-IL / Shimano XT, Multi Release
Bottom bracket
BB, BSA 73mm– Ø30mm, Ext. Seal
Rear derailleur
Shimano Deore XT RD-M8100 284 g SGS 12s
Average weight (g)
284
B axle hollow
B axle material
Stainless steel
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG 12-speed
Lower pulley max
51T
Lower pulley min
51T
Model
RD-M8100-SGS
P axle material
Steel
pulley.guide_pulley_bearing
Sealed bearing
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
13T
pulley.tension_pulley_bearing
Sealed bearing
Pulley cage
SGS
Speeds
12
Upper pulley max
10T
Upper pulley min
10T
Total capacity
41T
Chain
Shimano CN-M8100 252 g
Average weight (g)
252
Chromizing treatment roller link pin
Model
CN-M8100
Pin link plate
Gray
Roller link plate
Chromizing
Type
HG 12-speed
Cassette
Shimano Deore XT CS-M8100-12 HYPERGLIDE+
Aluminum gear finish
Anodized
Aluminum gear pieces
2
Aluminum spider arm finish
Painted
Aluminum spider arm pieces
1
Combination names
10-45T
10-51T
Compatible chain
HG 12-speed
Lock ring finish
Anodized
Lock ring material
Aluminum
Model
CS-M8100-12
Steel gear finish
Plated
Steel gear pieces
10
Type
HYPERGLIDE+
Weights
10-45T: 461g
10-51T: 470g
Frameset
Frame
NINETY-SIX CF4 III, 100mm suspension travel, material: carbon, 29x2.3" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard
Rear suspension
Fox Float DPS Performance Elite
Front suspension
Fox 34 Float Performance Elite
Wheels
Rims
Reynolds TR 309/289 XC, 110x15mm width front hub, 148x12mm width rear hub, 30/28mm inner width, Centerlock, Shimano 12 Speed, material: carbon, Tubeless ready (tubeless tape and valves included), Lifetime warranty
Tires
Maxxis Minion DHR II, 29x2.3", fold, TR EXO 3C MaxxTerra
Rear hub
MERIDA EXPERT TR, including removeable lever, 6/4mm allen key
Front hub
MERIDA EXPERT TR, including removeable lever, 6/4mm allen key

Geometry

Size SM MD LG XL
a
Seat tube length
400,0
440,0
470,0
500,0
b
Seat tube angle
75,0º
75,0º
75,0º
74,5º
c
Top tube length
581,0
601,0
624,0
648,0
d
Head tube length
95,0
95,0
105,0
115,0
e
Head tube angle
67,0º
67,0º
67,0º
67,0º
f
Rake
42,0
42,0
41,0
41,0
g
Trail
113,0
113,0
114,0
114,0
h
Wheelbase
1136,0
1156,0
1180,0
1203,0
i
Chainstay length
435,0
435,0
435,0
435,0
j
Bottom bracket drop
36,0
36,0
36,0
36,0
k
Stack height
595,0
595,0
605,0
614,0
l
Reach
420,0
440,0
460,0
480,0
m
Standover height
740,0
741,0
747,0
749,0
x
Bottom bracket height
338,0
338,0
338,0
338,0
y
Front center
703,0
723,0
747,0
770,0
