BikeWise

Merida NINETY-SIX RC XT 2022

MTB Cross Country
Groupset
Shimano XT
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Front travel
100mm
Rear travel
100mm
Merida NINETY-SIX RC XT 2022

About the Merida NINETY-SIX RC XT 2022

The Merida NINETY-SIX RC XT 2022 is a Full suspension Cross Country Mountain Bike with a carbon frame. Equipped with a Shimano XT drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148.

Features

The Merida NINETY-SIX RC XT 2022 has 7 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
trava-remota-guidao
Remote lockout More info
tubeless-ready
Tubeless ready More info

Specifications

Components
Saddle
MERIDA EXPERT CC, incl. MERIDA minitool
Headset
MERIDA-8151 1-1/8"-1.5" cartridge bearing set
Seatpost
MERIDA EXPERT TR LIGHT, 30.9mm diameter, 0mm setback, S/M/L/XL: 100mm travel seatpost
Handlebar
MERIDA EXPERT CC, material: aluminium, 760mm width, flat
Brakes
Shimano Deore XT BR-M8000 403 (BL-M8000) g Hydraulic disc brake 2 piston
Average weight (g)
403 (BL-M8000)
Brake hose color kit
Black
Brake hose kit
SM-BH90-SB
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Series color
Hose joint
Banjo
ICE TECHNOLOGIES pad compatible caliper
Model
BR-M8000
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad option
G04S Metal
Pad option
J04C Metal
Pad standard
G02A Resin
G03A Resin
Pad standard
J02A Resin
J03A Resin
Pad mount
Pad axle
Piston
2
Piston material
Ceramic
Recommended brake lever
BL-M8000
BL-T8000
Recommended disc brake rotor
RT-MT800
SM-RT86
Drivetrain
Crankset
Shimano XT, 32 teeth, 170 mm-S, 175 mm-M up
Shifter
Shimano SL -MT500-IL
Bottom bracket
BSA, 73mm, threaded
Rear derailleur
Shimano Deore XT RD-M8100 284 g SGS 12s
Average weight (g)
284
B axle hollow
B axle material
Stainless steel
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG 12-speed
Lower pulley max
51T
Lower pulley min
51T
Model
RD-M8100-SGS
P axle material
Steel
pulley.guide_pulley_bearing
Sealed bearing
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
13T
pulley.tension_pulley_bearing
Sealed bearing
Pulley cage
SGS
Speeds
12
Upper pulley max
10T
Upper pulley min
10T
Total capacity
41T
Cassette
Shimano Deore XT CS-M8100-12 HYPERGLIDE+
Aluminum gear finish
Anodized
Aluminum gear pieces
2
Aluminum spider arm finish
Painted
Aluminum spider arm pieces
1
Combination names
10-45T
10-51T
Compatible chain
HG 12-speed
Lock ring finish
Anodized
Lock ring material
Aluminum
Model
CS-M8100-12
Steel gear finish
Plated
Steel gear pieces
10
Type
HYPERGLIDE+
Weights
10-45T: 461g
10-51T: 470g
Chain
Shimano CN-M7100 252 g
Average weight (g)
252
Chromizing treatment roller link pin
Model
CN-M7100
Pin link plate
Gray
Roller link plate
SIL-TEC
Type
HG 12-speed
Frameset
Frame
NINETY-SIX RC CF4 III, 100mm suspension travel, material: carbon, 29 wheelsize, 148x12mm axle standard, BSA bottom bracket standard
Rear suspension
Fox Float DPS Performance Elite
Front suspension
Fox 32 Float Performance SC
Wheels
Rims
MERIDA EXPERT CC, 22.8mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Tires
Maxxis Rekon Race, 29x2.25", fold, TR EXO 120 TPI
Spokes
Double Butted Black stainless
Rear hub
Shimano SLX, 148x12mm width rear hub, 32 spoke holes, Centerlock
Front hub
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock

Geometry

Size SM MD LG XL
a
Seat tube length
400,0
440,0
470,0
500,0
b
Seat tube angle
76,5º
76,5º
76,0º
76,0º
c
Top tube length
576,0
596,0
619,0
643,0
d
Head tube length
95,0
95,0
105,0
115,0
e
Head tube angle
68,5º
68,5º
68,5º
68,5º
f
Rake
44,0
44,0
43,0
44,0
g
Trail
100,0
100,0
101,0
100,0
h
Wheelbase
1126,0
1146,0
1169,0
1193,0
i
Chainstay length
435,0
435,0
435,0
435,0
j
Bottom bracket drop
45,0
45,0
45,0
45,0
k
Stack height
585,0
585,0
595,0
604,0
l
Reach
433,0
453,0
473,0
493,0
m
Standover height
730,0
731,0
736,0
738,0
x
Bottom bracket height
329,0
329,0
329,0
329,0
y
Front center
695,0
715,0
738,0
762,0
