Groupset
Shimano Deore
Frame material
Alloy
Wheel size
29"
Suspension type
Full suspension
Weight
15,25 kg
Front travel
130mm
Rear travel
120mm
About the Merida ONE-TWENTY 400 2021
The Merida ONE-TWENTY 400 2021 is a Full suspension Trail Mountain Bike with a alloy frame. Equipped with a Shimano Deore drivetrain of 11 gears (1x11). Its features include dropper seatpost, boost 110 , and boost 148. The bike weighs approximately 15,25 kg.
Features
Dropper seatpost
More info
Dropper seatpost
Boost 110
More info
Boost 110
Boost 148
More info
Boost 148
Hydraulic disc brakes
More info
Hydraulic disc brakes
Tapered head tube
More info
Tapered head tube
Specifications
|
Steam
|
MERIDA COMP CC, material: aluminium, 31.8mm diameter, 6° stem angle, 60 mm all sizes
|
|---|---|
|
Saddle
|
MERIDA COMP CC
|
|
Headset
|
FSA NO.47/50
|
|
Seatpost
|
MERIDA COMP TR, 30.9mm diameter, 0mm setback, S: 100mm travel seatpost - M: 125mm travel seatpost - L/XL: 150mm travel seatpost
|
|
Handlebar
|
MERIDA EXPERT CC, material: aluminium, 740mm width, 10mm rise
|
|
Discs
|
Shimano RT10, 180mm
|
|
Brakes
|
Tektro HD-M275
|
|
Crankset
|
Shimano Deore M5100, 32 teeth, 170 mm-S, 175 mm-M up
|
|---|---|
|
Shifter
|
Shimano SL -MT500-IL / Shimano Deore M5100
|
|
Bottom bracket
|
Shimano MT500-PA pressfit
|
|
Rear derailleur
|
Shimano Deore RD-M5100-SGS
SGS
11s
|
|
|
|
|
Cassette
|
Shimano Deore CS-M5100-11
HG
|
|
11-51T |
|
|
Chain
|
KMC X11
|
|
Frame
|
ONE-TWENTY LITE, 120mm suspension travel, material: aluminium, 29x2.35" max. wheelsize, 148x12mm axle standard, BB92 bottom bracket standard
|
|---|---|
|
Rear suspension
|
SR Suntour Unair LOR8
|
|
Front suspension
|
SR Suntour XCR-34
|
|
Rims
|
MERIDA COMP CC, 20mm inner width, material: aluminium
|
|---|---|
|
Tires
|
Maxxis Rekon, 29x2.4", wire
|
|
Rear hub
|
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
|
|
Front hub
|
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
|
Geometry
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
|
a
Seat tube length
|
400,0
|
440,0
|
480,0
|
520,0
|
|
b
Seat tube angle
|
75,5º
|
75,5º
|
75,5º
|
75,5º
|
|
c
Top tube length
|
572,0
|
592,0
|
614,0
|
637,0
|
|
d
Head tube length
|
95,0
|
95,0
|
105,0
|
115,0
|
|
e
Head tube angle
|
67,3º
|
67,3º
|
67,3º
|
67,3º
|
|
f
Rake
|
51,0
|
51,0
|
52,0
|
50,0
|
|
g
Trail
|
101,0
|
101,0
|
100,0
|
102,0
|
|
h
Wheelbase
|
1141,0
|
1161,0
|
1185,0
|
1208,0
|
|
i
Chainstay length
|
435,0
|
435,0
|
435,0
|
435,0
|
|
j
Bottom bracket drop
|
40,0
|
40,0
|
40,0
|
40,0
|
|
k
Stack height
|
607,0
|
607,0
|
616,0
|
626,0
|
|
l
Reach
|
415,0
|
435,0
|
455,0
|
475,0
|
|
m
Standover height
|
707,0
|
730,0
|
759,0
|
787,0
|
|
x
Bottom bracket height
|
334,0
|
334,0
|
334,0
|
334,0
|
|
y
Front center
|
709,0
|
729,0
|
753,0
|
776,0
|
