Groupset
SRAM GX Eagle
Frame material
Alloy
Wheel size
27,5"
Suspension type
Full suspension
Weight
14,6 kg
Front travel
170mm
Rear travel
170mm
About the Mondraker Dune R 2020
The Mondraker Dune R 2020 is a Full suspension Downhill Mountain Bike with a alloy frame. Equipped with a SRAM GX Eagle drivetrain of 12 gears (1x12). Its features include boost 110 , boost 148, and hydraulic disc brakes. The bike weighs approximately 14,6 kg.
Features
Boost 110
More info
Boost 110
Boost 148
More info
Boost 148
Hydraulic disc brakes
More info
Hydraulic disc brakes
Tubeless ready
More info
Tubeless ready
Specifications
|
Grip
|
Onoff Desert, 1lock-on, 135mm
|
|---|
|
Steam
|
Onoff Sulfur FG 30mm reach, 0°, 6061 forged alloy, 31.8 mm clamp
|
|---|---|
|
Saddle
|
SDG Fly MTN, Light PU foam, steel rails, Cordura sides
|
|
Headset
|
Onoff Titan with ACB sealed bearings, top 41.8x30.5x8x45°x45°, bottom 51.9x40x8x45°x45°
|
|
Seatpost
|
Onoff Pija, 337x100mm on S, 387x125mm on M, 425x150mm on L/XL
|
|
Handlebar
|
OnOff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9° backsweep, 5° upsweep, 31.8mm clamp
|
|
Brake lever
|
SRAM G2 RSC
|
|
Brakes
|
SRAM G2 RSC
Hydraulic
248 g
|
|
|
|
|
Crankset
|
Truvativ Descendant 6K Eagle DUB, 170mm on S/M and 175mm on L/XL
|
|---|---|
|
Shifter
|
SRAM GX Eagle 12-speed
|
|
Bottom bracket
|
SRAM DUB 73mm BSA
|
|
Front derailleur
|
None (1x only)
|
|
Cassette
|
SRAM XG-1275 Eagle
12s
|
|
|
|
|
Chain
|
SRAM NX Eagle
252 g
|
|
|
|
|
Rear derailleur
|
SRAM GX Eagle
12s
|
|
|
|
|
Front suspension
|
FOX FLOAT FIT GRIP EVOL Performance, 37mm offset
|
|---|---|
|
Frame
|
Aluminum
|
|
Rear suspension
|
Fox Float DPX2 Performance EVOL
|
|
Rims
|
DT Swiss E1900 Spline, 30mm internal width, tubeless ready, 28 holes
|
|---|---|
|
Tires
|
Maxxis Minion DHF 2.5 WT, tubeless ready, 3C, EXO, Maxx Terra, 60TPI, folding bead front and Maxxis Minion DHR 2.4 WT, tubeless ready, dual compound, EXO, 60TPI, folding bead rear
|
|
Spokes
|
DT Swiss Champion straight pull
|
|
Rear hub
|
DT Swiss 350, 15x110mm front and 12x148mm rear
|
|
Front hub
|
DT Swiss 350, 15x110mm front and 12x148mm rear
|
Geometry
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
|
a
Seat tube length
|
380,0
|
420,0
|
470,0
|
510,0
|
|
b
Seat tube angle
|
74,5º
|
74,5º
|
74,5º
|
74,5º
|
|
c
Top tube length
|
607,0
|
633,0
|
656,0
|
677,0
|
|
d
Head tube length
|
110,0
|
110,0
|
120,0
|
120,0
|
|
e
Head tube angle
|
65,5º
|
65,5º
|
65,5º
|
65,5º
|
|
f
Rake
|
-
|
-
|
-
|
-
|
|
g
Trail
|
-
|
-
|
-
|
-
|
|
h
Wheelbase
|
1187,0
|
1212,0
|
1237,0
|
1261,0
|
|
i
Chainstay length
|
431,0
|
431,0
|
431,0
|
431,0
|
|
j
Bottom bracket drop
|
5,0
|
5,0
|
5,0
|
5,0
|
|
k
Stack height
|
592,0
|
592,0
|
600,0
|
609,0
|
|
l
Reach
|
442,0
|
467,0
|
487,0
|
507,0
|
|
m
Standover height
|
-
|
-
|
-
|
-
|
|
x
Bottom bracket height
|
350,0
|
350,0
|
350,0
|
350,0
|
|
y
Front center
|
-
|
-
|
-
|
-
|
