Norco Fluid FS 3 Women's 29 2019

Women's Bike
MTB Trail
Groupset
SRAM NX
Frame material
Alloy
Wheel size
29"
Suspension type
Full suspension
Front travel
130mm
Rear travel
120mm
Norco Fluid FS 3 Women's 29 2019

About the Norco Fluid FS 3 Women's 29 2019

The Norco Fluid FS 3 Women's 29 2019 is a Full suspension Trail Mountain Bike with a alloy frame. Equipped with a SRAM NX drivetrain of 11 gears (1x11). Its features include dropper seatpost, boost 110 , and boost 148.

Features

The Norco Fluid FS 3 Women's 29 2019 has 4 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
VP, Lock-on
Pedals
VP Nylon Flat, 9/16"
Components
Steam
TranzX 6061 alloy, 35mm
Saddle
Norco XC
Headset
Angular sealed cartridge bearings
Seatpost
TranzX YSP18JL Stealth dropper, 130mm, 1x lever
Handlebar
TranzX 6061 DB Alloy, 780mm
Brake lever
Tektro HD-M275
Brakes
Tektro Auriga
Drivetrain
Crankset
Truvativ Stylo 6K, 175mm
Shifter
SRAM NX, 11-speed
Bottom bracket
Truvativ PowerSpline, threaded BSA 73mm
Rear derailleur
SRAM NX 11s 322 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
42
Model
RD-NX-1-A1
Name
NX 1x11 X-HORIZON™ Rear Derailleur
Pulley bearings material
Steel
Speed
11s
Weight
322
Cassette
SRAM PG-1130 11s
Cog finish cassete
Black, Silver
Cog sizes
11-26t:11,12,13,14,15,16,17,19,21,23,26
11-28t:11,12,13,14,15,16,17,19,22,25,28
11-32t:11,12,13,14,15,17,19,22,25,28,32
11-36t:11,12,13,15,17,19,22,25,28,32,36
11-42t: 11,13,15,17,19,22,25,28,32,36,42
Gearing
11-26t
11-28t
11-32t
11-36t
11-42t
Model
CS-PG-1130-A1
Name
PG-1130 Cassette
Speed
11s
Technology cassete
PG
Chain
SRAM PC-1110 259 g
Chain connector
PowerLock
Chain length links
114 links
Color inner link
Grey
Color outer link
Grey
Compat speed
11s
Inner link finish
Polished
Model
CN-1110-A1
Name
PC-1110 Chain
Outer link finish
Polished
Pin variant
Solid Pin
Weight based on
114 links
Weight
259
Frameset
Frame
Aluminum
Front suspension
RockShox Recon RL Solo Air
Color
Diffusion Black, Gloss Black, Gloss White
fork offset
42mm (27.5"), 46mm (29"), 51mm (29")
Max tire width (mm)
62, 81
Maximum rotor size
220mm
Minimum rotor size
160mm
Model
FS-RCN-RL-A1
Name
Recon RL
Spring
Solo Air
Travel (mm)
100mm, 120mm, 130mm, 140mm, 150mm, 80mm
Upper tube type
32mm straight wall steel
Wheel size
27.5", 29"
Rear suspension
RockShox Deluxe R
Body eyelet
Bearing, No Bushing, Standard
Compression tune
L, L3, M
Eye to eye stroke
145x35(TR), 165x37.5(TR), 165x40(TR), 165x42.5(TR), 165x45(TR), 170x35, 185x47.5(TR), 185x50(TR), 185x52.5(TR), 185x55(TR), 190x37.5, 190x40, 190x42.5, 190x45, 205x57.5(TR), 205x60(TR), 205x62.5(TR), 205x65(TR), 210x47.5, 210x50, 210x52.5, 210x55, 230x57.5, 230x60, 230x62.5, 230x65
Model
RS-DLX-R-B1
Name
Deluxe R
Rebound tune
L, M
Shaft eyelet
Bearing, Standard, Trunnion
Wheels
Rims
WTB STP i29 TCS, 32 hole, 29mm internal width
Tires
Maxxis Forekaster, 2.6", EXO, TR, folding
Spokes
Stainless steel 14g, black
Rear hub
Front: Alloy, Boost 110mm x 15mm, Rear: Joytech D342TSE, Boost 12x148mm
Front hub
Front: Alloy, Boost 110mm x 15mm, Rear: Joytech D342TSE, Boost 12x148mm

Geometry

Size MD
a
Seat tube length
420,0
b
Seat tube angle
76,0º
c
Top tube length
593,0
d
Head tube length
100,0
e
Head tube angle
66,5º
f
Rake
-
g
Trail
-
h
Wheelbase
1172,0
i
Chainstay length
432,0
j
Bottom bracket drop
32,0
k
Stack height
606,0
l
Reach
443,0
m
Standover height
763,0
x
Bottom bracket height
342,0
y
Front center
-
