Groupset
SRAM NX
Frame material
Alloy
Wheel size
27,5"
Suspension type
Hardtail
Front travel
120mm
About the Norco Fluid HT 3 27.5 2019
The Norco Fluid HT 3 27.5 2019 is a Hardtail Trail Mountain Bike with a alloy frame. Equipped with a SRAM NX drivetrain of 11 gears (1x11). Its features include dropper seatpost, boost 110 , and hydraulic disc brakes.
Features
Dropper seatpost
More info
Dropper seatpost
Boost 110
More info
Boost 110
Hydraulic disc brakes
More info
Hydraulic disc brakes
Specifications
|
Grip
|
VP, Lock-On
|
|---|---|
|
Pedals
|
VP Nylon Flat Pedals, 9/16"
|
|
Steam
|
Alloy 60mm x 31.8
|
|---|---|
|
Saddle
|
Norco XC Saddle
|
|
Headset
|
Angular Sealed Cartridge Bearings - Tapered
|
|
Seatpost
|
TranzX YSP18JL Stealth Dropper, 120mm Travel, 31.6mm, 1x Lever
|
|
Handlebar
|
X6 Alloy 750mm x 31.8
|
|
Brake lever
|
Tektro HD-M275
|
|
Brakes
|
Tektro HD-M275
|
|
Crankset
|
SR Suntour Zeron Boost, 170mm (XS/S) | 175mm (M/L/XL), 30T
|
|---|---|
|
Shifter
|
Rear: SRAM NX, 11 Speed, Front: -
|
|
Bottom bracket
|
SR Suntour BB24, Threaded BSA 73mm
|
|
Rear derailleur
|
SRAM NX
11s
322 g
|
|
|
|
|
Cassette
|
SRAM PG-1130
11s
|
|
11-28t:11,12,13,14,15,16,17,19,22,25,28 11-32t:11,12,13,14,15,17,19,22,25,28,32 11-36t:11,12,13,15,17,19,22,25,28,32,36 11-42t: 11,13,15,17,19,22,25,28,32,36,42 11-28t 11-32t 11-36t 11-42t |
|
|
Chain
|
SRAM PC-1110
259 g
|
|
|
|
|
Frame
|
Norco Fluid HT, Aluminum, 9x141mm QR Dropouts
|
|---|---|
|
Front suspension
|
SR Suntour XCM 32
|
|
Rims
|
Alloy XD26, 32 Hole, 30mm Internal Width
|
|---|---|
|
Tires
|
WTB Ranger, 27.5x2.8”
|
|
Rear hub
|
Joytech D142TSE, 9x141mm QR
|
|
Front hub
|
Novatec Boost 110mm x 15mm
|
Geometry
| Size | MD | LG | XL |
|---|---|---|---|
|
a
Seat tube length
|
440,0
|
470,0
|
500,0
|
|
b
Seat tube angle
|
72,7º
|
72,3º
|
71,9º
|
|
c
Top tube length
|
621,0
|
651,0
|
681,0
|
|
d
Head tube length
|
100,0
|
110,0
|
120,0
|
|
e
Head tube angle
|
67,5º
|
67,5º
|
67,5º
|
|
f
Rake
|
51,0
|
51,0
|
51,0
|
|
g
Trail
|
92,0
|
92,0
|
92,0
|
|
h
Wheelbase
|
1148,0
|
1174,0
|
1,2e3
|
|
i
Chainstay length
|
436,0
|
436,0
|
436,0
|
|
j
Bottom bracket drop
|
45,0
|
45,0
|
45,0
|
|
k
Stack height
|
617,0
|
626,0
|
636,0
|
|
l
Reach
|
431,0
|
453,0
|
475,0
|
|
m
Standover height
|
779,0
|
790,0
|
801,0
|
|
x
Bottom bracket height
|
316,0
|
316,0
|
316,0
|
|
y
Front center
|
716,0
|
742,0
|
768,0
|
