Norco Revolver FS 2 27.5 2019
Groupset
SRAM GX Eagle
Frame material
Carbon
Wheel size
27,5"
Suspension type
Full suspension
Front travel
100mm
Rear travel
100mm

About the Norco Revolver FS 2 27.5 2019
The Norco Revolver FS 2 27.5 2019 is a Full suspension Cross Country Mountain Bike with a carbon frame. Equipped with a SRAM GX Eagle drivetrain of 12 gears (1x12). Its features include boost 110 e hydraulic disc brakes.
Features
Boost 110
More info
Boost 110
Hydraulic disc brakes
More info
Hydraulic disc brakes
Specifications
Grip
|
Ergon GA30 Lock On Grip
|
---|
Steam
|
Norco SL Alloy Stem
|
---|---|
Saddle
|
SDG Duster RL
|
Headset
|
Angular Sealed Cartridge Bearings - Tapered
|
Seatpost
|
Norco SL Alloy Post 31.6
|
Handlebar
|
Norco DB Lite 760mm 15mm Riser
|
Brake lever
|
SRAM Level TL
|
Brakes
|
SRAM Level TL
Hydraulic
370 g
|
|
Crankset
|
Truvativ Stylo 6K Eagle 34T DM
|
---|---|
Shifter
|
SRAM GX Eagle 12spd
|
Bottom bracket
|
SRAM PF MTB
|
Chain
|
SRAM GX Eagle
244 g
|
|
|
Cassette
|
SRAM XG-1275 Eagle
12s
|
|
|
Rear derailleur
|
SRAM GX Eagle
12s
|
|
Frame
|
Revolver FS Hi-Mod Carbon 100mm XC Race Frame
|
---|---|
Front suspension
|
RockShox SID RL
Solo Air
|
|
|
Rear suspension
|
RockShox Monarch RL
215 g
|
|
Rims
|
DT Swiss M1900 Spline Wheelset 25mm
|
---|---|
Tires
|
Maxxis Ikon 29"x 2.2"/27.5" x 2.2" TR/EXO
|
Rear hub
|
DT Swiss M1900 Spline Wheelset 25mm
|
Front hub
|
DT Swiss M1900 Spline Wheelset 25mm
|
Geometry
Size | XS |
---|---|
a
Seat tube length
|
380,0
|
b
Seat tube angle
|
75,0º
|
c
Top tube length
|
534,0
|
d
Head tube length
|
100,0
|
e
Head tube angle
|
70,0º
|
f
Rake
|
42,0
|
g
Trail
|
85,0
|
h
Wheelbase
|
1046,0
|
i
Chainstay length
|
419,0
|
j
Bottom bracket drop
|
20,0
|
k
Stack height
|
555,0
|
l
Reach
|
384,0
|
m
Standover height
|
736,0
|
x
Bottom bracket height
|
330,0
|
y
Front center
|
628,0
|
