Norco Sight A3 27.5 2018

MTB Trail
Groupset
SRAM NX
Frame material
Alloy
Wheel size
27,5"
Suspension type
Full suspension
Front travel
140mm
Rear travel
130mm
Norco Sight A3 27.5 2018

About the Norco Sight A3 27.5 2018

The Norco Sight A3 27.5 2018 is a Full suspension Trail Mountain Bike with a alloy frame. Equipped with a SRAM NX drivetrain. Its features include boost 110 , boost 148, and hydraulic disc brakes.

Features

The Norco Sight A3 27.5 2018 has 3 features listed below.
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
SDG Stage 1 lock on grip
Components
Steam
Alloy 6061 35mm bar bore, 50mm (29), 60mm (650B)
Saddle
SDG Fly Mtn
Headset
FSA #57 E ( tapered internal ) 1.5" to 1-1/8"
Seatpost
JD Trans X post 80mm XS, 100mm S, 125mm M,L,XL, 31.6mm
Handlebar
Norco 25mm rise 6061 DB alloy 760/780mm 31.8mm bore
Brake lever
Shimano MT500
Brakes
Shimano BR-MT500 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH59-JK-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Black
Hose joint
Straight
J-Kit spec for OEM
Model
BR-MT500
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad standard
B03S Resin
Pad mount
Split pin (stainless steel)
Piston
2
Piston material
Resin
Recommended disc brake rotor
SM-RT54*
SM-RT56*
Drivetrain
Chain
SRAM 11 speed
Crankset
SR Suntour Zeron Boost 30T (29), 32T (650B) 1X narrow/wide
Shifter
SRAM NX 11
Bottom bracket
SR Suntour 73mm threaded BB
Rear derailleur
SRAM NX 11s 322 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
42
Model
RD-NX-1-A1
Name
NX 1x11 X-HORIZON™ Rear Derailleur
Pulley bearings material
Steel
Speed
11s
Weight
322
Cassette
SRAM NX Eagle
Frameset
Frame
Sight Aluminum 130mm (29), 140mm (650B)
Front suspension
RockShox Revelation RC DebonAir
Color
Diffusion Black, Gloss Black
Damper type
Motion Control
fork offset
37mm (27.5"), 42mm (29"), 46mm (27.5"), 51mm (29")
Max tire width (mm)
81
Maximum rotor size
220mm
Minimum rotor size
180mm
Model
FS-RVL-RC-A2
Name
Revelation RC
Spring
DebonAir
Travel (mm)
120mm, 130mm, 140mm, 150mm, 160mm
Upper tube type
35mm tapered wall aluminum
Wheel size
27.5", 29"
Rear suspension
RockShox Deluxe RT
Body eyelet
Bearing, No Bushing, Standard
Compression tune
L, L1, LC, M
Eye to eye stroke
145x35(TR), 165x37.5(TR), 165x40(TR), 165x42.5(TR), 165x45(TR), 170x35, 185x47.5(TR), 185x50(TR), 185x52.5(TR), 185x55(TR), 190x37.5, 190x40, 190x42.5, 190x45, 205x57.5(TR), 205x60(TR), 205x62.5(TR), 205x65(TR), 210x47.5, 210x50, 210x52.5, 210x55, 230x57.5, 230x60, 230x62.5, 230x65
Lockout force
320
Model
RS-DLX-RT-B1
Name
Deluxe RT
Rebound tune
H, L, M
Shaft eyelet
Bearing, No Bushing, Standard, Trunnion
Wheels
Rims
WTB STP I29 TCS rim, 29mm inner
Tires
Maxxis Forecaster 2.35 folding bead
Spokes
Stainless steel black
Rear hub
Shimano Deore 148x12 boost
Front hub
Shimano Deore 110x15mm

Geometry

Size XS SM MD LG
a
Seat tube length
380,0
405,0
435,0
470,0
b
Seat tube angle
75,42º
74,95º
74,5º
74,06º
c
Top tube length
529,0
559,0
589,0
619,0
d
Head tube length
90,0
100,0
110,0
120,0
e
Head tube angle
66,5º
66,5º
66,5º
66,5º
f
Rake
44,0
44,0
44,0
44,0
g
Trail
107,0
107,0
107,0
107,0
h
Wheelbase
1091,0
1123,0
1154,0
1186,0
i
Chainstay length
417,0
422,0
427,0
432,0
j
Bottom bracket drop
15,0
15,0
15,0
15,0
k
Stack height
577,0
586,0
595,0
604,0
l
Reach
378,0
401,0
423,0
446,0
m
Standover height
769,0
764,0
769,0
781,0
x
Bottom bracket height
339,0
339,0
339,0
339,0
y
Front center
675,0
701,0
728,0
754,0
