Norco Sight C 27.5 2 2018

MTB Trail
Groupset
SRAM GX
Frame material
Carbon
Wheel size
27,5"
Suspension type
Full suspension
Front travel
150mm
Rear travel
140mm
Norco Sight C 27.5 2 2018

About the Norco Sight C 27.5 2 2018

The Norco Sight C 27.5 2 2018 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a SRAM GX drivetrain of 11 gears (1x11). Its features include dropper seatpost, boost 110 , and boost 148.

Features

The Norco Sight C 27.5 2 2018 has 4 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
SDG Stage 1, lock on
Components
Steam
Race Face Aeffect R, 60mm length
Saddle
SDG Fly MTN, chromoly rails
Headset
FSA No. 42 ACB
Seatpost
RockShox Reverb Stealth, trigger style lever, XS/S - 125mm travel, M - 150mm travel, L/XL - 200mm travel
Handlebar
Race Face Turbine R, 800mm width, 20mm rise
Brake lever
SRAM Guide RS
Brakes
SRAM Guide RS Hydraulic 384 g
Application
MTB
Blade material
Aluminum - Forged, Carbon
Bracket disk brake
Direct mount DIR, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(170mm Rear rotor) 30I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (10mm spacer) 10S, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (30mm bracket) 30P, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Gloss Black
Model
DB-GDE-RS-B1
Name
Guide RS
Orientation
Front, Rear
Pad type disc
Steel-backed metal sintered, Steel-backed organic
Weight based on
Direct Mount, 800mm hose, 160mm CL Rotor
Weight
384
Drivetrain
Chain
SRAM PC 12-speed
Crankset
SRAM GX Eagle, boost spacing
Shifter
SRAM GX 12-speed
Chain guide
OneUp S-3, upper guide
Bottom bracket
SRAM GXP 92, pressfit
Rear derailleur
SRAM GX 1x11 X-HORIZON Rear Derailleur 11s 265 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Aluminum
Color
Black, Blue, Red
Max tooth
42
Model
RD-GX-1-A1
Name
GX 1x11 X-HORIZON™ Rear Derailleur
Pulley bearings material
Steel
Speed
11s
Weight based on
RD 1x11 Long Cage Black
Weight
265
Cassette
SRAM XG-1150 11s
Cog finish cassete
Black
Cog sizes
10-42t:10,12,14,16,18,21,24,28,32,36,42
Gearing
10-42t
Model
CS-XG-1150-A1
Name
XG-1150 FULL PIN Cassette
Speed
11s
Technology cassete
XG
Frameset
Frame
Carbon Fiber
Front suspension
RockShox Pike RCT3 Dual Position Air, Solo Air 1835 g
Color
Diffusion Black, Gloss Black, Gloss White
Damper type
Charger, n/a
fork offset
40mm (26"), 42mm (27.5"), 46mm (29"), 51mm (29")
Maximum rotor size
203mm
Minimum rotor size
160mm
Model
FS-PIKE-RCT3-A2
Name
Pike RCT3
Spring
Dual Position Air, Solo Air
Travel (mm)
110mm, 120mm, 130mm, 140mm, 150mm, 160mm
Upper tube type
35mm tapered wall aluminum
Weight based on
26", Solo Air, 265mm tapered aluminum steerer, 15X100mm Maxle Ultimate
Weight
1835
Wheel size
26", 27.5", 27.5" B, 29", 29" B/27.5"+, 29"+
Rear suspension
RockShox Deluxe RT
Body eyelet
Bearing, No Bushing, Standard
Compression tune
L, L1, LC, M
Eye to eye stroke
145x35(TR), 165x37.5(TR), 165x40(TR), 165x42.5(TR), 165x45(TR), 170x35, 185x47.5(TR), 185x50(TR), 185x52.5(TR), 185x55(TR), 190x37.5, 190x40, 190x42.5, 190x45, 205x57.5(TR), 205x60(TR), 205x62.5(TR), 205x65(TR), 210x47.5, 210x50, 210x52.5, 210x55, 230x57.5, 230x60, 230x62.5, 230x65
Lockout force
320
Model
RS-DLX-RT-B1
Name
Deluxe RT
Rebound tune
H, L, M
Shaft eyelet
Bearing, No Bushing, Standard, Trunnion
Wheels
Rims
Race Face AR 30, 30mm inner width
Tires
Front: Maxxis Minion DHF 2.3" EXO, 3C folding bead, Rear: Maxxis Minion DHR II 2.3" EXO, 3C folding bead
Spokes
DT Competition, stainless steal, butted
Rear hub
DT Swiss 350, 15mm x 110mm, 12mm x 148mm, XD driver
Front hub
DT Swiss 350, 15mm x 110mm, 12mm x 148mm, XD driver

Geometry

Size XS SM MD LG
a
Seat tube length
380,0
405,0
435,0
470,0
b
Seat tube angle
75,4º
75,0º
74,5º
74,1º
c
Top tube length
529,0
559,0
589,0
619,0
d
Head tube length
90,0
100,0
110,0
120,0
e
Head tube angle
66,5º
66,5º
66,5º
66,5º
f
Rake
-
-
-
-
g
Trail
-
-
-
-
h
Wheelbase
1091,0
1123,0
1154,0
1186,0
i
Chainstay length
417,0
422,0
427,0
432,0
j
Bottom bracket drop
16,0
16,0
16,0
16,0
k
Stack height
575,0
584,0
593,0
602,0
l
Reach
379,0
401,0
424,0
446,0
m
Standover height
769,0
764,0
769,0
781,0
x
Bottom bracket height
339,0
339,0
339,0
339,0
y
Front center
-
-
-
-
