Norco Sight C1 27.5 2018

MTB Trail
Groupset
SRAM X01 Eagle
Frame material
Carbon
Wheel size
27,5"
Suspension type
Full suspension
Front travel
140mm
Rear travel
130mm
Norco Sight C1 27.5 2018

About the Norco Sight C1 27.5 2018

The Norco Sight C1 27.5 2018 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a SRAM X01 Eagle drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148.

Features

The Norco Sight C1 27.5 2018 has 4 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
SDG Stage 1 lock on grip
Components
Steam
Race Face Turbine basic 35, 50x6 (29), 60mm (650B)
Saddle
SDG Fly Mtn w/chromoly rails
Headset
FSA No 42 ACB 1.5" to 1-1/8"
Seatpost
Rockshox Reverb Stealth, new lever 100 XS,SM, 125 M, 150mm L/XL, 31.6mm
Handlebar
Race Face Next R 800mm wide carbon 20mm rise
Brake lever
SRAM Guide Ultimate
Brakes
SRAM Guide Ultimate Hydraulic 360 g
Application
MTB
Blade material
Carbon
Bracket disk brake
Direct mount DIR, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(170mm Rear rotor) 30I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (10mm spacer) 10S, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (30mm bracket) 30P, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Arctic Grey Anodized, Black Anodized
Model
DB-GDE-ULT-A1
Name
Guide Ultimate
Orientation
Front, Rear
Pad type disc
Steel-backed metal sintered, Steel-backed organic
Weight based on
Direct Mount (Ti Bolts), 800mm hose, 160mm CLX Rotor (Ti Bolts)
Weight
360
Drivetrain
Crankset
SRAM Decendent Eagle carbon crank w/32T (29), 34T (650B)
Shifter
SRAM XO1 Eagle 12 speed
Chain guide
OneUp S-3, upper guide
Bottom bracket
SRAM GXP Pressfit 92 BB
Chain tensioner
One Up S-3 mount upper guide
Chain
SRAM GX Eagle 244 g
Chain connector
PowerLock
Chain length links
126 links
Color inner link
Black
Color outer link
Silver
Compat speed
12s-Eagle
Inner link finish
Black Oxide
Model
CN-EAGL-GX-A1
Name
GX Eagle Chain
Outer link finish
Nickel
Pin variant
Solid Pin
Weight based on
114 links
Weight
244
Cassette
SRAM XG-1275 Eagle 12s
Cog finish cassete
Black
Cog sizes
10-52t:10,12,14,16,18,21,24,28,32,36,42,52
Gearing
10-52t
Model
CS-XG-1275-B1
Name
XG-1275 Eagle Cassette
Speed
12s
Technology cassete
XG
Rear derailleur
SRAM X01 Eagle 12s
Cable pull ratio
X-actuation
Color
Black, Lunar, Red
Max tooth
52
Model
RD-X0-1-B2
Name
X01 Eagle Rear Derailleur
Speed
12s
Frameset
Frame
Sight carbon 130mm (29), 140mm (650B)
Rear suspension
Fox Float DPX2 Performance
Front suspension
Fox 36 Float Factory
Wheels
Rims
E-13 TRS Race carbon rim 31mm inner
Tires
E-13 TRS Race Sticky Triple Compound 2.35
Spokes
DT Competition, stainless steal, butted
Rear hub
DT Swiss 240 Boost 148x12 w/XD driver
Front hub
DT Swiss 240 Boost 110x15

Geometry

Size XS SM MD LG
a
Seat tube length
380,0
405,0
435,0
470,0
b
Seat tube angle
75,4º
75,0º
74,5º
74,1º
c
Top tube length
529,0
559,0
589,0
619,0
d
Head tube length
90,0
100,0
110,0
120,0
e
Head tube angle
66,5º
66,5º
66,5º
66,5º
f
Rake
44,0
45,0
44,0
45,0
g
Trail
107,0
106,0
107,0
106,0
h
Wheelbase
1091,0
1123,0
1154,0
1186,0
i
Chainstay length
417,0
422,0
427,0
432,0
j
Bottom bracket drop
15,0
15,0
15,0
15,0
k
Stack height
575,0
584,0
593,0
602,0
l
Reach
379,0
401,0
424,0
446,0
m
Standover height
769,0
764,0
769,0
781,0
x
Bottom bracket height
339,0
339,0
339,0
339,0
y
Front center
675,0
701,0
728,0
754,0
