Norco Storm 2 27.5 2018

MTB Cross Country
Groupset
Shimano Altus
Frame material
Alloy
Wheel size
27,5"
Suspension type
Hardtail
Front travel
100mm
Norco Storm 2 27.5 2018

About the Norco Storm 2 27.5 2018

The Norco Storm 2 27.5 2018 is a Hardtail Cross Country Mountain Bike with a alloy frame. Equipped with a Shimano Altus drivetrain of 27 gears (3x9). Its features include hydraulic disc brakes.

Features

The Norco Storm 2 27.5 2018 has 1 features listed below.
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
Norco Grip
Pedals
Steel Cage Pedal
Components
Steam
Alloy 80mm/70mm x 31.8
Saddle
Norco XC Saddle
Headset
Zero Stack Headset
Seatpost
Norco Alloy 31.6
Handlebar
X6 Alloy 720mm x 31.8
Brake lever
Tektro HD-M285
Brakes
Tektro HD-M285
Drivetrain
Crankset
Prowheel MPE-901 9spd 40/30/22
Shifter
Rear: Shimano Altus SL-M2000 9spd, Front: Shimano Altus SL-M2000 3spd
Bottom bracket
Cartridge BB
Front derailleur
Shimano Tourney FD-TX800
Cassette
Shimano Altus CS-HG200-9 HG
Combination names
11-32T
11-34T
11-36T
Compatible chain
HG 9-speed
Lock ring finish
Phosphate coated
Lock ring material
Steel
Model
CS-HG200-9
Steel gear finish
Phosphate coated
Steel gear pieces
9
Type
HG
Chain
KMC Z99
Rear derailleur
Shimano Altus RD-M2000 SGS 9s
B axle material
Stainless steel
Bracket finish
Painted
Bracket material
Steel
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG 9-speed
Lower pulley max
36T
Lower pulley min
32T
Model
RD-M2000
P axle finish
Zinc plated
P axle material
Steel
pulley.screws_material
Steel
pulley.sunken_type_pulley_screw
Pulley teeth
11T
Pulley cage
SGS
Speeds
9
Upper pulley max
12T
Upper pulley min
11T
Total capacity
45T
Frameset
Frame
Storm 6061 Alloy XC Frame
Front suspension
SR Suntour XCT HLO
Wheels
Rims
WTB SX19 29"/27.5" DW Rims
Tires
WTB Nineline 29 x 2.25/Beeline 27.5" x 2.25
Rear hub
Joytech D342TSE-HL Alloy Disc QR 9spd
Front hub
Joytech D341DSE Alloy Disc QR

Geometry

Size XXS XS SM MD
a
Seat tube length
340,0
390,0
430,0
470,0
b
Seat tube angle
73,5º
73,1º
72,7º
72,3º
c
Top tube length
506,0
531,0
561,0
591,0
d
Head tube length
110,0
120,0
130,0
145,0
e
Head tube angle
68,5º
68,75º
69,0º
69,25º
f
Rake
42,0
42,0
42,0
42,0
g
Trail
95,0
93,0
91,0
90,0
h
Wheelbase
1020,0
1039,0
1062,0
1087,0
i
Chainstay length
426,0
426,0
426,0
426,0
j
Bottom bracket drop
55,0
55,0
55,0
50,0
k
Stack height
596,0
607,0
617,0
627,0
l
Reach
327,0
344,0
366,0
388,0
m
Standover height
722,0
715,0
724,0
767,0
x
Bottom bracket height
295,0
295,0
295,0
300,0
y
Front center
600,0
618,0
642,0
666,0
