Groupset
SRAM X01 Eagle
Frame material
Carbon
Wheel size
27,5"
Suspension type
Full suspension
Front travel
150mm
Rear travel
135mm
About the Pivot Switchblade RACE X01 27.5+ 2018
The Pivot Switchblade RACE X01 27.5+ 2018 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a SRAM X01 Eagle drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and hydraulic disc brakes.
Features
Dropper seatpost
More info
Dropper seatpost
Boost 110
More info
Boost 110
Hydraulic disc brakes
More info
Hydraulic disc brakes
Specifications
|
Grip
|
Phoenix Team Padloc
|
|---|---|
|
Pedals
|
None included
|
|
Steam
|
Phoenix Team Enduro, 35mm clamp, 35mm length (XS), 45mm length (S), 55mm length (M-XL)
|
|---|---|
|
Saddle
|
WTB Hightail (XS-S), WTB Vigo Race (M-XL)
|
|
Headset
|
Pivot Semi-Sealed Cartridge
|
|
Seatpost
|
FOX Transfer (LEV Integra for XS-S)
|
|
Handlebar
|
Phoenix Race, aluminum, 35mm diameter, 750mm width
|
|
Brake lever
|
Shimano SLX M7000
|
|
Brakes
|
Shimano SLX BR-M7000
|
|
Chain
|
SRAM Eagle, 12-speed
|
|---|---|
|
Crankset
|
SRAM X1 Eagle
|
|
Shifter
|
SRAM GX1 Eagle, 12-speed
|
|
Bottom bracket
|
PF92
|
|
Cassette
|
SRAM X01 Eagle
|
|
Rear derailleur
|
SRAM X01 Eagle
12s
|
|
|
|
|
Frame
|
Carbon Fiber
|
|---|---|
|
Front suspension
|
Fox 36 Performance
|
|
Rear suspension
|
Fox Float DPS Performance
|
|
Rims
|
Sun Ringle Duroc 40 Comp 27.5+
|
|---|---|
|
Tires
|
Maxxis Rekon, 2.8" TR 3C EXO MaxxTerra
|
|
Spokes
|
Sun Ringle Duroc 40 Comp 27.5+
|
|
Rear hub
|
Sun Ringle Duroc 40 Comp 27.5+, Front: Boost, 15mm x 110mm, Rear: Super Boost Plus, 12mm x 157mm
|
|
Front hub
|
Sun Ringle Duroc 40 Comp 27.5+, Front: Boost, 15mm x 110mm, Rear: Super Boost Plus, 12mm x 157mm
|
Geometry
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
|
a
Seat tube length
|
368,3
|
406,4
|
425,5
|
457,2
|
495,3
|
|
b
Seat tube angle
|
74,0º
|
73,75º
|
73,5º
|
73,5º
|
73,5º
|
|
c
Top tube length
|
557,3
|
584,0
|
617,0
|
637,3
|
662,7
|
|
d
Head tube length
|
85,1
|
89,9
|
101,6
|
107,9
|
119,9
|
|
e
Head tube angle
|
66,5º
|
66,5º
|
66,5º
|
66,5º
|
66,5º
|
|
f
Rake
|
-
|
-
|
-
|
-
|
-
|
|
g
Trail
|
-
|
-
|
-
|
-
|
-
|
|
h
Wheelbase
|
1117,9
|
1139,7
|
1174,3
|
1196,6
|
1226,3
|
|
i
Chainstay length
|
430,3
|
430,3
|
430,3
|
430,3
|
430,3
|
|
j
Bottom bracket drop
|
18,0
|
18,0
|
18,0
|
18,0
|
18,0
|
|
k
Stack height
|
607,6
|
612,4
|
623,6
|
629,7
|
640,9
|
|
l
Reach
|
382,3
|
402,4
|
432,3
|
452,4
|
477,3
|
|
m
Standover height
|
683,0
|
704,6
|
710,2
|
711,0
|
734,3
|
|
x
Bottom bracket height
|
337,1
|
337,1
|
337,1
|
337,1
|
337,1
|
|
y
Front center
|
-
|
-
|
-
|
-
|
-
|
