Radon RENDER 9.0 2020

E-Bike
MTB Trail
Groupset
Shimano XT
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Weight
23,7 kg
Front travel
150mm
Rear travel
140mm
Radon RENDER 9.0 2020

About the Radon RENDER 9.0 2020

The Radon RENDER 9.0 2020 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a Shimano XT drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148. The bike weighs approximately 23,7 kg.

Features

The Radon RENDER 9.0 2020 has 4 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
Ergon GE10 Evo
Pedals
not included
Remote
Bosch Kiox
Components
Steam
Race Face Æffect R, 35mm; M/40mm, L/40mm, XL/50mm
Saddle
Ergon SM10 E-Mountain Stealth
Battery
Bosch Powertube 625Wh
Headset
Acros Block-Lock, ZS56/ZS56
Seatpost
Radon Competition Dropper, 31.6mm; M/125mm, L/150mm, XL/150mm
Handlebar
Race Face Æffect R, 35 x 780mm, 20mm rise
Brake lever
Shimano XT BR-M8120/BR-M8100
Brakes
Shimano Deore XT BR-M8120 410 (BL-M8100) g Hydraulic disc brake 4 piston
Average weight (g)
410 (BL-M8100)
Brake hose color kit
Black
Brake hose kit
SM-BH90-SBM
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Series color
Hose joint
Banjo
ICE TECHNOLOGIES pad compatible caliper
J-Kit spec for OEM
Model
BR-M8120
Mount type
Post-type
Oil
SHIMANO Mineral
Pad option
D03S Resin (w/o fin)
Pad option
D02S Metal (w/o fin)
Pad standard
N03A Resin (w/ fin)
Pad standard
N04C Metal (w/ fin)
Pad mount
Pad axle
Piston
4
Piston material
Ceramic
Recommended brake lever
BL-M8100
BL-T8100
Drivetrain
Crankset
e*thirteen Plus e*spec, e*thirteen Chainring, 34T, 165mm
Motor
Bosch Performance Line CX
Shifter
Shimano SLX SL-M7100-IR, I-Spec EV
Chain guide
e*thirteen e*spec Plus
Rear derailleur
Shimano Deore XT RD-M8100 284 g SGS 12s
Average weight (g)
284
B axle hollow
B axle material
Stainless steel
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG 12-speed
Lower pulley max
51T
Lower pulley min
51T
Model
RD-M8100-SGS
P axle material
Steel
pulley.guide_pulley_bearing
Sealed bearing
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
13T
pulley.tension_pulley_bearing
Sealed bearing
Pulley cage
SGS
Speeds
12
Upper pulley max
10T
Upper pulley min
10T
Total capacity
41T
Cassette
Shimano SLX CS-M7100-12 HYPERGLIDE+
Aluminum gear finish
Anodized
Aluminum gear pieces
1
Aluminum spider arm finish
Painted
Aluminum spider arm pieces
1
Combination names
10-45T
10-51T
Compatible chain
HG 12-speed
Lock ring finish
Anodized
Lock ring material
Aluminum
Model
CS-M7100-12
Steel gear finish
Plated
Steel gear pieces
11
Type
HYPERGLIDE+
Weights
10-45T: 513g
10-51T: 534g
Chain
Shimano CN-M7100 252 g
Average weight (g)
252
Chromizing treatment roller link pin
Model
CN-M7100
Pin link plate
Gray
Roller link plate
SIL-TEC
Type
HG 12-speed
Frameset
Frame
RENDER HYBRID; Material: Carbon main frame / Aluminium rear triangle, Max. width tire: 2.6", Powertube Capacity: 625 Wh
Front suspension
Fox 36 Rhythm
Rear suspension
Fox Float DPX2 Performance EVOL
Wheels
Rims
DT Swiss H1900 Spline 29, 30mm, 110/148mm
Tires
Schwalbe Magic Mary, Addix-Soft, TLE, Super Gravity, Kevlar, 29" x 2.6"
Spokes
DT Swiss H1900 Spline wheelset
Rear hub
DT Swiss H1900 Spline wheelset, 6-bolt rotor mounts, 15x110mm Boost front, 12x148mm Boost rear
Front hub
DT Swiss H1900 Spline wheelset, 6-bolt rotor mounts, 15x110mm Boost front, 12x148mm Boost rear

Geometry

Size MD LG XL
a
Seat tube length
425,0
455,0
490,0
b
Seat tube angle
75,5º
75,5º
75,5º
c
Top tube length
583,0
606,0
628,0
d
Head tube length
110,0
120,0
135,0
e
Head tube angle
65,5º
65,5º
65,5º
f
Rake
45,0
45,0
45,0
g
Trail
121,0
121,0
121,0
h
Wheelbase
1206,9
1230,8
1254,2
i
Chainstay length
449,2
449,2
449,2
j
Bottom bracket drop
28,0
28,0
28,0
k
Stack height
607,7
616,8
630,5
l
Reach
432,1
451,9
469,1
m
Standover height
766,0
766,0
766,0
x
Bottom bracket height
346,0
346,0
346,0
y
Front center
759,0
783,0
806,0
