Radon SKEEN TRAIL CF 10.0 SL 2020

MTB Trail
Groupset
SRAM X01 Eagle
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Weight
12,7 kg
Front travel
130mm
Rear travel
120mm
Radon SKEEN TRAIL CF 10.0 SL 2020

About the Radon SKEEN TRAIL CF 10.0 SL 2020

The Radon SKEEN TRAIL CF 10.0 SL 2020 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a SRAM X01 Eagle drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148. The bike weighs approximately 12,7 kg.

Features

The Radon SKEEN TRAIL CF 10.0 SL 2020 has 4 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
SDG Slater
Pedals
not included
Components
Steam
Race Face Turbine, 35mm; 16"/60mm, 18"/60mm, 20"/60mm, 22"/70mm
Saddle
SDG Radar
Headset
Acros AzX, ZS44/ZS56
Seatpost
SDG Tellis Dropper, 31.6mm; 16"/125mm, 18"/150mm, 20"/150mm, 22"/150mm
Handlebar
Race Face Turbine, 35 x 760mm, 10mm rise
Brake lever
SRAM G2 RSC
Brakes
SRAM G2 RSC Hydraulic 248 g
Application
MTB
Blade material
Aluminum - Stamped
Bracket disk brake
Direct mount DIR, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Diffusion Black
Model
DB-G2-RSC-A1
Name
G2 RSC
Orientation
Front, Rear
Pad type disc
Steel-backed metal sintered, Steel-backed organic
Weight based on
Direct Mount 800mm Hose, no clamp/mounting hardware
Weight
248
Drivetrain
Crankset
SRAM X1 Eagle Carbon, DUB, 32T, Boost, 175mm
Shifter
SRAM GX Eagle, Matchmaker X
Chain guide
MRP 1X, ISCG05
Bottom bracket
SRAM DUB, PressFit, 92mm
Chain
SRAM GX Eagle 244 g
Chain connector
PowerLock
Chain length links
126 links
Color inner link
Black
Color outer link
Silver
Compat speed
12s-Eagle
Inner link finish
Black Oxide
Model
CN-EAGL-GX-A1
Name
GX Eagle Chain
Outer link finish
Nickel
Pin variant
Solid Pin
Weight based on
114 links
Weight
244
Cassette
SRAM XG-1275 Eagle 12s
Cog finish cassete
Black
Cog sizes
10-52t:10,12,14,16,18,21,24,28,32,36,42,52
Gearing
10-52t
Model
CS-XG-1275-B1
Name
XG-1275 Eagle Cassette
Speed
12s
Technology cassete
XG
Rear derailleur
SRAM X01 Eagle 12s
Cable pull ratio
X-actuation
Color
Black, Lunar, Red
Max tooth
52
Model
RD-X0-1-B2
Name
X01 Eagle Rear Derailleur
Speed
12s
Frameset
Frame
SKEEN TRAIL CF 29; Material: Carbon mainframe, alloy rear triangle, Max. width tire: 2.4", Hanger: #10240
Rear suspension
Fox Float DPS Factory
Front suspension
Fox 34 Float Factory Kashima
Wheels
Rims
Newmen Evolution SL X.A. 25, 25mm, 110/148mm
Tires
Schwalbe Nobby Nic, Addix-Speedgrip, TLE, Kevlar, 29" x 2.35"
Spokes
Newmen Evolution SL X.A. wheelset
Rear hub
Newmen Evolution SL X.A. wheelset, 110x15mm Boost front, 148x12mm Boost rear
Front hub
Newmen Evolution SL X.A. wheelset, 110x15mm Boost front, 148x12mm Boost rear

Geometry

Size 16" 18" 20" 22"
a
Seat tube length
392,0
425,0
455,0
490,0
b
Seat tube angle
76,5º
76,4º
76,4º
76,4º
c
Top tube length
559,0
580,6
603,5
625,5
d
Head tube length
100,0
110,0
120,0
135,0
e
Head tube angle
66,5º
66,5º
66,5º
66,5º
f
Rake
48,0
49,0
49,0
50,0
g
Trail
110,0
109,0
109,0
108,0
h
Wheelbase
1165,0
1186,0
1210,0
1233,0
i
Chainstay length
427,0
427,0
427,0
427,0
j
Bottom bracket drop
31,6
31,6
31,6
31,6
k
Stack height
597,0
606,0
615,0
628,0
l
Reach
429,0
446,0
466,0
482,0
m
Standover height
709,5
736,8
746,0
756,0
x
Bottom bracket height
343,0
343,0
343,0
343,0
y
Front center
740,0
761,0
785,0
808,0
