Scott Spark 920 2019

Groupset
SRAM GX
Frame material
Carbon
Wheel size
29"
Suspension type
Full suspension
Weight
12,6 kg
Front travel
120mm
Rear travel
120mm
Scott Spark 920 2019

About the Scott Spark 920 2019

The Scott Spark 920 2019 is a Full suspension Trail Mountain Bike with a carbon frame. Equipped with a SRAM GX drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148. The bike weighs approximately 12,6 kg.


Features

The Scott Spark 920 2019 has 6 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
tubeless-ready
Tubeless ready More info

Specifications

Components
Steam
Syncros FL1.5 / Alloy 2014 integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8"
Saddle
Syncros XR2.0 / CROM rails
Headset
Syncros Pro Drop in / Tapered 1.5"-1 1/8" bearing diameter size 42mm and 52mm
Seatpost
FOX Transfer Dropper Remote 31.6mm / S size 100mm / M, L & XL 125mm
Handlebar
Syncros FL1.5 T-Bar / Alloy 7050 D.B. T shape Flat / 9° / 740mm Syncros Pro lock-on grips
Brakes
Shimano SLX BR-M7000
Drivetrain
Crankset
SRAM GX Eagle DUB Boost 32T
Shifter
SRAM GX Eagle Trigger
Chain guide
SCOTT custom
Bottom bracket
SRAM DUB PF integrated / shell 41x92mm
Chain
SRAM GX Eagle 244 g
Chain connector
PowerLock
Chain length links
126 links
Color inner link
Black
Color outer link
Silver
Compat speed
12s-Eagle
Inner link finish
Black Oxide
Model
CN-EAGL-GX-A1
Name
GX Eagle Chain
Outer link finish
Nickel
Pin variant
Solid Pin
Weight based on
114 links
Weight
244
Cassette
SRAM XG-1275 Eagle 12s
Cog finish cassete
Black
Cog sizes
10-52t:10,12,14,16,18,21,24,28,32,36,42,52
Gearing
10-52t
Model
CS-XG-1275-B1
Name
XG-1275 Eagle Cassette
Speed
12s
Technology cassete
XG
Rear derailleur
SRAM GX Eagle 12s
Cable pull ratio
X-actuation
Cage
Long
Cage material
Aluminum
Color
Lunar
Max tooth
52
Model
RD-GX-1-B2
Name
GX Eagle Rear Derailleur
Pulley bearings material
Steel
Speed
12s
Frameset
Frame
Spark 3 Carbon / IMP technology / HMF Mainframe BB92 / Alloy SL 6011 swingarm SW dropouts for Boost 12x148mm 2.6 tire compatible / TBC Trunnion box construction
Front suspension
Fox 34 Float Performance
Rear suspension
Fox NUDE Trunnion
Wheels
Rims
Syncros Silverton 2.5 6 Bolt F: 15x110mm, R: 12x148mm Boost 25mm Tubeless ready rim / 28H / XD / DT RWS
Tires
Maxxis Rekon / 2.4" / 120TPI Kevlar Bead TR Tubeless Ready / EXO 3C maxx Terra

Geometry

Size SM MD LG XL
a
Seat tube length
410,0
440,0
490,0
540,0
b
Seat tube angle
73,8º
73,8º
73,8º
73,8º
c
Top tube length
568,0
598,0
628,0
648,0
d
Head tube length
95,0
95,0
105,0
115,0
e
Head tube angle
67,2º
67,2º
67,2º
67,2º
f
Rake
48,0
48,0
48,0
48,0
g
Trail
100,2
100,2
100,2
100,2
h
Wheelbase
1114,6
1144,6
1175,8
1196,9
i
Chainstay length
431,0
431,0
431,0
431,0
j
Bottom bracket drop
43,0
43,0
43,0
43,0
k
Stack height
586,1
586,1
595,4
604,6
l
Reach
395,7
425,7
453,0
470,3
m
Standover height
731,0
739,0
753,0
771,0
x
Bottom bracket height
327,0
327,0
327,0
327,0
y
Front center
687,0
717,0
748,0
769,0
