Specialized Fuse Expert 27.5+ 2019

MTB Trail
Groupset
SRAM NX Eagle
Frame material
Alloy
Wheel size
27,5"
Suspension type
Hardtail
Front travel
120mm
Specialized Fuse Expert 27.5+ 2019

About the Specialized Fuse Expert 27.5+ 2019

The Specialized Fuse Expert 27.5+ 2019 is a Hardtail Trail Mountain Bike with a alloy frame. Equipped with a SRAM NX Eagle drivetrain of 12 gears (1x12). Its features include dropper seatpost, boost 110 , and boost 148.

Features

The Specialized Fuse Expert 27.5+ 2019 has 7 features listed below.
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
eixo-e-thru
E-THRU AXLE More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
tubeless-ready
Tubeless ready More info

Specifications

Acessories
Grip
Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
Pedals
Specialized Dirt
Components
Steam
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Saddle
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
Seatpost
TransX dropper, 30.9mm, S: 120mm, M/XXL: 150mm Travel
Handlebar
Stout Riser, double-butted alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 750mm width, 31.8mm
Brakes
SRAM Level TL Hydraulic 370 g
Application
MTB
Blade material
Aluminum - Forged
Bracket disk brake
Direct mount DIR, Flat Mount 20mm offset, Flat Mount no offset, Intl Std(140mm Rear,160mm Frt rotor) 0IS, Intl Std(160mm Rear,180mm Frt rotor) 20I, Intl Std(170mm Rear rotor) 30I, Intl Std(180mm Rear,200mm Frt rotor) 40I, Intl Std(200mm Rear rotor) 60I, Post mount (10mm spacer) 10S, Post mount (20mm bracket) 20P, Post mount (20mm spacer) 20S, Post mount (30mm bracket) 30P, Post mount (40mm bracket) 40P
Brake type
Hydraulic
Color
Diffusion Black Anodized, Gloss Black
Model
DB-LVL-TL-A1
Name
Level TL
Orientation
Front, Rear
Pad type disc
Steel-backed metal sintered, Steel-backed organic
Weight based on
Direct Mount, 800mm hose, 160mm CL Rotor (TARGET)
Weight
370
Drivetrain
Crankset
SRAM NX Eagle, DUB, Steel, 30T
Shifter
SRAM NX Eagle, trigger, 12-speed
Bottom bracket
SRAM, DUB, PF30
Chain
SRAM NX Eagle 252 g
Chain connector
PowerLock
Chain length links
126 links
Color inner link
Grey
Color outer link
Grey
Compat speed
12s-Eagle
Inner link finish
Polished
Model
CN-EAGL-NX-A1
Name
NX Eagle Chain
Outer link finish
Polished
Pin variant
Solid Pin
Weight based on
114 links
Weight
252
Rear derailleur
SRAM NX Eagle 12s 339 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
50
Model
RD-NX-1-B1
Name
NX Eagle Rear Derailleur
Pulley bearings material
Steel
Speed
12s
Weight
339
Cassette
SRAM NX Eagle
Frameset
Frame
Specialized M4 Aluminum w/ Smooth Welds, tapered head tube and seat tube, forged post-mount 160mm disc, 148mm thru-axle dropout, alloy replaceable derailleur hanger
Front suspension
RockShox Reba RL Solo Air 1620 g
Color
Diffusion Black, Gloss Black, Gloss White
Damper type
n/a, RL
fork offset
40mm (26"), 42mm (27.5"), 46mm (29"), 51mm (29")
Maximum rotor size
200mm
Minimum rotor size
160mm
Model
FS-REBA-RL-A6
Name
Reba RL
Spring
Solo Air
Travel (mm)
100mm, 120mm, 80mm
Upper tube type
32mm straight wall aluminum
Weight based on
15x100 Maxle Stealth, Tapered steerer, 120mm travel
Weight
1620
Wheel size
26", 27.5", 27.5" B, 29", 29" B/27.5"+
Wheels
Rims
Stout Trail SL 27.5, 38mm internal width, tubeless ready, disc-specific
Tires
Purgatory, GRID casing, GRIPTON® compound, 2Bliss Ready, 27.5 x 3.0"
Spokes
Stainless, 14g
Rear hub
Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
Front hub
Specialized, sealed cartridge bearings, 15x110mm thru-axle, 24h

Geometry

Size SM MD LG XL XXL
a
Seat tube length
394,0
434,0
470,0
505,0
555,0
b
Seat tube angle
74,0º
73,0º
73,0º
73,0º
73,0º
c
Top tube length
569,0
602,0
627,0
650,0
673,0
d
Head tube length
95,0
100,0
115,0
130,0
150,0
e
Head tube angle
67,5º
67,5º
67,5º
67,5º
67,5º
f
Rake
51,0
51,0
51,0
51,0
51,0
g
Trail
95,0
95,0
95,0
95,0
95,0
h
Wheelbase
1108,0
1130,0
1155,0
1179,0
1205,0
i
Chainstay length
424,0
424,0
424,0
424,0
424,0
j
Bottom bracket drop
51,0
51,0
51,0
51,0
51,0
k
Stack height
604,0
608,0
623,0
637,0
655,0
l
Reach
394,0
414,0
434,0
452,0
470,0
m
Standover height
751,0
775,0
800,0
824,0
860,0
x
Bottom bracket height
306,0
306,0
306,0
306,0
306,0
y
Front center
689,0
708,0
735,0
760,0
786,0
