Trek Fuel EX 7 2022

MTB Trail
Groupset
SRAM NX Eagle
Frame material
Alloy
Wheel size
27,5" / 29"
Suspension type
Full suspension
Weight
14,48 kg
Front travel
140mm
Rear travel
130mm
Price
$2,879.10
Trek Fuel EX 7 2022

About the Trek Fuel EX 7 2022

The Trek Fuel EX 7 2022 is a Full suspension Trail Mountain Bike with a alloy frame. Equipped with a SRAM NX Eagle drivetrain of 12 gears (1x12). Its features include internal routing, dropper seatpost, and boost 110 . The bike weighs approximately 14,48 kg.

Features

The Trek Fuel EX 7 2022 has 8 features listed below.
cabeamento-interno
Internal routing More info
canote-retratil
Dropper seatpost More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
eixo-e-thru
E-THRU AXLE More info
freio-hidraulico
Hydraulic disc brakes More info
tapered-head-tube
Tapered head tube More info
tubeless-ready
Tubeless ready More info

Specifications

Acessories
Grip
Bontrager XR Trail Comp, nylon lock-on
Components
Steam
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 50mm length
Saddle
Bontrager Arvada, steel rails, 138mm width
Headset
Knock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom
Seatpost
Size: XS, S, TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length; Size: M, ML, L, XL, XXL, TranzX JD-YSP18, 150mm travel, internal routing, 31.6mm, 445mm length
Handlebar
Bontrager alloy, 31.8mm, 15mm rise, 750mm width
Discs
Size: XS, S, M, ML, L, XL, XXL, Shimano RT56, 6-bolt, 180mm; Size: XS, S, M, ML, L, XL, XXL, SRAM CenterLine, 6-bolt, round edge, 180mm
Brakes
Shimano BR-MT410 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH59-JK-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Black (SHIMANO logo)
Hose joint
Straight
J-Kit spec for OEM
Model
BR-MT410
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad standard
B03S Resin
Piston
2
Piston material
Resin
Recommended disc brake rotor
SM-RT30*
SM-RT54*
SM-RT56*
Drivetrain
Crankset
Size: XS, S, M, ML, L, SRAM NX Eagle, DUB, 30T steel ring, Boost (52mm chainline), 170mm length; Size: M, ML, L, XL, XXL, SRAM NX Eagle, DUB, 30T steel ring, Boost (52mm chainline), 175mm length
Shifter
SRAM NX Eagle, 12 speed
Bottom bracket
SRAM DUB, 92mm, PressFit
Chain
SRAM NX Eagle 252 g
Chain connector
PowerLock
Chain length links
126 links
Color inner link
Grey
Color outer link
Grey
Compat speed
12s-Eagle
Inner link finish
Polished
Model
CN-EAGL-NX-A1
Name
NX Eagle Chain
Outer link finish
Polished
Pin variant
Solid Pin
Weight based on
114 links
Weight
252
Rear derailleur
SRAM NX Eagle 12s 339 g
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
50
Model
RD-NX-1-B1
Name
NX Eagle Rear Derailleur
Pulley bearings material
Steel
Speed
12s
Weight
339
Cassette
SRAM PG-1230 Eagle 12s 615 g
Cog finish cassete
Black
Cog sizes
11-50t:11,13,15,17,19,22,25,28,32,36,42,50
Gearing
11-50t
Model
CS-PG-1230-A1
Name
PG-1230 Eagle Cassette
Speed
12s
Technology cassete
PG
Weight
615
Frameset
Frame
Alpha Platinum Aluminum, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130mm travel
Front suspension
RockShox 35 Gold RL DebonAir
Color
Diffusion Black, Gloss Black
Damper type
Motion Control
fork offset
37mm (27.5"), 44mm (27.5"), 44mm (29"), 51mm (29")
Max tire width (mm)
81
Maximum rotor size
220mm
Minimum rotor size
180mm
Model
FS-35G-RL-A1
Name
35 Gold RL
Spring
DebonAir
Travel (mm)
100mm, 120mm, 130mm, 140mm, 150mm, 160mm
Upper tube type
35mm straight wall aluminum
Wheel size
27.5", 29"
Rear suspension
Fox Float Performance EVOL
Wheels
Rims
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Tires
Size: XS, S, M, ML, L, XL, XXL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120tpi, 29.x2.40''; Size: XS, S, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60''; Size: S, M, ML, L, XL, XXL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60''
Spokes
DT Swiss Champion, J-Bend, Black
Front hub
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle

Geometry

Size 14" High 14" Low 15.5" High 15.5" Low 17.5" High 17.5" Low 18.5" High 18.5" Low 19.5" High 19.5" Low 21.5" High 21.5" Low 23" High 23" Low
a
Seat tube length
355,0
356,0
395,0
395,0
420,0
420,0
435,0
435,0
450,0
450,0
500,0
500,0
540,0
540,0
b
Seat tube angle
75,5º
75,0º
75,5º
75,0º
75,5º
75,0º
75,5º
75,0º
75,5º
75,0º
75,5º
75,0º
75,5º
75,0º
c
Top tube length
551,0
552,0
573,0
574,0
608,0
609,0
624,0
625,0
639,0
640,0
668,0
669,0
693,0
694,0
d
Head tube length
90,0
90,0
100,0
100,0
100,0
100,0
105,0
105,0
105,0
105,0
120,0
120,0
140,0
140,0
e
Head tube angle
66,5º
66,0º
66,5º
66,0º
66,5º
66,0º
66,5º
66,0º
66,5º
66,0º
66,5º
66,0º
66,5º
66,0º
f
Rake
42,0
43,0
42,0
43,0
43,0
43,0
43,0
43,0
43,0
43,0
43,0
43,0
43,0
43,0
g
Trail
106,0
111,0
106,0
111,0
116,0
119,0
116,0
119,0
116,0
119,0
116,0
119,0
116,0
119,0
h
Wheelbase
1125,0
1126,0
1149,0
1150,0
1184,0
1185,0
1201,0
1202,0
1216,0
1217,0
1247,0
1248,0
1275,0
1276,0
i
Chainstay length
442,0
443,0
442,0
443,0
442,0
443,0
442,0
443,0
442,0
443,0
442,0
443,0
442,0
443,0
j
Bottom bracket drop
14,0
21,0
14,0
21,0
28,0
34,0
28,0
34,0
27,0
34,0
27,0
34,0
27,0
34,0
k
Stack height
565,0
569,0
574,0
578,0
611,0
615,0
615,0
619,0
615,0
619,0
629,0
633,0
647,0
651,0
l
Reach
406,0
401,0
426,0
421,0
451,0
446,0
466,0
461,0
481,0
476,0
506,0
501,0
526,0
521,0
m
Standover height
706,0
701,0
713,0
706,0
754,0
748,0
757,0
751,0
762,0
756,0
774,0
768,0
812,0
806,0
x
Bottom bracket height
341,0
335,0
341,0
335,0
346,0
340,0
346,0
340,0
346,0
340,0
346,0
340,0
346,0
340,0
y
Front center
683,0
684,0
707,0
708,0
743,0
744,0
760,0
761,0
775,0
776,0
806,0
807,0
834,0
835,0
