BikeWise

Yeti ARC C1.5 2022

MTB Trail
Groupset
Shimano XT
Frame material
Carbon
Wheel size
29"
Suspension type
Hardtail
Weight
12,09 kg
Front travel
130mm
Yeti ARC C1.5 2022

About the Yeti ARC C1.5 2022

The Yeti ARC C1.5 2022 is a Hardtail Trail Mountain Bike with a carbon frame. Equipped with a Shimano XT drivetrain. Its features include dropper seatpost, boost 148, and hydraulic disc brakes. The bike weighs approximately 12,09 kg.

Features

The Yeti ARC C1.5 2022 has 3 features listed below.
canote-retratil
Dropper seatpost More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
ODI ELITE PRO
Components
Steam
RACE FACE RIDE 35X50MM
Saddle
SILVERADO CUSTOM
Headset
CANE CREEK 40 INTEGRATED
Seatpost
FOX TRANSFER 31.6MM / SM: 175MM, MD/LG/XL: 200MM
Handlebar
RACE FACE AEFFECT R 35X760MM
Discs
SHIMANO 180/SHIMANO 180
Brakes
Shimano Deore XT BR-M8000 403 (BL-M8000) g Hydraulic disc brake 2 piston
Average weight (g)
403 (BL-M8000)
Brake hose color kit
Black
Brake hose kit
SM-BH90-SB
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Series color
Hose joint
Banjo
ICE TECHNOLOGIES pad compatible caliper
Model
BR-M8000
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad option
G04S Metal
Pad option
J04C Metal
Pad standard
G02A Resin
G03A Resin
Pad standard
J02A Resin
J03A Resin
Pad mount
Pad axle
Piston
2
Piston material
Ceramic
Recommended brake lever
BL-M8000
BL-T8000
Recommended disc brake rotor
RT-MT800
SM-RT86
Drivetrain
Crankset
SHIMANO XT 32T 170MM
Shifter
SHIMANO XT
Bottom bracket
SHIMANO XT BB92
Rear derailleur
Shimano Deore XT RD-M8100 284 g SGS 12s
Average weight (g)
284
B axle hollow
B axle material
Stainless steel
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG 12-speed
Lower pulley max
51T
Lower pulley min
51T
Model
RD-M8100-SGS
P axle material
Steel
pulley.guide_pulley_bearing
Sealed bearing
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
13T
pulley.tension_pulley_bearing
Sealed bearing
Pulley cage
SGS
Speeds
12
Upper pulley max
10T
Upper pulley min
10T
Total capacity
41T
Chain
Shimano CN-M8100 252 g
Average weight (g)
252
Chromizing treatment roller link pin
Model
CN-M8100
Pin link plate
Gray
Roller link plate
Chromizing
Type
HG 12-speed
Cassette
Shimano Deore XT CS-M8100-12 HYPERGLIDE+
Aluminum gear finish
Anodized
Aluminum gear pieces
2
Aluminum spider arm finish
Painted
Aluminum spider arm pieces
1
Combination names
10-45T
10-51T
Compatible chain
HG 12-speed
Lock ring finish
Anodized
Lock ring material
Aluminum
Model
CS-M8100-12
Steel gear finish
Plated
Steel gear pieces
10
Type
HYPERGLIDE+
Weights
10-45T: 461g
10-51T: 470g
Frameset
Frame
TURQ Series carbon fiber frame, press-fit BB92, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, integrated derailleur hanger, and axle.
Front suspension
Fox 34 Performance
Wheels
Rims
DT SWISS M1900 30MM *Orders may ship with DT SWISS E532 30MM
Tires
MAXXIS MINION DHF 2.6 EXO

Geometry

Size SM MD LG XL
a
Seat tube length
380,0
410,0
450,0
495,0
b
Seat tube angle
76,0º
76,0º
76,0º
76,0º
c
Top tube length
574,4
601,3
623,0
650,4
d
Head tube length
95,0
102,9
109,6
119,6
e
Head tube angle
67,0º
67,0º
67,0º
67,0º
f
Rake
-
-
-
-
g
Trail
-
-
-
-
h
Wheelbase
1140,5
1168,5
1191,2
1220,1
i
Chainstay length
430,0
430,0
430,0
430,0
j
Bottom bracket drop
64,0
64,0
64,0
64,0
k
Stack height
628,7
635,9
642,1
651,3
l
Reach
417,0
442,0
462,0
487,0
m
Standover height
720,0
719,0
717,0
717,0
x
Bottom bracket height
310,0
310,0
310,0
310,0
y
Front center
710,5
738,5
761,2
790,1
