Groupset
SRAM X01
Frame material
Alloy
Wheel size
27,5"
Suspension type
Full suspension
Weight
15,2 kg
Front travel
203mm
Rear travel
200mm
About the YT Tues CF Pro Race Mob Edition 2018
The YT Tues CF Pro Race Mob Edition 2018 is a Full suspension Downhill Mountain Bike with a alloy frame. Equipped with a SRAM X01 drivetrain of 7 gears (1x7). Its features include boost 110 e hydraulic disc brakes. The bike weighs approximately 15,2 kg.
Features
Boost 110
More info
Boost 110
Hydraulic disc brakes
More info
Hydraulic disc brakes
Specifications
|
Grip
|
ODI AG-1 Lock-on
|
|---|
|
Steam
|
Renthal Integra 35, 50mm length
|
|---|---|
|
Saddle
|
SDG I-Fly 2.0, YT Mob custom red
|
|
Headset
|
Acros AZX-255
|
|
Seatpost
|
SDG I-Beam, carbon, 300mm length
|
|
Handlebar
|
Renthal Fatbar Carbon 35, 800mm width, 30mm rise, gold
|
|
Brake lever
|
TRP G-Spec DH, tool-free reach adjust, aluminum
|
|
Brakes
|
TRP G-Spec
|
|
Crankset
|
e*thirteen LG1R Carbon, 165mm length
|
|---|---|
|
Shifter
|
SRAM X0, 7-speed
|
|
Chain guide
|
e*thirteen LG1+
|
|
Bottom bracket
|
e*thirteen G2
|
|
Cassette
|
E*thirteen 7 speed
|
|
Chain
|
SRAM PC-1130
259 g
|
|
|
|
|
Rear derailleur
|
SRAM X01 DH
10s, 7s
|
|
|
|
|
Frame
|
Aluminum
|
|---|---|
|
Front suspension
|
Fox 40 Float Factory
|
|
Rear suspension
|
Fox Float X2 Factory
|
|
Rims
|
e*thirteen LG1R Carbon, 32 hole, 31mm width
|
|---|---|
|
Tires
|
Onza Aquila, 2.4"
|
|
Spokes
|
e*thirteen LG1R
|
|
Rear hub
|
e*thirteen LG1R, Front: 20mm x 110mm, Rear: 12mm x 150mm
|
|
Front hub
|
e*thirteen LG1R, Front: 20mm x 110mm, Rear: 12mm x 150mm
|
Geometry
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
|
a
Seat tube length
|
400,0
|
400,0
|
400,0
|
420,0
|
420,0
|
|
b
Seat tube angle
|
73,5º
|
73,5º
|
73,5º
|
73,5º
|
73,5º
|
|
c
Top tube length
|
584,0
|
606,0
|
633,0
|
659,0
|
682,0
|
|
d
Head tube length
|
100,0
|
105,0
|
115,0
|
123,0
|
129,0
|
|
e
Head tube angle
|
63,5º
|
63,5º
|
63,5º
|
63,5º
|
63,5º
|
|
f
Rake
|
52,0
|
52,0
|
52,0
|
56,0
|
52,0
|
|
g
Trail
|
119,0
|
119,0
|
119,0
|
115,0
|
119,0
|
|
h
Wheelbase
|
1199,0
|
1220,0
|
1248,0
|
1278,0
|
1302,0
|
|
i
Chainstay length
|
435,0
|
435,0
|
435,0
|
435,0
|
435,0
|
|
j
Bottom bracket drop
|
7,0
|
7,0
|
7,0
|
7,0
|
7,0
|
|
k
Stack height
|
601,0
|
605,0
|
614,0
|
621,0
|
636,0
|
|
l
Reach
|
410,0
|
429,0
|
452,0
|
474,0
|
495,0
|
|
m
Standover height
|
707,0
|
709,0
|
714,0
|
723,0
|
727,0
|
|
x
Bottom bracket height
|
348,0
|
348,0
|
348,0
|
348,0
|
348,0
|
|
y
Front center
|
764,0
|
785,0
|
813,0
|
843,0
|
867,0
|
